AANAL VIBRO SCREENS are one of the most Versatile, Reliable and Economical continuous process equipment for carrying out various Size Based Separation like Screening, Sifting, Classification, Grading, Oversize or Undersize Removal, De-Dusting, Dewatering, De-Lumping, Fiber Recovery, Filtration, Pre-Filtration and Scalping.AANAL VIBRO SCREENS are Vibratory or Gyratory Sieving Machine designed on the principle of gyratory motion generated by vibromotor. The machine performs any size based separation with the use of wire mesh or perforated sheet and can work for various application of solid separation or solid liquid separation or slurry separation.   Applications:     The screen is most useful for ceramic, abrasive, sand and glass, ceramic slip, sugar-mixed / screen juice, melt, seed, syrup and sugar-grading, food-biscuit, edible oil Cellulose powder, cattle feed, starch slurry, spices, tea, Table salt, paper and pulp, fiber recovery, black liquor, bulk drugs and many other products. The special custom built screen is also available.

AANAL VIBRO SCREENS are one of the most Versatile, Reliable and Economical continuous process equipment for carrying out various Size Based Separation like Screening, Sifting, Classification, Grading, Oversize or Undersize Removal, De-Dusting, Dewatering, De-Lumping, Fiber Recovery, Filtration, Pre-Filtration and Scalping. AANAL VIBRO SCREENS are Vibratory or Gyratory Sieving Machine designed on the principle of gyratory motion generated by vibromotor. The machine performs any size based separation with the use of wire mesh or perforated sheet and can work for various application of solid separation or solid liquid separation or slurry separation.

Suspension Type Magnets use is recommended for low contamination products. If the frequency of the impurities is very much, it will make a layer shunting magnetic field. Hence, the equipment required frequnet cleaning. Over band type Magnetic Separator is recommended for this type of application. The principal applications are for processing of bulk products such as Culets, Glass, Cofee, Cereals, Minerals, Coal and Sugar etc., AANAL magnets can be installed at the end of belt above the head drum (Image-1) or across the Conveyor belt (Image-2). Toavoid disturbances to the magnetic field, in both cases, the magnetic parts must be placed below the surface of the magnet. The installation shown in Image-1 is recommended for high speeds. Due to trajectory of the products and the fact that it is then fluidized, separation is more efficient.

The Permanent Magnetic Drums consists of a stationary Permanent magnetic assembly having uniform and everlasting Magnetic field accross the entire width of the drum, which is effective over approximately half the drum circumference as shown in Fig-1. Drum shell made of non Magnetic stainless steel revolves around the magnetic field. As the material fed evenly from the chute falls over drum, powerful magnetic field attracts and holds ferrous particles to the revolving shell. As the revolving shell carries the Iron particles through the stationery magnetic field the non-magnetic material falls frelly from the shell while ferrous particles are firmly held until carried beyond devider and out of magnetic field.

single/double deck vibrating screening machines are designed for screening of powders. These machines are simple and robust in construction. available in screen size of 1500 x 600mm,1800mm x 800mm, 2500mm x 800mm. Special sizes as per customer specifications are also manufactured. the vibrating screens are also available with magnetic system to remove fine iron. Contamination from products like chemicals, pharmaceutical and food products etc.

Material : Mild Steel

The Permanent Magnetic Drums consists of a stationary Permanent magnetic assembly having uniform and everlasting Magnetic field accross the entire width of the drum, which is effective over approximately half the drum circumference as shown in Fig-1. Drum shell made of non Magnetic stainless steel revolves around the magnetic field. As the material fed evenly from the chute falls over drum, powerful magnetic field attracts and holds ferrous particles to the revolving shell. As the revolving shell carries the Iron particles through the stationery magnetic field the non-magnetic material falls frelly from the shell while ferrous particles are firmly held until carried beyond devider and out of magnetic field. The strength of the permanent magnetic drum is guaranteed to be greater than corresponding electromagnetic drum. The Permanent magnets used are everlasting magnents and its strenght does not diminish during normal use and can be used through

"AANAL MAGNETIC" manufacture a wide range of Rare Earth and Ferrite Magnetic Pulleys. These Pulleys are widely used to remove tramp iron mixed with the material moving on a conveyor belt. The permanent magnetic pulley is dual-purpose equipment used for protection of crusher Jaws or other machinery and also for purification and concentration of magnetic material from the mines. It has the widest application in food, chemical, ceramic, paper, coal handling, foundry operation and mining industry. The magnetism in a Permanent Magnetic Pulley is generated by internal assembly of magnets enclosed in non magnetic Stainless Steel shell. The steel shaft is extended on both sides. One side is provided with Key-way. The Pulleys have a face width of 50 mm to 100 mm more than the belt width.  The magnetic strength of the pulley depends on the diameter and also quality of magnets used.  Pulleys with Rare Earth Magnets can handle depths up to 300 mm. Pulley width is determined by width of conveyor belt to be used. Diameter depends on depth of material and speed of the conveyor.  It can be designed to suit custemers specificapplication. The magnetic Drum pulley replaces the drive pulley at the end of conveyor belts. In view of the wide variety of conveyor belt types, the drum pulley are supplied made to measure and ready for installation. As the figure clearly show, the magnetic head roller extracts the iron particles from the material flow and carries them to the underside of the belt where they are removed and collected. Head roller magnets for conveyor belt are supplied in permanent magnets.             Features 304 stainless steel faces. Removable mild steel shaft. Four hub styles. Flat face. Key way and set screws.         Options: Taper locks Crowned face Fixed shaft Lagging Stainless steel shaft

