Ropp Cap Sealing Machine Dealers in Ahmedabad

• Phase: Single Phase
• Model: SBCS-40R
• Machine Name: Semi Automatic Single ROPP Head Caps Sealing Machines
• Production Speed Per Hour: 480 to 600 Bottles per Hour (Speed Depends up on the size of caps & bottles).
• Capping Unit: Roll Over Pilfer Proof capper designed to thread and seal aluminum cap
• Caps Feeding: Manually on bottle
• Caps Hammering: Pneumatic System
• Machine Motion: Rotary Motion -Index Based
• Suitable for Products: PET / Glass/Aluminum/ HDPE Bottle
• Suitable for Products: Plastic, HDPE, PP Cap
• Application: To Tight & Seal the Caps on Bottles
• Up-Down Movement: Mechanical (Cam System)
• Machine Weight: Approx 250 Kgs
• Machine Dimension: Approx 610mm (L) x 610mm (W) x 1525mm (H)
• Machine main frame: Square Pipe, Stainless Steel 304
• Machine Coverings: Complete in Stainless Steel 304
• Product Contact Parts: Stainless Steel 304
• Non Contact Parts: Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
• Bearings: SKF / Nachi / Timken
• Plating(Wherever Applicable): ENP / Zinc / Hard Chrome / Blackening
• Capping Unit: Stainless Steel .304
• Capping Head Pillar: Mild Steel with ENP / Hard Chrome
• Capping Head Motor Make: 1 H.P Bonfiglioli
• Capping Head Gear Box Make: Bonfiglioli Ratio: 20:1
• Capping Head VFD Make: 1 H.P Delta
• Sensor Make: Sick / Leuze / Panasonic
• Proxy: Autonix / Pulset
• “No Cap in Shute Elevator Stop” Sensor (If machine is with Elevator): Panasonic
• Electrical Wiring: Ferrule Numbering on all the wires with Proper Markings
• Electrical Components: ABB / Delta /Spectra
• Pneumatics: SMC / Festo / Janatics
• Air Pipes: SMC / Festo / Janatics
• Wires & Cables: Labb
• Control Panel: Relay Card (Push Button Type )
• Power: 1 H.P / 230 V.AC
• Compressed Air Required: 3 H.P Compressor (6 bar pressure 0.5 CFM)

• Thickness: 20mm
• Width: 90mm
• Frequency: 50/60 Hz
• Packaging Type: Packet
• Machine Size: 440X390X250mm
• Sealing Length: 10 Inch
• Specialities: Robust, Efficient Performance, Simple Operation, Dimensionally Accurate
• Capacity (Pouch Per Hour): 0-100, 100-200, 200-500 Pouch Per Hour
• Overall Dimension (LXBXH): 490X270X460mm
• Type: Ropp Cap Sealing Machine
• Brand Name: apecs
• Material: Steel
• Shape: Round
• Color: Silver
• Voltage: 220V
• Condition: New
• Finishing: Polished
• Automatic Grade: Automatic
• Driven Type: Mechanical
• Phase: Three Phase
• Warranty: 1 Year
• Country of Origin: India
• Diameter (mm): 50mm
• Net Weight: 100kg
• Usage: Pharmaceutical Industry
• Sealing Power: 0.5 Kw
• Direction Of Movement: left to right

• Warrenty: Other
• Driven Type: Electric
• Voltage: 440 V
• Material: Stainless Steel
• Automation Grade: Automatic
• Capacity: 2000 Bottle Per Hour
• Brand: BE
• Motor: 2 HP

• Automatic Grade: Semi Automatic
• Warranty: 1 Year
• Product Size: 15 mm to 90 mm
• Cap Size: 20 mm/ 22 mm/ 25mm/ 28mm
• Capping Head: ROPP or Screw Cap Head

The quality-driven range of Semi-Automatic ROPP / Screw Cap Sealing Machine comprises the main structure, adjustable height, cap sealing head, bottle holding unit & mains for performing On and Off functions.   Salient Features Sturdy and vibration freedesign Less maintenance Compact design User friendly Durable   Application Cap sealing   Industry Pharmaceutical Chemical Lubricant Cosmetic FMCG Food processing Beverages

• Brand Name: ASHIRVAD
• Model No.: AIASC-40
• Machine Direction: Left to Right.
• Machine Dimension: 1828 mm (L) X 910 mm (W) X 1828 mm (H)
• Production Speed: 40 to 50 Bottles/Minute.
• Capping / Sealing Type: ROPP
• Power Characteristics: 230 Volt, Single Phase, A.C. 50Hz.
• Motor: 1 HP.
• AC Drive: 1 HP Single Phase.

