Mehta Cad Cam Systems Pvt. Ltd. Sarkhej, Ahmedabad, Gujarat

Features: industrial y structure frame constructed with industrial y frame and structure, the machine is heavy duty and built to last. industrial servo motor a high performance of industrial servo motor provides excellent control of the movement of the shuttle. ricoh gh2220 printhead latest ricoh development of industrial gh2220 printhead makes continuous printing at ultra-high quality and delivers excellent cost performance. negative pressure system negative pressure system ink supply with digital control pressure display gauges ensures high-quality printing at higher possible firing frequency, hence increasing speed and stability. anti crush system anti crush device give signal to stop movement of carriage printing if any obstacles or object come in the way and protect the head from crush hazard. vacuum bed technical specifications model rj 455 v print head 4 ricoh gh2220 industrial printhead structure industrial structure frame with heavy duty y-bar x & y motor high quality servo motor maximum print size 45cm[w] x 50cm[l] printing resolution 720x600 dpi, 1200x900 dpi printing direction uni and bi-direction printing technology variable dot printing [grey scale printing] media table size 46cm[w] x 75cm[l] max. Thickness 15 cm with infrared sensor protection weight 15kgs ink type uv led curable inks ink colour c.m.y.k. White[standard], varnish[optional] ink capacity 500ml bottle ink supply system negative pressure system [nps] with automatic ink supply uv technology 1 x 6 -8w uv led lamp rip photoprint[bundel version] colorgate[optional] interace usb 2.0 3.0 power requirements 100-110 volt 220-240v, 5060hz dimension (wxhxd) 128cm x 65cm x 75 cm net weight 125 kg

Brand Name : Mehta

Highlight Features Ricoh GH2220 Printheads Latest Ricoh development of industrial GH2220 printhead makes continuous printing at altra-high quality and delivers excellent cost performance. Vacuum System The vacuum bed holds media steady to ensure stable printing. The vacuum system can be turned ONOFF easily from the control panel by a button. Mechanical Material Alignment System Mechanical alignment point allows accurate and consistent media placement. Negative Pressure System Negative pressure system with digital control pressure display gauges ensures high-quality printing at higher possible firing frequency, hence increasing printing speed and stability. White Ink Circulation System Keeps color particulates in motion to improve stability and dispersions of the pigments in the fluid reservoir and ink path. Low Ink Volume Reminding System When the ink volume is low, the alarm will light up and beep. Technical Specifications Print Head : 6 Ricoh GH2220 Industrial Printhead Structure : Industrial Structure Frame With Heavy Duty Y-Bar X & Y Motor : High Quality servo Motor Maximum Print Size : 100cm (W) x 160cm (L) Printing Resolution : 720x900 dpi, 720x1200 dpi Printing Direction : Uni and Bi-Direction Printing Technology : Variable Dot Printing [Grey scale printing] Media Table Size : 105cm[W] x 165cm[L] Max. Thickness : 75 mm with infrared sensor protection Weight : 50kgs Ink Type : UV LED curable Inks Ink Colour : C.M.Y.K. White[standard], varnish[optional] Ink capacity : 1000ml Bottle Ink Supply System : Negative pressure system [NPS] with automatic ink supply UV Technology : Dual UV LED lamp RIP : ColorGate Interace : USB 2.0 3.0 Power requirements : 100-110 volt 220-240V, 5060Hz Dimension (WxHxD) : 215cm x 222cm x 114 cm Net Weight : 450 kg Printing Speed Resolution : 72

Brand Name : Mehta

Performance and Features of PLASMA Cutting Machine • Widey used for cutting of S.S., M.S., Galvanized sheet etc. • Being used World Leader in Plasma Source – Hypertherm • Automatic Torch height adjustment system that helps to increase the life of consumables and improves cutting quality Technical Specifications Processing Material : Iron, Stainless steel plate, Aluminium, Galvanised sheets, Galvanised sheets, Titanium plate, M.S. plate Plasma Source : Powermax 45 Drive System : X, Y axis – Rack and Pinion , Z axis- Ball screw Maximum Traveling Speed : 20 mmin Control System : 7” display with high resolution, industrial ARM7 processor chip , 2 axis controller, Storage capacity- 32 MB Output Power : 20 to 45 A Torch Height Controller : THC system included for accurate torch height maintanence Input Voltage : 3 Phase 420V AC, 5060Hz Air System : Clean ,Dry and Oil Free Applications: Cutting of stainless steel, Aluminium, Iron, Galvanised sheet, Titanium plate, M.S. plate for signs, architectual components, fabrication units, etc.

