Gear Coupling Dealers in Kalupur, Ahmedabad

• Material: Mild Steel
• Packaging Type: Box
• Country of Origin: Made in India
• Application: Mechanical Workshop
• Brand Name: Mangalbhai and Brothers
• Item Code: A-8
• Shape: Round

At, mangalbhai & brothers, we manufacture and export a wide range of finest quality gear couplings. It is a mechanical device useful for transmitting torque between two non-collinear shafts. It comprises a flexible joint set to every shaft.

Gear coupling : Gear coupling is come in different types chain coupling, flexible shaft coupling, HRC couplling,Jaw coupling. ALl those type of the coupling is used in different machinery to joint the long shafting between electrical motor and machinery.

Leveraging upon our vast industry experience, we are engaged in providing a broad range of Gear Couple. Used for transmitting torque and power between two shafts, it is normally used for the coupling of Motor to fly-wheel, fly-wheel to gear box, etc. This couple is robustly fabricated using high quality raw material and sophisticated technology under the supervision of skilled professionals. Specifications: Size: 100 no. to 110 no. Full Gear, Half Couple Features: A torsionally rigid, lubricated design that offers high torque capacity Capable of taking jerk load Rated torque, rated speed, torsional stiffness, and backlash are some of the points considered while designing a gear coupling High Tensile fixing bolts Teeth of the Gear Coupling are properly heat treated All Pitches of the gear coupling are precisely checked

• Finishing: Polished
• Material: Nylon
• Application: Automobile Industry
• Shape: Round
• Diameter: 5-10 mm

Half gear coupling A gear coupling is a mechanical device for transmitting torque between two shaft. It consist of a flexible joint fixed too each shaft

• Material: Metal, EN8,9
• Finishing: Polished
• Shape: Round
• Color: Black, BLACK
• Condition: New
• Size: 100-119
• Feature: Excellent Quality, Fine Finished, High Strength
• Type: Full Gear Coupling
• Thickness: 50-60mm
• Country of Origin: India
• Certififacation: ISI Certified
• Brand Name: KEVYA
• Flexible or Rigid: FLEXIBLE

Gear Couplings belong to the category of flexible couplings that are capable of transmitting very high torques. It is a mechanical device for transmitting torque between two shafts that are not collinear. Constructionally the gear coupling utilizes the advantages of gear engineering; practically the coupling is a complete gear assembly. The gear couplings consists of a forged sleeve with internal teeth cut on its inside. The forged sleeves are normally two halves possessing internal gears in both of them. In certain cases the forged sleeve tends to remain a single piece,Two hubs with external teeth containing the same number of teeth as in the internal gear is present with each one being mounted on the driven and driver shaft respectively. The tooth profile of the external teeth is normally crowned in order to take up more loads,The entire assembly in normally enclosed and is provided with gaskets at the joints and O-rings at vantage points in order to prevent the leakage of the lubricant filled inside the coupling,,Lubrication plugs are provided at vantage points in order to lubricate the couplings during predetermined intervals of time

Geared Couplings, conveyor sprocket wheel, Sprocket Wheels, Shafts, shaft

We bring forth comprehensive Full Gear Couplings for our valuable clients. Our Full Gear Couplings are manufactured from high-grade material and technologically advanced machinery. The demand for these Full Gear Couplings has increased tremendously in the recent times. We provide the Full Gear Coupling at market leading prices. Attributes : SimpleEasy to installLow maintenance Specifications Size Max. Bore mm Pilot Bore mm TORQUE kg.M H.P PER 1000 RPM Load Capacity MAX RPM C WT.With Solid Hubs.Kg. GD2 KG.M Dimensions in mm ABD E F G H M 100 35 10 50 7 8000 4.2 0.03 120 75 50 93 93 15 45 1.5 45 101 50 20 100 14 6300 10 0.14 170 110 65 115 115 17 55 2.5 65 102 60 30 250 35 5000 15 0.2 185 125 85 145 145 17 70 2.5 80 103 75 40 450 63 4000 26 0.48 220 150 105 175 175 20 85 2.5 105 104 90 50 850 119 3350 40 0.95 250 175 130 215 215 20 105 2.5 125 105 110 60 1300 182 2800 62 1.9 290 200 155 230 230 25 110 5 140 106 125 75 2000 280 2500 85 3 320 230 175 260 260 25 125 5 155 107 140 90 3500 490 2100 120 5.25 250 260 205 290 290 25 140 5 175 108 160 105 4500 630 1900 180 8.5 380 290 230 320 320 25 155 5 190 109 180 125 5600 784 1700 210 15 430 330 250 156 340 25 165 5 205 110 220 140 8200 1148 1400 290 30.5 490 390 171 370 370 25 180 5 220

Gear Coupling, chain lock, Fastener, Hand Tool, Pipe Fitting

Gear Coupling, industrial bolt, Industrial Nut, Worm Wheels
