Electric Control Panels Dealers in Changodar, Ahmedabad

Ease in modification of logic, reduced size, means of remote communications and advances in the technology have made PLC Automation Control Panels an edge over conventional relay based systems. We provide PLC based Panels from PLC of Allen Bradley, Schneider, delta, Siemens, Modicon, GE Fanuc. From small I/O application to the complex I/O systems are provided by us. we develop communication software's for remote communication of the PLC Panels in various different protocols. With PLC based Panels HMI/MMI are provided to provide the operator various messages and controls of the process plants touch screen MMI are provided. To effective control of the system.

Automatic Power Factor Control(APFC) Panels:  These panels are used in commercial buildings and industries power supply for maintain unity power factor.  In case of load variation, a mechanism to switch in and switch out the capacitors is required which is basically handled using APFC panels.

Medium & low voltage draw-out switchgear panels are manufactured in different current and voltage levels, short circuit currents in metal enclosed type according to client request. Type test certification by CPRI upto 65 kA is available. Manufactured under continuous quality monitoring system helps to create world class product, every time…Free standing panels for Industrial applications , expandable or extendable by adding cells.Internal & External Powder coating cover with RAL 7032 or any other custom color.Installation possibility for different type of Fan, Heater, Lighting system, Cooler & ventilation systems etc.Index of protection degree IP 42 ~ 55 according to client requirement.

• Phase: Three Phase
• Rated Voltage: 415 V
• Brand Name: SiBOX
• Rated Current: Upto 6300 Amps
• IP Rating: IP54
• Usage/Application: Motor Control
• Automation Grade: Semi-Automatic
•  :
•  :

Electrical requirements may demand that a single control panel command ten or more wiring assemblies terminating in the crane control panel. Or, we may need to fit several cable extensions into a single, small control panel without sacrificing durability or precision.

A VCB panel is a type of circuit breaker where the arc quenching occurs in vacuum environment. VCB technology is ideal for medium voltage apps. Users can avail the technology for higher voltage, but it is not commercially viable. Material used for electricity carrying contacts is significant as the performance of all VCB panels, including 22 KV VCB panel relies on it. CuCr is an ideal material used by engineers to produce VCB contacts. However, it is still in the line of development technology and they are working hard on this developing technology. VCB or Vacuum Circuit Breaker is renowned technology today and is also known as the most reliable current interruption technology for medium voltage switchgears. Unlike other Relay Control Panel, VCB requires less maintenance. Benefits Of Using Vcb Technology You can expect longer service life in case you are using VCB over other types of circuit breakers. Unlike oil circuit breakers, you don’t have to worry about fire mishaps while using vacuum circuit breakers. Your VCB panel is environmental friendly and user-friendly. There is no complexity faced by user or engineer while replacing faulty or damaged vacuum interrupter. ts.

• Country of Origin: Made in India
• Brand Name: ravel , agni
• I Deal In: New Only
• Product Type: Fire alarm control panel
• Usage/Application: industrial , offie ,commercial

We are capable of undertaking complete fabrication job works that involve designing control panels and control cabinets using mild steel and stainless steel. Catering to the requirements of power industry, we provide these huge structures of control panels and control cabinets that are inhouse manufactured by our team of engineers, welders, fitters, cutters and many more people. These professionals have in-depth knowledge of the intricacies of the job work and carry out the fabrication effeciently using our resources to the fullest.

FEATURES Activat Model : 1-1,1-3,3-3,11ECO, STP, ETP, UV Gold microprocessor based panels are ideally suited for small and medium sized RO plants. Complete operating logic of the process is pre -programmed. Inputs from LPS, HPS and Level Switch (LS). Four outputs in the correct operating sequence namely Raw water pump (RWP), High pressure pump (HPP) Flushing solenoid valve (RL2) and Cleaning Pump (CP)/Doser. The electronics take care of required motor protection such as overload, dry running, single phasing and high conductivity. Debounce time. (In built debounce time to avoid chattering of high pressure pump contactor due to initial dipping in suction pressure). Time based flushing. New improved RO control panels with additional features such in built conductivity,one auxiliary input (can be configured as RWLVL, RL2, ORP, Dosing, TP I/P) & more. OTHER APPLICATIONS Auto multiport Valve. Hydro Pneumatic. Ultra Filtration. Waste water treatment.

Standard KHIRA Display Panel is 1M wide and 2M high. Further panel of 1M width can be added on either side of any individual panel. Each panel comes with laminated top at bottom with stand. Following optional accessories are available:1. Steel sheet shelves with bracket. Size 1000mmW * 300mmD Model: SHDP/100.2. Panel for plastic bin Model: PBDP/1003. Assortment Hooks: Single Hook:50/14, Single Holder:90/15, Twin Holder:90/15,  Twin Hook: 90/15, 6 PronHook:120/240. Saw Blade Holder, Drill bit Socket,  Spanner Hook, Screw Driver Holder.KHIRA Display Panel frame and accessories are powder coated in black color, and for perforated panels you can choose from 4 handsome colors. Key Attributes KHIRA Display Panel are exactly right for modern show room and sales areas Highly visible presentation of all parts of the range Display shelves are available to show additional items. Each stand is free standing and tool can be displayed on either side of it Further panels can be added on either side of any individual panel
