Annu Valve Products Shahibaug, Ahmedabad, Gujarat

Product Features: Low cost compare to other convention check valve Very low face to face dimensions hence space required for mounting is less than 10% of that conventional valves Very low weight-total weight is only approximately 1/6 the weight of a conventional check valve Short wafer body enables mounting the valve with shorter length fasteners of lesser number compared to flanged swing check valve. Approximately 50% saving in cost of fasteners. Considerable secondary advantages resulting in substantial savings in handling, packing, transportation, installation and maintenance Saving in terms of overall length required for piping Tightening torque to be applied on the companion flange bolting is lower due to face sealing O-rings Practically maintenance free due to fewer number of parts and simple construction Can be installed in horizontal or in vertical line without any special pipe support.

A Vacuum Valve, or Air Vacuum Valve is a safety valve opening inward to admit air to a vessel in which the pressure is less than that of the atmosphere, in order to prevent collapse. Vacuum valve are also known as Trickle Valves.JDM offers premium quality Vacuum Valve which is available in size ranging from 25 mm to 50 mm made of S.S. bar stock 304 / 316 body with stainless steel trim.

Product Features: Bolted cover, Swing type disc Seating is either metal-to- metal or metal seat  to  composition  disk Allows for full flow area during normal operation Easy Installation Low pressure drop across the valve Beautiful design

Steam traps are a type of automatic valve that filters out condensate (i.e. condensed steam) and non-condensable gases such as air without letting steam escape. In industry, steam is used regularly for heating or as a driving force for mechanical power.We supplies the high and robust quality Thermodynamic type Steam Trap for your application. The thermodynamic trap is an extremely robust steam trap with a simple mode of operation. The trap operates by means of the dynamic effect of flash steam as it passes through the trap. The only moving part is the disc above the flat face inside the control chamber or cap. Product Features: Robust and Compact in size Inbuilt Strainer that avoids the Clogging Hardened Disc To Withstand Continuous Water Hammering Seat Integral with Body

A sight glass is a device which allows a person to see the level of fluids or gases in a system, or to look inside a closed system to see what is happening inside. Glass tubes which allow for internal views are sometimes referred to as viewing glasses. Sight glasses are used on many different types of equipment and they add to the safety and ease of operation. Like other equipment parts, a sight glass is replaceable if it becomes damaged or compromised in some wayAnnu Valve Products Sight Glasses are constructed using a robust tie rod cage and heavy wall borosilicate glass. Their design offers a 360 degree viewing area and they are available with both carbon and stainless steel flanges either unlined or PFA lined for corrosive duties. Product Features: Economical Ease of maintenance Wide view area to inspect the fluid Tempered Borosilicate Glass Glass Length available from 100MM to 200MM

The Manual Knife Edge Gate Valves are ideal for use in applications handling Slurries and Fibrous Media, and particularly in the Pulp and Paper Industry where they have the ability to “cut” through the medium to attain a seal. This is in fact how the Valves originally got their name. Knife Gate Valves have short face to face dimensions which make them convenient to install in Plants where space is at a premium.Annu Valve Products has carved prominent position in the Knife Edge Gate Valves manufacturing market, because of superior quality and credibility. Product Features: Sealed design Gate guided through full length of the stroke Mechanically-retained molded body seal Self-cleaning flush out corners prevent deposit buildup in sealing area Full bore unrestricted flow area – no seat pockets or cavities Bi-directional leak-proof sealing

A pressure Relief Valve is a safety device designed to protect a pressurized vessel or system during an overpressure event. An overpressure event refers to any condition which would cause pressure in a vessel or system to increase beyond the specified design pressure or maximum allowable working pressure (MAWP). JDM Spring loaded pressure Relief Valve has been developed to meet the need for a simple, reliable, system actuated device to provide overpressure protection. In order to meet the numerous necessities of our clients, we have been able to provide a wide range of Spring Relief Valve. Product Features: Good Quality Reliable Sturdy Design Durable

