Measurement Gauge Dealers in Odhav, Ahmedabad

We are a leading organization of the domain, engaged in offering an effective array of Fillet Welding Gauge Calibration Service for customers. These offered calibration services are rendered using high-quality support and modern technology. Apart from this, these calibration works are rendered according to the client's desires.

• Range: 1 to 10 TPI. (14 sizes)

This Hard Chrome Plated Guage is used to measure the ACME Threads for setting of cutting tool. This gauge is used to set the quick change gearbox to required number of threads per inch & also to set Compound rest 14.5oto the right. (half the included thread angle.

• Measuring Range: 0 to 300 mm
• Brand: Mitutoyo
• Model: 570-312
• Resolution: 0.01 mm
• Accuracy: 0.002 mm

• Specialties: Perfect strength,Superior functionality,Durability

Portable Coating Thickness Gauge NOVOTEST TP-1 – device for operative non-destructive testing of coating Thickness in accordance with standard ISO 2808 with high measurement accuracy.   Coating Thickness gauge is designed to test : Thickness of various thick protective coatings on various metals and alloys; Thickness of paint and other dielectrics – radioabsorbing, mastic, teflon, plastic, electroplating coatings on steel; Thickness of electroplating and paint coatings on non-ferromagnetic alloys and non-ferrous metals; Thickness of bitumen and other thick coatings on various metals and alloys; As well as relative humidity, air temperature, surface temperature, dew point temperature and difference between surface and dew point temperatures, estimate the depth of grooves and the surface roughness   Electronic Thickness gauge – device which widely used in shipbuilding and automotive industries for measuring the Thickness of paint, in order to test the quality of products, also it used for determining technical condition of the tested objects.   Advantages Large thickness measurement range Convenience and ease in operation Minimum number of controls - one button – one function. Graphical display with backlight Automatic recognition of probe Indication of the connected probe type Control of batteries.

We have manufacture of all types of pressure gauge parts . Like socjet adapter Can u purchase from out side ?? If yes then we have also provide u on best quality with best rate within delivery time period

We have become a notorious manufacturer, supplier and exporter amid industries for delivering the highest quality of the thread ring gauge at the most likable rates. Considerable caution of our team towards accuracy and outlined quality standards are fair reason for the quality our clientele experiencing in our provided thread ring gauge. We make use of the superior quality raw material and proven quality processes in synchronization of the crucial quality standards to achieve the determined quality of the thread ring gauge. The comprehensive gamut of thread ring gauge we provide is hence guaranteed for the conforming to the prevailing quality regulations and delivering remarkable performance spanning various applications.

CONSTRUCTION FEATURES Dial Size : 100mm & 150mm. Accuracy : ±1% of full scale. Case & Bezel (IP-65) : SS 304 Snap Action Bayonet type. Movement : Brass / SS 304. Pressure Element : SS 316 Diaphragm / Compact capsule. Dial : Aluminum white painted with 270 degree black scale marking. Pointer : Al. / Brass, Zero adjustment / Micro Zero Adjustment pointer. Window : Toughened / Safety glass. Over Load Protection : 125% of f.s.d. for ≤ 150 Kg/cm /                                    115% of f.s.d. for > 150 Kg/cm . Mounting : Direct Bottom entry. Scale Range : For Schaffer Diaphragm: 760mmHg Vacuum,Compound, 0.6 to 21 Kg/cm . For Low Pressure Diaphragm : 250mmWc to 6000 mmWc. For Compact Capsule : 250mmWc to 6000mmWc.Upper Chamber Material : SS 304 / Carbon Steel Powder Coated. Diaphragm Material : Brass / SS 316, Teflon Coating can provided if required. Lower Chamber : SS 304 / SS 316, PTFE Lining provide if required.( Threaded / Flange type ). OPTIONAL FEATURES• Economic M.S. Model available on request.• Flanged connection available on request. APPLICATIONMedical & Vacuum Technology, environment &heating engineering, level indication & filter monitoring.

A Coating Thickness Gauge (also referred to as a Paint Meter) is used to measure Dry film thickness. Dry film thickness is probably the most critical measurement in the coatings industry because of its impact on the coating process, quality and cost. Dry film thickness measurements can be used to evaluate a coating’s expected life, the product’s appearance and performance, and ensure compliance with a host of International Standards.

• Range: Vacuum, Compound, 0….1 Kg/cm2 to 0….2100 Kg/cm2
• Configuration: Bourdon Tube
• Shape of Bourdon: ‘C’ Type / Helix Type
• Movement: SS 304

• Features: Sturdiness, Convenient to use, Accurate results
• Item Code: EG-03

• Thickness: less than 0.6 of their nominal size.

we have etched a specialist among the most trusted name in this business engaged with offering a wide range of plug gauge to our important clients. The offered gauge is precisely engineered with the aid of superior quality Steel and high latest technology. Our offered plug gauge is tested on different parameters by our quality controllers as per industry standards. The Plug Gauges are highly used for measuring whole sizes. Available in different size and shapes we customize these plug gauges as per the client’s requirements. Available range:- 3mm to 100mm Features of plug gauge:- High durability Rust resistance

Ultrasonic Thickness Gauge Your reliable worktool for every day: light, easy, precise.a formal quality management system.