Brand Name : Mehta

Material : Stainless Steel

Brand Name : Mehta

Voltage : 440 V

Features of elita-480 x, y axis adopt round rail and belt transmission to make machine more stable stable and full equipped design concept, equipped with advanced industrial cooling system with anhydrous alarm automatic protection system, improve the stability and safety of continuous work. Full-equipped dust, anti pollution exhaust system, more attention to environmental protection. Perfectly cutting material • 30 mm acrylic • 10 mm mdf technical specifications of elita-480 model : libra-480 laser tube : 60, 80 , 100, 130, 150, 180 watt power working area : 4 x 8 feet laser type : co2, sealed laser tube, wavelength 10.6um cooling system : water cooling power adjustment : 0-100% stepless control, 0-100% adjustable in software control and driving : high speed dsp control, stepper motor high subdivide driving engraving speed : 0-70000 mmmin cutting speed : 0-18000 mmmin working voltage : ac220v110v ±10% 50hz60hz position accuracy : ≤± 0.01mm consuming power : ≤ 2000 w running environment temperature : 0-45°c. Humidity : 5%-95% (free of condensed water) supported format : plt, dst, dxf, bmp, ai. Support autocad, coreldraw output directly applications: acrylic engraving, acrylic cutting, paper cutting, mdf cutting, and more.

Brand Name : Mehta

Features: • special design of carriage where 2" lens or 5" lens both can be used. 5" lens gives you better quality of cutting, if the thickness of material is more than 10mm and 2" lens should be used for cutting media less than 10mm thickness. • high quality touch panel display - very easy to use • pass through design for long length of work piece in y-axis direction • machine is provided with foot-mounting legs so that there is no vibration in machine and machine can be adjusted on zero level • as it is made in india, no waiting period for spare parts & quick service support • machine is provided with heavy duty compressor which has air-assist combining adjustable focus systems in coaxial jet air to prevent cutting edge from burning down • laser cut software with window based software enhance cutting speed and angel curve performance • laser seals the edges of fabric while cutting • maximum cutting thickness of acrylic - 20mm • high quality of chiller unit for better performance and long life of laser tube technical specifications of elita 43: x, y cutting area : 4' x 3' (1220 x 918 mm) laser power : 80w travelling speed : 0.1 to 400 mms reposition accuracy : ±0.025mm minimum letter size : 1 mm (english font) x y movement system : linear guide way z - axis movement : manual power adjustment : 0.1 to 100% maximum cutting thickness : up to 20mm acrylic driving system : stepper motor operating system windows xp, windows 7 32bit interface : usb interface supported format : plt, ai, dxf, bmp working voltage : single phase 220v50hz (require earthing) running environment : 45°c, humidity 5% - 80% operating display : touch panel memory buffer : 100 mb (max. 33 files) overall dimension : 1525 x 1920 x 1100 mm weight : 332 kg power consumption : 2 kw

Brand Name : Mehta

Features of elita-21 elita 21 is with high speed usb and offline control system, the split frame structure, working is stable and reliable, it has wide range of application and economical � utility model. Elita 21 is of high accuracy, fast, stable performance, simple operation and easy maintenance. Elita 21 can engrave and cut variety of non-metallic materials like acrylic, mdf, paper, fabric, leather etc. Elita 21 is best for letter cutting, trophy and awards, plaques, gifts, photo album cover etc. technical specifications of elita-21: model elita-21 working area 600 x 400 mm laser type sealed-off glass co2 laser wavelength : 10.6um laser power 60 w laser tube cooling water cooling control system and driver high speed dsp control system, stepper motor, high sub division driver engraving speed 0-900 mms cutting speed 0-400 mms reposition accuracy