Material : SS/MS

the permanent over band magnetic separators (obms) supension type permanent over band magnetic separator are develioped to remove tramp metal from the product carried by vibratory feeders, belt, or inclined planes. These are mainly used to safeguard machine such as shedders, crushers, others and to remove ferrous particles and purify the end products (industries such as coal mines , foundries, cement works, food, sponge iron< glass, char coal, chemical and domestic waste recycling plants) these permanent over band magnetic separator are used for an automatic removal of ferrous contamination. For other purposes, fixed permanent suspension type magnets are more suitable.   applications several types of separators are developed to operate at pre determined working space over the conveyor i.e. 100,150,200,250 and 300 mm. While choosing the over band, the speed of the belt, the nature of the product, its density, its granulometry and size of the particles, which have to be extracted are the main parmameters to be taken into consideration.     construction :   2 "u" section pieces are fitted on the magnet by fastening ears and are supporting bearings of drums and the drumd are enuipped with shafts mounted on removable hubs. All the bearings are equipped with stakes for tightening the belt. Reduction gear coupled electric motor/geared motors by vee belts drives the belt. magnet unit :    this magnet is developed from high intensity stroncium ferrite rare earth magnets and guaranteed to give full magnetic power in the entire life span of installation. One non magnetic stainless steel plate is supplied to cover the poles of the magnet. No need for electrical supply or maintenance. installation :   these magnetic separator can be installed either inline over the terminal head pulley (image-1) or transversal to the conveyor (image-2). For both cases, it is required to foresee non-magnetic products under the magnetic fileld. Most suitable position is inline (photo-1) over the head pulley. The material being conveyed is in vitual suspension and tramp iron is therefore more readily extracted. Good results are obtained by combining a permanent megnetic over and with permanent magnetic pulley at discharge end.

For Faster, More Accurate Sizing, Splitting or Correcting. Designed for use in the sizing of Minerals, Ceramics, Refractories and other powders. The principle on which the  Multi-Form grader operates is equally adaptable for the handling of many ceramic products. The Unit is more than "Just a Screen" It is is a precision tool for producing accurate grades, not merely rough groupings of sizes. It is economical of power and space; screen life is long; upkeep low. Flexible in its adaptability to widely different materials and conditions, it is unyielding in the uniformity of grades produced. Available in several models.

Material : SS/MS

Magnet Grade : Y-38

Country of Origin : Made in India

Manufacture a wide range of Rare Earth and Ferrite Magnetic Pulleys. These Pulleys are widely used to remove tramp iron mixed with the material moving on a conveyor belt. The permanent magnetic pulley is dual-purpose equipment used for protection of crusher Jaws or other machinery and also for purification and concentration of magnetic material from the mines. It has the widest application in food, chemical, ceramic, paper, coal handling, foundry operation and mining industry.

Feature : Removable mild steel shaft.

They are available in both flat and curved shapes and could be installed either above or along the passage of materials flow. They are provided with Clamps and could be located on the conveyor of carrying such materials ideally, they are located 30 mm above the layer of material flow. These plates are constructed with high energy permanent magnets plated in a magnetic circuit. They are extensively used in CTS Tea machinery and in Biscuit stacking machines. They are available in various sizes as per the requirement.

Permanent Magnetic Plates are used for separation of tramp iron found in Tea. Tobacco, Coffee, Cocoa, Milk Powder, Chemicals etc. They are available in both flat and curved shapes and could be installed either above or along the passage of materials flow. They are provided with Clamps and could be located on the conveyor of carrying such materials ideally, they are located 30 mm above the layer of material flow. These plates are constructed with high energy permanent magnets plated in a magnetic circuit. They are extensively used in CTS Tea machinery and in Biscuit stacking machines. They are available in various sizes as per the requirement.

Country of Origin : Made in India

Country of Origin : Made In India

Capacity : 20 Ton/Hour

Country of Origin : Made In India

Capacity : 2 Ton/Hour

Country of Origin : Made In India

Aanal Magnetic The Coolant fluid with iron dust particles falling by gravity to the inlet of the separator from the precision machine tools such as Grinders, Milling Machines, Automats etc. The coolant with iron impurities come into contact with Magnetic Drum and extracts all iron particles. The Magnetic drum is kept clean at all times by a spring steel blade scrapping along the circumference. A Rubber roller squeezes the sludges gathered to ensure that no coolant is wasted. SPECIFICATIONS :- A Magnetic drum enclosed in stainless steel Drum having extra powerful Magnets with uniform Magnetic field all along the circumference. A sturdy welded Stainless Steel/M.s Frame. A neoprene rubber roller with covered bearings. A spring steel blade with adjustments for efficient scrapping of the sludge. An electric motor working 440 Volts with a reduction gear revolving the drum at about 10 RPM
