Monoblock Filling Machine Dealers in Ahmedabad

The incoming dry bottle sterilized is fed through the in feed Turn Table with suitably guided on the moving Delran flat conveyor belt at the required speed for feeding. There is one filling head mounted on machine top plate in the same line. When bottle reaches to the first filling station, it will be held by the pneumatic bottle holder. Immediately it will be sensed by the bottle sensor as soon as it gets signals from sensor magnetic clutch starts to rotate which is mounted on auger shaft. It will fill the desired amount of powder to the bottle through auger, where rotation time is previously saved in PLC control. After filling of first bottle pneumatic piston goes back and release the first bottle to move on conveyor, by the same time second bottle also moves along with the first bottle in empty condition. The main advantage of this machine is Pneumatic bottle holding system is directly connected with Auger rotation, so till bottle get filled with powder as per set value pneumatic system will not going to release the bottle.

• Brand Name: Ashirwad
• Material: Stainless Steel
• Driven Type: Up Down
• Condition: New
• Automatic Grade: Automatic
• Pressure: Low Pressure, High Pressure
• Usage: Bottle Water, Soft Drink
• Voltage: 110V
• Packaging Type: Carton Box, Wooden Box, Metal Sheet Box
• Specialities: Rust Proof, Long Life, High Performance, Easy To Operate
• Capacity: 30-40 BPM
• Type: Filling Machine
• Country of Origin: India
• Phase: Single Phase
• Corrosion Resistance: No
• Warranty: 1 Year
• Weight: 1000-1500kg
• No. of Heads: 4 - 6 -8 Head
• Fill Size: 100ml to 1000ml. with the Help of Change Parts
• Machine Speed: 30-40 BPM
• No. of Nozzles: 2-4-6-8 Head
• Air Consumption: 4 kg/cm2
• Output: 220 bottles per minute

• Brand Name: salvin
• Driven Type: Pneumatic
• Condition: New
• Automatic Grade: Fully Automatic

The Mono Block Liquid Filling-Capping Machine is an integrated, compact system designed for the simultaneous filling and capping of liquid products. This machine combines both processes into a single unit, streamlining production and reducing the need for separate equipment. It is equipped with precise filling mechanisms and automatic capping stations, ensuring accurate fill volumes and secure closures. Ideal for industries such as food and beverage, pharmaceuticals, and cosmetics, the Mono Block Machine enhances efficiency, minimizes handling, and maintains high-quality standards in packaging operations

• Country of Origin: India
• Voltage: 220V
• Automatic Grade: Automatic
• Driven Type: Electric
• Finishing: Polished
• Main Machine: 1.5 HP / 415 V / 50 Hz
• Height of Conveyor: 910 mm to 960 Adjustable

• Height: 3.5 Feet
• Length: 12 Feet

Drink Filling Machine combines washing, filling and rotary capping function in one unit, it is a fully automatic and high effeciency liquid packing equipment. It is suitable for packing beverage containing gas. All parts, for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. So it conforms to the requirements of food sanitation. Sealing parts are made of heat-proofing rubber, in order to

Description :Automatic Bottle and Vial filling capping machine is suitable for chemical, food, beverages, cosmetics and pharmaceutical application. It has an SS elegantly matt finished body and rigid vibration free construction for trouble free performance. In this machine 4 head filling unit and 1 head capping unit synchronized with AC variable drive system    Features • No container, filling machine stop system.• No caps in chute machine stop system.• Any bottle fixing in star plate, machine stop system.• Mechanically stopper for bottle holding at filling point• Minimum change over time, from one size to another size of container or fill size.• Branded makes AC variable drive and electric motors.• Contact parts are in SS 316.   Technical specification • Output – 20 to 40 bottle per minute.• Power – 1 hp 3 phase in filling head, 1 hp 3 phase in capping head, 5 amp in vibratory coil and 0.25 hp in conveyor drive.• Bottle dia – 22 mm to 70 mm.• Fill size – 10 ml to 500 ml with the help of different size of syringes and star plate for bottle dia.• Accuracy - + / - 1% on single dose.