Brand Name : Mehta

Features of elita 32 â�¢ special design of carriage where 2" lens or 5" lens both can be used. 5" lens gives you better quality of cutting, if the thickness of material is more than 10mm and 2" lens should be used for cutting media less than 10mm thickness. Â�¢ high quality touch panel display - very easy to use â�¢ pass through design for long length of work piece in y-axis direction â�¢ machine is provided with foot-mounting legs so that there is no vibration in machine and machine can be adjusted on zero level â�¢ as it is made in india, no waiting period for spare parts & quick service support â�¢ machine is provided with heavy duty compressor which has air-assist combining adjustable focus systems in coaxial jet air to prevent cutting edge from burning down â�¢ laser cut software with window based software enhance cutting speed and angel curve performance â�¢ laser seals the edges of fabric while cutting â�¢ maximum cutting thickness of acrylic - 20mm â�¢ high quality of chiller unit for better performance and long life of laser tube technical specifications of elita 32 x, y cutting area : 3' x 2' (918 x 610 mm) laser power : 80w travelling speed : 0.1 to 400 mms reposition accuracy : â±0.025mm minimum letter size : 1 mm (english font) x y movement system : linear guide way z - axis movement : manual power adjustment : 0.1 to 100% maximum cutting thickness : up to 20mm acrylic driving system : stepper motor operating system : windows xp, windows 7 32bit interface : usb interface supported format : plt, ai, dxf, bmp working voltage : single phase 220v50hz (require earthing) running environment : 45â°c, humidity 5% - 80% operating display : touch panel memory buffer : 100 mb (max. 33 files) overall dimension : 1200 x 1780 x 1060 mm weight : 243 kg power consumption : 2 kw

Brand Name : Mehta

Voltage : 220V

Features: • 4 axis laser welding • high magnification system • adjustable waveform • uses military grade water tank • imported compressor • pulsed laser power supply • internal microcontroller technical specification model : galaxy:3400a-500w whole power consumption : 12kw laser wavelength: 1064nm laser power : 200w-650w laser point : size>=0.15mm laser type nd : yag repeating frequency : 1- 200hz positioning accuracy : 0.01mm working table : 300*300mm(customization) sight positioning : ccd monitor (standard configuration) four axis : x y z c axis the diameter of rotation axis : 40mm focus lenght : 200mm note: *also available in 250w (1200 x 1200mm working area).

Brand Name : Mehta

Application : Multi-fuction laser welding machine

Features of laser marking machine evan evan laser provides a fast, flexible and efficient way to permanently mark a wide variety of materials such as metals, plastics, ceramics, silicon etc. features • first and last pulse equally useable • bitmap marking compatible. • high repeatabilitystability design. • status monitoring and safe shut down. • high speed marking (mhz repetition rate). • long using time : the average using time more than 100000 hours • good stability and free maintenance : no need to maintenance for laser advice high quality gray scale marking technical specifications of laser marking machine evan 20 model no. : evan-20 laser average output power : 20 w wavelength : 1064 nm power adjustment : 0 to 100 % cooling : air cooled min. Line : width min. 0.03 mm (depend on material) max. Speed : max. 10000 mms (max. Linear speed) marking depth : 0.01~0.3mm (depends on material) min character height : 0.5mm marking range : 145 mm x 145 mm(standard) optional : 175 x 175 mm & 300 x 300 mm supporting format : support plt, dxf, bmp file etc., using shx ttf character storage directly marking area : 145 x 145 (standard) 175 x 175 300 x 300 (optical) single pulse energy (mj) : 1 to 20khz repetition frequency range : 20-80 khz output power stability : < 3% beam quality(m2 ) : < 1.5 pulse width(ns) : < 130 to 20 khz power supply : dc 24 volt ac 220 volt max power consumption : 200 watt

Brand Name : Mehta

Application : Fast, flexible and efficient way to permanently mark a wide variety of materials such as Metals, Pla

Features of gloria-510f • fscut closed – loop control loop • powerful hardware configuration • cypcut software • start processing immediately without waiting • fast & practical scanning cutting • bcs100 height controller technical specifications of laser engraving machine gloria series model : gloria-510f working area : 4 x 8 feet 5 x 10 feet laser type : imported original fiber laser laser wavelength : 1070 nm laser output power : 300w 500w 750w 1000w 1200w cutting tickness 0.2-5 mm max. Cutting speed : 30000 mmmin (adjustable according to defferent cutting thickness) position accuracy : ≤ ± 0.04 mm minimum line width : ≤ 0.12 mm cooling system : water cooling driving system : mitsubishi yaskawa servo motor and drivers transmission : x axis with imported ball screw, y axis is imported square rail working voltage : 380v 220v total power consumed : 9 kw

