PVC Cable Dealers in Navrangpura, Ahmedabad

PVC Insulated & Sheathed Three Core Flat Cables as per IS 69490 are used to connect submersible pump motor with supply lines, these cables are made keeping in mind the severe operating conditions. The slot available in the tube well being narrow the shape of the cables has to be suited for such an application.

.1 kV, 1 cores AL CU conductor, PVC insulated, unarmoured cables as per IS 1554 Part – 1. Conductor : AL up to 10 Sq. mm conductor are solid Cl.1 as per IS 8130. And above 10 Sq. mm conductor are stranded round or compact Cl. 2 as per IS 8130 In CU 4 & 6 Sq. mm conductor are solid Cl.1 or stranded Cl. 2 as per IS 8130. 10 Sq. mm & above stranded round or stranded compact Cl. 2 as per IS 8130 Insulation : PVC Type – A, as per IS 5831. (Option : HR PVC Type – C, as per IS 5831) Core Color : Red or yellow or blue or black or natural Outer Sheath : PVC Type ST-1 as per IS 5831. (Option : PVC Type – ST 2 as per IS 5831 FR Type FRLS Type ) Cable Color : Black (Options : Any other color as per requirement)

* Heavy duty performance. * Offers the best combination of safety, efficiency and economy. * Sheath : PVC, HR, FR, FRLS 105º C PVC * Range : 1.5 to 2.50 sqmm upto 24 cores control cables * 1.5 to 35.0 sqmm upto 5 cores power cables

Pvc Insulated Power Cables, xlpe insulated cables, PVC Insulated Cables

PVC Power Cables, controls cables, Instrumentation Cables

PVC Power Cables, Instrumentation Cables, Lt Control Cables