• Driven Type: Electric
• Certification: ISO 9001 2015
• Type: Filling Machine
• Voltage: 220V/380V
• Packaging Type: Bottles
• Condition: New
• Brand Name: Adinath
• Port: Mumbai
• Packaging Details: Product & transport worthy wooden packing
• Packaging Material: Glass, Plastic
• Application: Beverage, Food, Medical
• Supply Ability: 5 Unit/Units per Month
• Model Number: ALCFM-60

• Conveyor Height: 800 mm ± 50 mm (Adjustable)
• Container Height:: 210 mm Maximum

We are one of the leading Manufacturers and Exporters Monoblock Filling Machine. FEATURES No Contamination as immediate sealing of filled bottles. Accuracy ± 1% due to piston dozing principle. Centralized Volume Adjustment System. Placing of Cap Feeder Outside Monoblock-avoid entering of dust in it. No Bottle No Fill for Individual head, hence no spillages.

We are one of the leading manufacturer and supplier of monoblock filling machine.

ompact GMP model.     “No Bottle - No Filling” system.     Single Operator for two operations.     All contact parts made of AISI SS 316 material with easy removal system for easy cleaning.     Machine construction in AISI SS 304 material.     Infeed turn table for automatic feeding of bottles.     Diving Nozzle for Foam free filling.     Very High Fill Accuracy.     Automatic In-feed and Exit of Bottles.     Minimum Change Over time.     Variable AC frequency drive for speed adjustment.     Digital bottle counter for counting production output.

Monoblock -Rotary Dry Syrup Powder Filling & Sealing Machine Application & Process : Automatic monoblock type dry syrup powder filling & sealing Machine is works on vacuum principle with rotary star wheel & piston assembly & Rotary funnel head. It is used to fills dry syrup powder in bottle in pharmaceuticals, foods, and dairy and agro chemicals industries. Automatic monoblock rotary dry syrup filling cum sealing machine is versatile, self-supported on stainless steel structures. The machine is precision built with conveyor, rotary star wheel with funnel head with Powder filing head & piston for filling and rotary capping head. Machine basic works on vacuum principle with rotary motion. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body. Main drive of the machine, conveyor drive, rotary star wheel, Powder filling head, cap-feeding bowl, cap sealing head & drive gear motors with synchronized variable Drive and No container No filling & No cap No Sealing system arrangement. Containers are feeds from air jet cleaning machine or unscrambler and moves on SS Slat conveyor at desire speed, feeds below the funnels through feed worm & in-let star wheel with 16 station funnels. The powder filling head is mounted from centre pipe, which gives flexibility to adjust position of wheel and to be sets weight by adjust piston working. Powder is fill in hopper and agitator in hopper is fills powder in rotary filling head with consistency and uniformly. Powder wheel is consist of piston in each feeding head and vacuum plate at behind of powder wheel, which is fitted with zero clearance so, powder is fill in head by suction of vacuum and fill weight can be adjustable by piston working. After that powder head is indexing further and there is closed powder scrapper to scraps excess powder. The vacuum is remaining in head till filled head reaches in vertical position to drop powder in funnel by help of compressed air, sterilized low pressure air or nitrogen gas sequentially flushes so powder comes out from port of powder wheel and fill in to funnel. Funnels are mounted on rotary plate with aligned to bottles mouth and moves on star wheel assembly with up and down plate form to tight fit connect with funnel for filling. After filling star wheel bringing the bottles below the sealing head in the subsequent indexing part, mean while the bottle pickup a cap from the delivery chute of cap feeding bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of threading & sealing and move container further process for inspection, labeling or packing. Salient Features : Designed as per cGMP - Current Good Manufacturing Practices compliance All contact parts AISI 316 & non contact parts AISI 304. Dry Syrup Powder Filling & sealing on single machine. Machine can handle 15 ml to 125 ml bottle with 22 to 25 mm cap size by change parts. To avoid contamination due to immediate sealing of filled bottle. Easily adjustable filing volume in powder wheel. Vacuum pump is incorporate with machine No bottle - No fill and No cap - No sealing for Individual head. Acrylic cabinet with aluminum section supports. Outside cap feeder system as per cGMP norms. Minimum and maximum level of cap in chute to be maintain through sensor hence to avoid damage & rubbing of cap. Powder level sensor to maintain automatically minimum & maximum level in hopper, Inching system provide for setting of filling & sealing operation. Machine structure is covered with s.s.304. Dust collector system can be supply with machine. Synchronized variable speed for conveyor, star wheel, powder feed wheel and sealing head. Rigid gear drives with motor.