Performance and features of lx 1325 cnc router â�¢ 25 mm linear guidways for high positional accuracy and long life with high motion accuracy. Â�¢ original italian spindle gives you very stable, trouble-free, maintenance-free performance for long period of time. Â�¢ fast speed and high accuracy ensured by gear transmission equipped on cnc router. Â�¢ high accuracy and heavy workload ensured by imported square rail. Â�¢ periodic lubrication maintenance provided by automatic lubrication system. Â�¢ axis drive system : x, y - rack, z-ball screw. Â�¢ working table is covered with rigid pvc sheet for long life of aluminum t slot table. technical specifications models lx - 1325 outer dimension : 2002 x 3150 x 1541 mm working area (x, y, z) 1300 x 2500 x 200 mm spindle 6 kw air cooled (hsd italian) spindle speed 18000 rpm distance between bed and gentry 200 mm maximum traveling speed 20 mtrmin cutting tool diameter ã�3 to ã�20 mm repeated location 0.025 mm operating system dsp - hand held controller driving system stepper motor weight 875 kg power supply ac 420v3ph applications: acrylic, wood, acp, brass, aluminium, foam board, mdf, etc.

Performance and features of lx 1212 cnc router â�¢ 25 mm linear guideways for high positional accuracy and long life with high motion accuracy. Â�¢ original italian spindle gives you very stable, trouble-free, maintenance-free performance for long period of time. Â�¢ fast speed and high accuracy ensured by gear transmission equipped on cnc router. Â�¢ high accuracy and heavy workload ensured by imported square rail. Â�¢ periodic lubrication maintenance provided by automatic lubrication system. Â�¢ axis drive system : x, y - rack, z-ball screw. Â�¢ working table is covered with rigid pvc sheet for long life of aluminum t slot table. technical specifications outer dimension : 1902 x 1750 x 1541 mm working area (x, y, z) : 1200 x 1200 x 200 mm spindle : 3 kw air cooled (hsd italian) spindle speed : 18000 rpm distance between bed and gentry : 200 mm maximum traveling speed : 20 mtrmin cutting tool diameter : ã�3 to ã�14 mm repeated location : 0.025 mm operating system : dsp - hand held controller driving system : stepper motor weight : 650 kg power supply ac : 230v1ph applications: acrylic, wood, acp, brass, aluminium, foam board, mdf, etc.

Performance and features of gx 1325 cnc router • heavy duty frame structure • x, y and axis are driven by ac servo motor (japan) which gives more accuracy and speed than our lx series and rx series cnc routers • high positional accuracy, heavy work load and long life is ensured by hiwin brand 30 mm square linear guidways. • original italian spindle gives you very stable, trouble-free, maintenance-free performance for long period of time. • fast speed and high accuracy ensured by gear transmission equipped on cnc router. • periodic lubrication maintenance provided by automatic lubrication system which gives long life to mechanical parts. • if any electronic part get damaged during running operation, auto stop mode function stops the machine and so the tool or material doesn't get damaged. • axis drive system : x, y - rack. Z - ball screw. • working table is covered with rigid pvc sheet for long life of aluminum t slot table. technical specifications model : gx - 1325 outer dimension : 2161 x 3160 x 1000 mm working area (x, y, z) : 1300 x 2500 x 250 mm spindle : 6 kw air cooled (hsd italian) spindle speed : 18000 rpm maximum traveling speed : 30 mtrmin cutting tool diameter : ø3 to ø20 mm x and y axis traveling : rack & pinion (made in taiwan) table structure : heavy duty rigid mild steel frame structure repeated location : 0.020 mm operating system : high speed pci base controller driving system : ac servo motor (japan) weight : 1260 kg power supply : ac 440v3ph applications: heavy duty application, high speed, like wooden industries, high speed 3d carving, flush door manufacturing, etc.

Performance and features of stona 1325 ã¢ï¿½â¢ profiled steel welded lathe bed, stabilizing treated under artificial prescription ensures minimum distortion, excellent rigidity and vigorous strength. â�⢠precise travelling of y axis driven by double motors ensures stable performance of machine. â�⢠high precision rack transmission ensures high accuracy, fast speed and strong power. â�⢠imported square linear guide rail ã¢ï¿½â¢ best mechanical and electrical design ã¢ï¿½â¢ dust proof design ã¢ï¿½â¢ filtration system technical specifications model : stona 1325 outer dimension(w*l*h) : 2365*3630*1575 mm machining area : 1300*2500 mm spindle : 5.5 kw (water cooled spindle) spindle rpm : 24000 max z max. Running : 15 mmin distance between bed and gentry : 200 mm cutting tool diameter : ã��3, ã��4, ã��6, ã��8, ã��10 repeated location : 0.025 mm max running speed : 15mmin weight : 1075 kg power supply : ac 420v 50hz applicaions: 2d & 3d engraving on granite, marble, soft & hard stones etc.

