Fly Ash Brick Making Machine Dealers in Odhav, Ahmedabad

We are Manufacturer, Supplier of Fully Automatic Fly Ash Brick Making Machine (FAM-222). This machine has an output of 8 Bricks at one time. Engineered to perfection, the Fully Automatic Fly Ash Brick Making Machine (FAM- 222).comprises of sturdy vibrators, conveyors, pan mixers, etc. This model of Fully Automatic Fly Ash Brick Making Machine (FAM-222) has a production capacity of 10000 Bricks per shift . TECHNICAL SPECIFICATION OF BRICK PLANT SR. NO PARTICULARS DIMENSION 1 OVERALL DIMENSION 10 X 4.5 X 3.9 METER 2 PALLET SIZE 550 X 565 X 18 (MM ) 3 BRICK PER STROKE (230 X 105 X 75 MM ) 8 4 FREQUANCY OF VIBRATER 75- 95 Hz 5 CYCLE TIME 20-25 SEC 6 INSTALLED CAPACITY Kw (H.P ) 25.96 Kw 7 BELT CONVEYOR 22 FOOT 8 PAN MIXER 350 KG – 02 NOS 1500 MM X 400 MM 9 HYDRAULIC TANK OIL CAPACITY 400 LITER 10 MAXIMUM EXCITATION FORCE 40 -45 KN 11 TONNAGE OF HYDRAULIC PRESSURE 100 TON ELECTRIC EQUIPMENTS / MOTOR SR NO PARTICULARS MAKE ( H.P ) 1 HYDRAULIC MOTOR CROMPTON GREAVES 10 HP 2 MAIN PRESS VIBRATOR MOTOR CROMPTON GREAVES 3 HP 3 MATERIAL FEEDER VIBRATION CROMPTON GREAVES 2 HP 4 PALLATE FEEDER CROMPTON GREAVES 1 HP 5 CONVEYOR BELT MOTOR CROMPTON GREAVES 2 HP 6 PAN MIXER – 2 nos CROMPTON GREAVES 7.5+ 7.5 ( 15 H.P ) 7 HYDRAULIC VALVE YUKEN 8 HYDRAULIC PUMP DOWTY / REXROTH 9 PLC AND HMI DELTA OR Schneider 10 ALL ELECTRIC ITEM IN PANEL BOARD DELTA OR Schneider RAW MATERIAL SR NO PARTICULARS UTILIZED RATIO SPECIFICATION 1 FLY ASH 50 % IN POWDER FORM 2 SAND 20 % SIEVED QUALITY â‰Â¤3MM SIZE 3 STONE DUST 20 % LESS THAN 4 MM IN SIZE 4 CEMENT 07 % OPC 53 GRADE BRICK & BLOCK PRODUCTION CAPACITY WITH SIZES SR NO PARTICULARS IMAGE PRODUCTION CAPACITY PCS / Hr SIZES PCS/ MOULD 1 FLY ASH BRICK 230 X10 X75 MM 8 1440 2 FLY ASH BRICK WITHOUT FROG 230 X10 X75 MM 10 1800 3 I SHAPE PAVER BLOCK 200 X 165 X 60 MM 6 720 4 SOLID CONCRETE BLOCK 390 X 190 X 190 MM 3 450 6 HOLLOW CONCRETE BLOCK 390 X 190 X 190

Exporter of fly ash brick making machine manufacturer, automatic brick making machine manufacturers, cement block making machine, fly ash brick making machine in Ahmedabad, Gujarat, india.

We hold an expertise to offer our esteemed clients a unique range of Fly Ash Brick Making Machine. Used for making bricks, the provided machine is available in various technical specifications as per the requirements of our valuable clients. In adherence to the set industry standards, this machine is manufactured by our skilled professionals using high grade components and latest technology. Owing to its long operational life and minimum maintenance, the offered machine is much-admired by our clients. Features: • Less power consumption • long Operational life • Minimum maintenanc

• Method: Hydraulic Pressure
• Automation Grade: Automatic
• Brick Type: Solid
• Capacity (bricks per hour): 1000-1500
• Tolerance: 1 mm

Specifications: The main body from Heavy Plates &; Pipes guide rod will be chromium plated 3 Stroke in a minute 6 Pavers in a Stroke 8 bricks in a stroke Pan Mixer Details: Pan Ø: 1500 mm Side Wall Height: 500 mm Bottom Plate: 12 mm M.S Side Wall Plate: 6 mm M.S Motor: 7.5 HP, 1440 rpm 3 phase Power (Load): Hydraulic: 10 HP Taper Conveyor: 2 HP Down Conveyor: 1 HP Vibrator: 2 HP Pan Mixer: 7.5 HP X 2 NOS Total Power: 30 HP Hydraulic Cylinder: Ramming: 1 no Box: 2 nos Feeder: 1 no Wooden Pallet Conveyor: 1 no Conveyor Belt: Conveyor Belt Thickness: 8 mm Length: 22 foot P.L.C Control: Well designed PLC control system Auto Pallet Function: For hydraulic Tank Capacity for Hydraulic Oil: 400 liters Single Layer Feeder box Electrical PLC control panel Bricks Removal: Through 10 ft conveyor Total Weight: 3500 kg Operating Pressure: 220 bar-100 ton Mixing Rough Material: From pan mixer to conveyor through conveyor to storage box, then storage box to feeder and to auto ram and box

• Capacity: 10-50kg/h, 50-100kg/h, 100-200kg/h
• Finishing: Polished, Unpolished, Chrome Finish, Powder Coated
• Machine Weight: 100-1000kg
• Pressure: Medium Pressure, High Pressure
• Usage: Brick Industry
• Specialities: High Performance, Easy To Operate
• Type: Fly Ash Brick Making Machine
• Brand Name: AAVJO INDUSTRIES
• Material: Cast Iron
• Shape: Rectangular
• Color: Blue
• Condition: New
• Driven Type: Electric
• Country of Origin: India
• Operating Mode: Semi Automatic
• Machine Structure: Horizontal
• Reverse Rotation: No
• Is It Variable Speed: Yes

Fly Ash Brick Making Machine: Model 200 Ton For Bricks Belt Type   With firm commitment to quality, we are presenting for our clients a quality assured Automatic Fly Ash Brick Making Machine that is precisely designed to make superior quality fly ash bricks. The offered machine is highly acclaimed for its consistent performance and high productivity. Our skilled professionals manufacture this machine using progressive technology and quality tested components. Before final dispatch, our provided brick machine is stringently checked by our quality experts to assure its flawless performance.   Features: Anti-corrosive body Sturdy design Highly automatic functions