Needle valves have a slender, tapered point at the end of the valve stem that is lowered through the seat to restrict or block flow. Fluid flowing through the valve turns 90 degrees and passes through an orifice that is the seat for a rod with a cone shaped tip.JDM Needle Valve are widely used to accurately regulate the flow of liquids and gases at low flow rates. The fine threading of the stem and the large seat area allow for precise resistance to flow. They can be used as both on/off valves and for throttling service. Small, simple needle valves are often used as bleed valves in water-heating applications. We also provide high pressure Needle Valve in Square body design. Product Features: Economical valve for regulating pressure up to 10,000 PSI Suitable for air, water, oil, gas and other fluids Available in Round and Square body design Robust construction Excellent durability

Material : Carbon Steel

Strainer is a type of perforated metal sieve used to strain or filter out solid debris in the water system and where frequent clean-out is not required. JDM strainer has been designed with outstanding quality and the feature you need to streamline your operations. We customized strainer according to the customer specifications and meet the machinery requirements across the industries. Product Features: Perfect finish High Performance Automatic self-cleaning strainer High quality screen Low Pressure drop Robust construction Ease of maintenance

Globe valves are named for their spherical body shape with the two halves of the body being separated by an internal baffle. The baffle inside a globe valve causes the product to divert its direction to move through the baffle. This angled movement means that the product cannot flow as freely and causes a pressure drop after the valve.A globe valve is primarily designed to stop, start and regulate flow. They are generally used for throttling purpose in the industry. JDM Globe valve has excellent and precise throttling ability for high-pressure systems. JDM Globe Valves are designed for structural stability, mechanical strength and safe weld ability. Magnetic particle inspection is carried out for special applications. Our Globe Valves are Precision machined to suit various industrial uses. Product Features: Robust Uniform Wall Thickness Smooth flowing contours Can be installed in liquid, steam, vapour applications

Gauge Glass Pair Valve widely used in various industries to visually monitor the liquid level in tanks or vessel. The compact design of gauge glass cock valves enables it to be safely located close to the tank or vessel.JDM Gauge Glass Pair Valve are machined from Solid Round Bar Stock Needle type design with vent & drain arrangement & available in Screwed (BSP/NPT) Connection. Product Features: Economical valve for regulating pressure up to 5000 PSI Suitable for air, water, oil, gas and other fluids Available in Round and Square body design Robust construction Excellent durability

A gate valve has a flat closure element that slides into the flow stream to stop the fluid. They are one of the most commonly used valves, and are primarily used to permit or prevent the flow of liquids.The distinct feature of a gate valve is that the sealing surfaces between the gate and seats are planar, so gate valves are often used when a straight-line flow of fluid and minimum restriction is desired. Gate valves are primarily designed for on-off services. They are best used in systems which require infrequent use of the valve. They are designed for full-area flow to minimize the pressure drop and allow the passage of a pipe-cleaning pig. Since most of the flow change occurs near the shutoff, the relatively high fluid velocity causes disk and seat wear and eventual leakage if the valve is used to regulate flow.JDM Gate Valve are highly appreciated by our client due to its unmatched quality and sturdy construction. The valve is widely demanded in industries and is offered at the market leading price. Product Features: Rigid Sturdy Design Low Pressure loss Durable BODY MOC Cast Iron (IS 210 Gr. FG 200) Cast Carbon Steel (ASTM A 216 GR. WCB) Cast Stainless Steel (ASTM A 351 GR. CF 8/ CF 8M)Cast Alloy Steel (ASTM A 217 GR. WC 6/ WC 9)Alloy Stainless Steel (ASTM A 351 GR. CF 3 / CF 3M)

A Foot Valve is a one way or anti-siphon valve which is installed on the pick-up end of the water pipe near the bottom of the well.The foot valve prevents water from flowing backwards out of the jet pump and well piping back into the well when the jet pump stops operating. Foot valves are also used on deep well installations to help protect against loss of prime in the well piping system.Based upon the latest technology, our Foot Valve has been proved to be highly efficient in performance. The Foot Valve, we offer, has lower maintenance and longer working life. The company is one of the prominent Foot Valve Supplier and thus offers it at affordable prices.Annu Valve Products supplies JDM brand Foot Valve in various material like PVC, C.I. and Bronze in a size ranging from 15 MM to 200 MM.