Overview of cnc engraving machine me 3030 me-3030 is a new cnc engraving machine developed for small moulds and metal engraving. The machine has a double column design, imported liner guide and ball screw. It is small, fast, sturdy and accurate. Me-3030 has nc studio controller and it is easy to operate and easy to learn. You can see the simulation before start program. If there is a power failure, or tool breakage, the machine can remember the starting point. The machine gives very low priceperformance ratio and can be used broad range of applications. technical specifications model : me-3030 outer dimension(w x l x h) : 780 x 950 x 1550 mm machining area : 300 x 300 mm spindle : 2.2 kw (water cooled) spindle rpm :18000 max z max. Traveling : 100 mm distance between bed and gentry : 100 mm cutting tool diameter : ã�3,ã�4,ã�6,ã�8 repeated location : 0.005 mm max running speed : 7 mmin weight : 375 kg power supply ac : 320v 50hz applications: engraving for small moulds and metals.

Brand Name : Mehta

Application : Engraving for Small moulds and metals.

Performance and Features of GX 1530 CNC Router • Heavy duty frame structure • X, Y and axis are driven by AC SERVO motor (JAPAN) • HIWIN brand 30 mm square linear guidways. • Original italian spindle • Gear transmission equipped on CNC router. • Automatic Lubrication System • Auto Stop Mode Function • Axis drive system : X, Y - Rack. Z - Ball Screw. • Working table covered with rigid PVC sheet for long life of aluminum T slot table. Technical specifications Model: GX - 1530 V ATC Outer Dimension : 3065 x 3660 x 3683 mm Working Area (X, Y, Z) : 1500 x 3000 x 300 mm Spindle: 7.5 KW (Optional 10kw & 12 kw) (HSD Italian) Spindle Speed : 24000 RPM Maximum Traveling Speed: 45 mtrmin Automatic Tool Changer: BT30 ISO30, 8 Positions Material Holding : Vacuum Combined T-slot Weight : 2500 Kg Power Supply : AC 440V3PH Applications: Heavy duty application, high speed, like wooden industries, high speed 3D carving, flush door manufacturing, etc.

Features of erina 100 • based on laser tube beam design, this system direct accept the beam of laser tube, without the beam expander, highly improves the optical light transmittance. Technical specifications of erina 100 laser power :100 w (rf metal laser tube usa) water cooled laser energy regulator: 0 to 100% field size (mm) :300 x 300 400 x 400 450 x 450 500 x 500 600x 600 working distance (mm): 350 450 500 550 660 speed :5000 mmsec motion control: 3 axis dynamic galvano system meter system graphic format supported: ai, bmp, jpg, plt, dfx, dst, dwg power supply ac 220 v ± 5% 50 hz 60 hz working environment 15 ° c - 30 °, humidity : 30-80%

Performance and Features of GX 1530 CNC Router • Heavy duty frame structure • X, Y and axis are driven by AC SERVO motor (JAPAN) • HIWIN brand 30 mm square linear guidways. • Original italian spindle • Gear transmission equipped on CNC router. • Automatic Lubrication System • Auto Stop Mode Function • Axis drive system : X, Y - Rack. Z - Ball Screw. • Working table covered with rigid PVC sheet for long life of aluminum T slot table. Technical specifications Model: GX - 1530 V ATC Outer Dimension : 3065 x 3660 x 3683 mm Working Area (X, Y, Z) : 1500 x 3000 x 300 mm Spindle: 7.5 KW (Optional 10kw & 12 kw) (HSD Italian) Spindle Speed : 24000 RPM Maximum Traveling Speed: 45 mtrmin Automatic Tool Changer: BT30 ISO30, 8 Positions Material Holding : Vacuum Combined T-slot Weight : 2500 Kg Power Supply : AC 440V3PH Applications: Heavy duty application, high speed, like wooden industries, high speed 3D carving, flush door manufacturing, etc.
