Density Testing Equipment Dealers in Ahmedabad

• Material: Mild Steel
• Voltage: 230 V
• Usage: Industrial
• Display Type: Digital
• Frequency: 50 Hz
• Power Source: Electric

We offer bulk density apparatus specially designed to study, the packing down of powder beds of diffrent pharmaceuticals and chemicals in the process of tablet manufacturing, capsule filling & cosmetics. Installed with an automatic device for preset of strokes. Gear driven noiseless and sturdy motor. Elegantly designed for smooth operation electrically operated on 230v ac,50 hz.digital model with programmable drop counter and buzzer.

We are the leading manufacturers of Field Density Test Apparatus. This apparatus is used for the in place determination, of the dry density of compact, fine and medium grained soils and for layers.

Hexa plast offers best in class Density Test Apparatus. The machine is made with the highest precision to bring the accurate results. We have ensured that the design of the machine matches the international standards. Our Digital density tester comes with multiple microprocessor so that you can set the exact number of taps.

• Type: Automatic
• Application: Laboratory
• Color: Blue, Gray
• Warranty: 1 Year
• Certificate: ISO Certified
• Brand Name: RASAYAn
• Power Supply: Not Applicable
• Voltage: 220 V

RASAYAN make sdi kit is useful for determination of silt density index of water. we are the leading manufacturer of sdi kit in ahmedabad, gujarat, india.RASAYAN Silt Density Index (SDI) kit is used to determine the fouling potential of water feeding a membrane filtration process such as a reverse osmosis (RO) system. This test is defined by its specific procedure (ASTM D- 4189). The ASTM procedure should be referenced for a more detailed description of the procedure. The nature of this test is such that it cannot be run in the laboratory. The SDI test should be run daily on the water entering the RO membranes after the cartridge filters. This frequency can be reduced to weekly once background data proves that less frequent sampling is sufficient. As such, a sample tap should be installed on the RO machine after the cartridge filters. This test can also be run across vessels such as filters or clarifiers to see if they are doing the job expected of them. SDI tests on the raw supply water should be part of every feasibility study for an RO system and it is good to run one periodically during operation of the system to make sure changes haven’t occurred. It is recommended practice to keep a record of SDI values and filters to observe changes over time.Completely assembled in a portable, compact case, ready for on-site testing. Includes ASTM instructions for measuring silt density index. Minimum of 30 PSI water pressure required. Optional Pump Assembly Kit available for pressures below 30 PSI.

SAND REPLACEMENT METHOD: Three sizes Available. 10cm (Small Size) 15cm (Medium Size) 20cm (Large Size) 10cm (Small Size) :-Sand Replacement Method. Consists of Sand Pouring Cylinder, one calibrating container 10 cm dia & a square tray of 30 cm x 30 cm with a central hole of 10 cm diameter. Relevant Standard : IS : 2720(Part-XXVIII) 15cm (Medium Size) :Sand Replacement Method. Consisting of Sand Pouring Cylinder container metal tray hole in the centre. 20cm (Large Size) :Sand Replacement Method. with calibrating container of 250mm internal depth, one metal tray 450 mm square and 50 mm deep with a 200 mm dia hole in the centre.

Specifications: Made of brass with stainless steel wire mesh 6.3mm size ruggedly constructed, approximately 20cm dia x 20cm high. Complete with handle.

SAND REPLACEMENT METHOD: Three sizes Available.10cm (Small Size) :- Sand Replacement Method. Consists of Sand Pouring Cylinder, one calibrating container 10 cm dia & a square tray of 30 cm x 30 cm with a central hole of 10 cm diameter. Relevant Standard : IS : 2720(Part-XXVIII),15cm (Medium Size) : Sand Replacement Method. Consisting of Sand Pouring Cylinder container metal tray hole in the centre.20cm (Large Size) : Sand Replacement Method. with calibrating container of 250mm internal depth, one metal tray 450 mm square and 50 mm deep with a 200 mm dia hole in the centre.

Asphalt Mixer Theoretical Density Meter (AIM 582)   This machine is used for determination of theoretical density of asphalt mixer by vacuum method for applications such as asphalt mixer design, road condition investigation, calculation of porosity and compactness in the road construction quality management.The equipment has a main body fitted with vacuum gauge, two vacuum containers, vibratory table and control panel.The vibratory table operates on manual and automatic mode to release the entrapped air from the asphalt sample.Suitable for operation on 220V, 50Hz, 1phase, AC supply.     Application For determination of theoretical density of asphalt mixer Industry Civil Infrastructure Asphalt / Petroleum/ Bitumen Testing Dams & Tunnels Real Estate Roads, Highways & Bridges Traffic Monitoring Education Building Technology Civil Department Geotechnical Science Colleges Traffic & Transportation Roads, Highways & Bridges

Used for specific gravity and water absorption test of aggregate. The basket is used in conjunction with a suitable electronic balance, a specially designed robust frame to support the electronic balance and water tight container.