• Bottle Dimension: Min. Dia. 25 mm X Min. Ht. 38 mm Max. Dia. 100 mm X Max. Ht. 200 mm

Containers moving on SS Slat conveyor, feed below the filling nozzles through feed worm & in-let star wheel, Filling station consist of volumetric filling head and a central rotating liquid reservoir tank. This reservoir tank fed continuously with the liquid by external source. In-feed liquid controlled automatically by sensing the liquid level in the reservoir tank with the help of floating level switch to actuate pneumatically operated solenoid valve. Fill volume adjustment can be done by a screw, which changes the volume of all the syringes simultaneously. Fine adjustment of individual syringe is possible with the help of mechanism provided on top of the individual syringe.

• Machine can fill: 10 grams to 50 grams

SHPF-100 Automatic Monoblock Dry Syrup Powder Filling Cap Sealing Machine is a Compact machine used for filling and sealing of Dry Syrup in bottles. The incoming dry container (sterilized and siliconised) are fed through the infeed Turn Table with suitably guided on the moving delrin flat conveyor belt at the required speed for feeding to the feed worm for correct spacing between two bottles and get enter into the infeed starwheel, which will be transferred below funnel, 16 nos. of funnel is mounted on round plate and powder filling head is mounted from centre pipe, which gives the flexibility to adjust position of wheel as per requirements and consumes less space on machine. Machine will be having a lifter assembly on base of bottom plate, when bottle come below funnel, bottom platform will lift the bottle and insert the bottle tight fit inside funnel. The sterilized powder is stored in to powder hopper is agitated by pair of mechanical agitators for maintaining consistency and uniform bulk density, powder wheel rotates at the pre-determined speed below the powder hopper with practically no clearance. Powder wheel consist of Piston in each port and behind the powder wheel and vacuum plate is provided there is no clearance between powder wheel and avacuum plate due to back spring pressure. Precise volume of powder is sucked in to the port of powder wheel during vacuum according to the piston length different fill size can be achieved.

• Dimensions: 2510 MM (L) x 1200 MM (W) x 2160 MM (H).
• Net weight: 1700 Kgs. (Approx).

High Production Capacity in High Filling Quantity also, M.S Frame structure duly power coated and covered with S.S. Sheet, Machine can handle bottle size from 15ml to 125ml and Cap size of 22mm, 25mm & 28mm (with help of Change parts).�NO BOTTLE, NO FILL� system eliminates wastage of costly powder, Dust Collection System. All Assemblies under top plate are positioned as for easy cleaning or maintenance, Machine speed can be adjusted through A.C. Frequency drive, which is time saving.

In Case You Want To Save Footprint By Making A Monoblock Machine Of "Screw Capping Machine" And "ROPP Capping Machine". Please Refer To The Links For More Information, Feel Free To Write Us In Case Of Any Queries.

• Driven Type: Pneumatic
• Condition: New
• Automatic Grade: Automatic

Salvin Industries is offering world Class Equipment with German technology for Bulk Drugs, Cosmetics & Food , Pharmaceuticals, Chemicals Industries machinery is an added advantage of automatic processing & packaging machineries for Dairy , Distilleries & pesticides , Cosmetics & Breweries etc.  Apart from this, the company also manufacturers automatic machines for Lube & toiletries packaging, Food & Edible oil packaging machineries.