• Features: Precise measurement, Precision-designed, Light weight.
• Material: Stainless Steel
• Usage/Application: Industrial
• Brand: Preksha Precision

• Connection Type: NPT
• Dial Size: 10 inch / 250 mm
• Display Type: Analog
• Brand Name: WIKA
• Connection Size: 1/2 inch
• Pressure Range: 0 to 4 bar(0 to 60 psi)
• Country of Origin: Made in India
• Application: Calibration
• Pressure Type: Differential Pressure

• Brand Name: JABEE
• Measuring Range: Upto 7 Bar
• Material: Aluminium
• Connection: Bottom Connection
• Color: Silver
• Country of Origin: Made in India
• Usage/Application: For Ariculture
• Size: 1/4"
• I Deal In: New Only

• Brand Name: INSIZE
• Accuracy: 2μm
• Payment Terms: T/T (Bank Transfer)

• Material: Plastic
• Pressure: 50 Lbs/sq
• Application: Oil Tank
• Type: Transparent Level Gauge
• Brand Name: Laika
• Centre Distance: 3 inch
• Fluid Type: Oil
• Model Name/Number: OLI-3
• Temp: 150 OC
• Thread Length: 13 mm

Supplier & Manufacturer of Pressure Guage. Our Product Range also comprise Hydraulic Gear Pump, Hydraulic Accessories & Controls. We are engaged in offering our clients with industrial Pressure Gauge that are available at affordable prices.

we are one of the leading organization is manufacturing and supplying snap gauge in India. These are made as per the norms of International Standard while using superior quality steel alloys and various advanced technology. It’s widely used in various grade components so as to ensure its longer services life and excellent operational accuracy. This gauge is widely used for measuring purpose. We offer these gauge in diverse designs and sizes at market leading prices.

Tank Level Gauges Description : Fluid Tech Hydraulics is one of the leading manufacturer of Tank Mountain Strainer (either suction or return) can be installed through a tank top by welding a standard bell reducer (coupling) over a hole cut in the top. A standpipe, threaded into the coupling, need be only long enough to stay below the lowest fluid level encountered .The strainer may be removed for servicing without draining the tank. tank-mounted strainers and diffusers install through the side wall, or through the hole in which they are mounted, and access to the tank interior is three styles: for suction straining, return –line straining, or return-line diffusion.

• Type: Transparent Level Gauge
• Application: Oil Tank
• Material: Aluminium
• Centre Distance: 3 inch
• Fluid Type: Oil
• Thread Size: 3/8inch

• Shape: Round

The Tipping Bucket Rain Gauge is used for measuring the rainfall. The Weather Station Tipping Bucket Rain Gauge consists of twin buckets built up on a horizontal shaft. The mechanism of the Tipping Bucket Rain Gauge involves sophisticated technology to ensure efficient working. The facility of leveling the bucket and proper calibration makes it an operation-friendly one. We are, that’s why, among the prominent Manufacturers of Tipping Bucket Rain Gauge.

• Country of Origin: India
• Material: Stainless Steel
• Shape: Round
• Display Type: Digital
• Operating Mode: Automatic
• Packaging Type: Corrugated Boxes

• Material: Metal
• Application: Measuring Object Height
• Certification: ISI Certified
• Display Type: LCD
• Automatic Grade: Automatic
• Display: 7"
• Screen Type: Touch Screen
• Warranty: 1 year

FEATURES : State-of-the-art multi functional measuring system with a touch screen colour LCD display, 7", featuring an intuitive, fast and ease-of-use alphanumeric and graphic readout to process measurements and advanced geometrical calculations. Carriage for motorized vertical displacement. Fast sliding movements on air bearings allowing greater accuracy and reliability. Constant minimized measuring force with consequent optimization of the measurements performed by means of extended probes. Automatic stand-by for energy saving. USB/ LAN port to import or export data and measuring programs. Automatic software updates via USB Pendrive. R5232 port for connection to printer or other external devices. Calibration master piece including 5 mm gauge block as standard supply.FUNCTIONS : Automatic processing of 10 and ZD measurements. Calculation of tolerances of the performed measurements. Extensive statistical evaluations with automatic storage of the detected values. One key function to start measurement procedures automatically. Self-learning of measuring sequences, creation, storage and recall of measuring programs. Possibility to set an unlimited number of reference points on the workpiece. Perpendicularity and straightness measurements by means of the optional kit code 404-A. System software and operational menus available in various languages. Automatic temperature compensation. Automatic compensation of the measurements performed either in floating or static mode. Non-linear error compensation (SLEC) and angular deviation. Probe flexion error compensation.