• SKU: PO-650 PH-2-3
• Category: SDI Kit
• Pressure: 0-7 kg/cm2
• Gauge dia.: 40mm
• Body color: Transparent
• Beaker capacity: 500 ml

FEATURES Complies with USP, IP specifications Extremely useful for pharmaceutical labs Microprocessor based, easy to use 20 x 4 line alphanumeric LCD display with backlit 16 Soft touch membrane type keys Independent programmable setups for User & USP mode with storage Rs232 Printer attachment facility Automatically calculate result parameters like Tap Density, Initial Density, Compressibility Index and Hausner Ratio Automatically stores last Result Power Failure detection facility User friendly operation with menus & current status indicators. Microprocessor Tap Density Tester, Model 1951 is a density measurement equipment used to measure tapped density of powders, as well as granulated or flaked materials by standardized and repeatable procedures. Instrument uses the latest microprocessor technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. System is equipped with 4 line alphanumeric LCD display with backlit and 16 number of soft touch membrane type keys. The unit is provided with two motorized platforms which allow for 14 ± 2.0 mm drop height for the USP Method I version, and a 3 ±0.3 mm drop height for the USP Method II version. The motorized platforms consist of two cylinder holders with snap-lock mechanism designed to hold 100 ml and 250 ml cylinders. The simultaneous rotating and tapping motion minimizes any possible loss of mass during tapping down.

Density Determination Kit is available in 2 types one to be mounted on the pan and the othertype is with attachment for weigh below the balance. Density Determination Kit consists density weighing pan assembly, stainless steel base for beaker, glass beaker, optional sinker for testing materials having density less than water and software (program) for density determination.   Spacification : * Facility for programming density of liquid (other than water) and temperature of water.* Incase of multiple samples, storage of all the sample weights in air first and then in water, viewing of density of individual samples one by one on the display.* Determination of density of liquid samples (Optional).* Determination of air release value for oil samples (Optional).Range :0.1 mg - 200g1mg - 1000g

      Introduction The equipment is assembled in a mild steel cabinet attractively painted. A central shaft carries a platform with the glass cylinders of 50 ml. each. The platform with the glass cylinders moves up and down at 30 strokes per minutes through a distance of 5 cm and strikes on rubber cushioned bed. Electrically operated, supplied with time switch 0-15 minutes.

• dia: 20cm
• pressure gauge: 1.0 to 10Kg/cm2 x0.1Kg/cm2

Consists of panel for wall mounting on which are fitted wall mounting on which are fitted 1.0 to 10Kgcm2 x0.1Kgcm2 a pressure gauge, Bourdon tube 20cm dia. Glass U-tube manometer for measuring low positive pore pressures negative pore pressures and checking zero error of pressure gauge. It is provided with a mercury trap (Mercury supplied at extra cost ) Null indicator made out of clear transport perspex with mercury trap and cursor to indicate the mercury level.

• Material: Galvanization
• Type: Manual
• Country of Origin: Made in India
• Usage/Application: Civil Lab
• Features: Light weight, Easy to carry, Flawless finish

We are the leading manufacturers, exporters and supplier of this products.

• Material: Mild Steel
• Color: White
• Uses: Laboratory
• Finishing: Powder Coated
• Capacity: 30Ltr

• Density cube size: 25.4 0.076 mm
• Baffle box / material: 45 mm x 45 mm / Stainless Steel

Top funnel with mesh material : 16 mesh, 0.56 mm wire dia, 1.03 mm opening. Baffle material : 4 nos. Glass, Baffle box material : 45 mm x 45 mm Stainless Steel, Bottom funnel : Stainless steel, Density cup – Cylindrical volume : 25.00 0.03 cubic cm, Density cup – inner diameter : 28.30 0.20 mm, Density cup- Cube volume : 16.39 0.05 cubic cm, Instrument stand : Level & vibration free, distance between bottom funnel lower opening & top of the density cup : 19 mm (34 in.)

• Electronic Balance capacity: 5 kg x 0.5gm / 5 kg x 0.1 gm with under bench weighing facility.
• Specification: 20cm dia x 20cm high fitted, galvanized wire mesh of 6.3mm handle for suspending it from the balance