Product Features: Smaller in size and lighter weight More feasible in operation Dual spring loaded plates / disc hinged on a central hinge pin Operates on the differential pressure between fluid flow pressure & spring torsion pressure Only Check Valve which can be installed for flow upside down due to spring assisted closure Efficient and Positive sealing under most flow and pressure conditions. Valve closes before flow reversal at zero velocity Long life and trouble -free operation

Product Features: Compact and Robust Design Stronger, Lighter and Smaller than Conventional Swing Check Valve Single Disc type Spring Loaded Disc to Prevent Reverse Flow in Pipe Lines Easy To Installation between Two Pipe Flanges Maintenance Free Metal To Metal or Soft Seat option Full Port Opening Less Expensive to install

Check valves are "automatic" valves that open with forward flow and close with reverse flow. The pressure of the fluid passing through a system opens the valve, while any reversal of flow will close the valve. They are classified as one-way directional valves. This sort of function is essential for a variety of safety applications, as well as for preventing overflow. Most common types of Check valves are swing / tilting disc, Split disc / dual plate, Wafer, lift (piston and ball) and diaphragm.Annu Valve Products manufactures and supplies wide range of Check Valve which includes Swing, Wafer, Disc and Dual Plate type. Product Features: Low cost compare to other convention check valve Very low face to face dimensions hence space required for mounting is less than 10% of that conventional valves Very low weight-total weight is only approximately 1/6 the weight of a conventional check valve Short wafer body enables mounting the valve with shorter length fasteners of lesser number compared to flanged swing check valve. Approximately 50% saving in cost of fasteners. Considerable secondary advantages resulting in substantial savings in handling, packing, transportation, installation and maintenance Saving in terms of overall length required for piping Tightening torque to be applied on the companion flange bolting is lower due to face sealing O-rings Practically maintenance free due to fewer number of parts and simple construction Can be installed in horizontal or in vertical line without any special pipe support.

Material : Cast Iron

Type : Square body

Brand Name : JDM

Media : Air, Water, Gas , Steam

A Butterfly valve is a quarter-turn rotational motion valve that is used to stop, regulate, and start flow. Butterfly valves are easy and fast to open. A 90° rotation of the handle provides a complete closure or opening of the valve. Large Butterfly valves are usually equipped with a so-called gearbox, where the hand wheel by gears is connected to the stem. This simplifies the operation of the valve, but at the expense of speed.Avail the high performance JDM Butterfly Valves at Annu Valve Products, manufactured in various types that include Slim Seal (Centre) disc type, Offset (Eccentric) disc type and Lug type.   Product Features: Economical compare to other valve Low weight Compact design Best in service requiring tight shut-off and precise flow control Easy operation Absence of sliding parts Low head loss Require less space for installation Large capacity Unbreakable pressed steel levers Low leakage rates

Ball valves are quarter-turn, straight-through valves that have a round closure element with matching rounded seats that permit uniform sealing stress. The valve gets its name from the ball that rotates to open and close the valve. Ball valves are used in situations where tight shut-off is required. They are wide duty valves, able to transfer gases, liquids and liquids with suspended solids (slurries).JDM Ball Valves are designed and manufactured to considering maximum safety, performance and long life in, single piece design / two piece design / three piece design / floating ball type. These valves are easy to perform online maintenance, which saves time, energy and money. JDM Ball Valves are provided with blowout proof stem. Specially designed stem seal ensures zero passing through the gland. Moreover, with our innovative ideas, we have gained reputation of one of the top Stainless Ball Valves Manufacturers and Ball Valves Suppliers  Product Features: Dimensional Accuracy Split body design for easy maintenance Seats and packing are replaceable Positive shut off Easy Installation Durability Leak Resistance Blow-Out Proof Stem High Flow capacity in Compact size Valves Super finish Ball for effective sealing 100% Factory tested BODY MOC Cast Iron (IS 210 Gr. FG 200) Cast Carbon Steel (ASTM A 216 GR. WCB) Cast Stainless Steel (ASTM A 351 GR. CF 8/ CF 8M)Bar stock Steel CF 8 / CF8MForged (ASTM A 105/S.S. 304/S.S.316)

Design : 1 Piece / 2 Piece / 3 Piece and 3 Way / 4 Way

Type : Full bore & Reduce bore

Operation : Lever, Pneumatic

Size : 15 MM to 100 MM 15 MM to 50 MM (For Forged)
