Braking Resistors Dealers in Ahmedabad

Braking resistors are used to increase the control torque of the AC drive, for frequently repeated ON-OFF cycles of the AC drive, or for decelerating a load with large inertia.

• Application: Commercial, Residential Sectors
• Color: Silver
• Feature: High Performance
• Voltage: 220V
• Frequency: 50Hz, 60Hz

• Type: Fixed Resistor
• Application: Used to slow down a mechanical system,Industrial
• Function: To dissipate heat
• Performance: Optimum
• Maintenance: Low
• Durability: Long Life
• Temperature Coefficient: + - 240ppm degree C
• Power (W): 60-5000 W

The property of resistors to dissipate heat can be used to slow down a mechanical system. This process is called braking and such a resistor is called a braking resistor.   Features : Lower wear of components. Control motor voltage within safe levels. Faster braking of AC and DC motors. Less service required and higher reliability.

• Shape: Cylindrical, rectangle
• Warranty: 1 year
• Country of Origin: Made in India
• Power Rating: 1/8W
• Usage/Application: Electrical Industry

• Power Ratings: 60 Watts to 4000 Watts in Single Module
• Ohmic Value: 0.1&! to 50K&!
• Dielectric Strength: 2000V a.c. for 1 Minute
• Overload: 5X for 5 seconds

A braking resistor is a high- wattage resistor used in motor control to help a motor stop quickly through a process known as dynamic braking. When disconnected power supply to motor. The motor acts as generator, converting mechanical power back to electrical power. This power is returned to the drive's dc link element (capacitor or reactor). A dc link connected electronics power switch or braking dc chopper control dissipation of this power. As heat in a set of resistors cooling fans may be used to prevent resistor overheating.

• Features: Small Size Low Price,High Power and Excellent Load Life Stability,Strongly Resistant to Moisture, Solvent and Insulation,Excellent Short Time Overload,Both Standard Winding and Non- Inductive Type Winding are Available.

• Max. Power Dissipation (watt): 100 W
• Material: Stainless Steel
• Output: 12V-33A
• R And N: 120mv
• Effciency: 87%
•  :

braking resistor, AC Drives, AC Servo Systems, Programmable Logic Controller

DBR Braking Resistor, Omron Proximity Sensor