Salient Features: Total cGMP model. Total contact parts are of S.S. 316, and Non Contact Parts are of S.S. 304. Manufactured with latest technology pneumatic based machine. Automatic speed control system. No bottle No Capping system. Elegantly matt finished body. Inbuilt protection against over current, Voltage fluctuation, Short circuit in. Standard in quality & economical in price.

• Certification: ISO 9001:2008
• Condition: New
• Automatic Grade: Automatic
• Driven Type: Electric
• Net Weight: 500 Kgs. (approx).
• Application: Cap Sealing Machine
• Output: 2400 to 3600 Bottle per / Hr
• Power: 1 H. P/1440 Rpm/440v/50hz/3 Phase
• Cap Size: 18mm to 35 Mm.
• Bottles Height: 52mm to 210mm.
• Bottle Dia: 30mm to 75mm.
• Dimension: 1600mm(l) X 750mm(w) X 1800mm(h).
• Conveyor: 700 to 750 Adjustable
• Item Code: Ymmc_201

• Material: Stainless Steel
• Voltage: 440V
• Automatic Grade: Automatic
• Driven Type: Electric
• Frequency: 50/60 Hz
• Phase: Three
• Capacity: 50 bottle per min

• Driven Type: Electric
• Material: MS
• Finishing: Polished
• Condition: New
• Color: Silver
• Automatic Grade: Semi Automatic
• Usage: Industrial Use
• Voltage: 440V
• Type: Ropp Cap Sealing Machine
• Brand Name: RRPM

• Approx Price: Rs 85,000 / Piece

We have parted our infrastructure into several units and one of them is storehouse. We update it on regular basis so as to meet stated industry standards. A famed name, the company is enlisted amidst the well-known Suppliers of Automatic ROPP Cap Sealing Machine.   Features : S.S. Elegantly matt finished body. Simple Design. Easy to operate. Low Power Consumption & Maintenance Free. Range: 22mm cap, 25mm cap, 28mm cap or as per requirement. Speed: 300 to 1500 containers / Hour depending on operator skilled & size of the bottle. Packing Material: Bottles, Jars & container. Rigid vibration free construction for trouble free performance

We are leading manufacturer and exporter of Single Head Ropp Capping Seal Machine and our product is made up of good quality.Single Head Ropp Capping Seal Machineoffered comes designed and developed using latest technology support and comes in precision built structure finish as well as in sturdy welded steel frame for lasting performance. Further, these machines come with feed container for moving on the conveyor belt for smooth operations. Features :  No container no cap arrangement  Low operation noise and power consumption  SS matt finished body  Provide for smooth and noiseless conveying  Provide for suitable resistance against corrosion

The automatic multi head ropp cap sealing machine is built on the welded steel frame enclosed in stainless steel sheet. The height of the machine can be adjusted by the adjustment system. The machine is self supported on stainless steel legs. HOW TO OPERATE : The conveyor belt is used to move the containers. It feeds the containers in to the star wheel through in-feed worm. The containers are set below the sealing head in the subsequent indexing part, by the star wheel. The cap is picked by the bottle from the delivery chute of the cap filling bowl.  The body and neck of the containers are positioned below the rotating head. The sealing head performs the operation of threading and sealing perfectly.   WHICH FEARURES MAKE MACHINE BETTER : The storage capacity of the bowl is increased by the specially designed hopper. For the easy and quick setting of the in-feed worm, the universal coupling is used. The height of the conveyor belt is adjustable to align with other machine of the line. S.S. cladding or hard chrome plating of all exposed parts. For the different container diameter, no need to change the parts. Head movement is by the motor. In built control panel The S.S. matt finished body Self lubricating UHMW-PE guide profile for S.S. slat chain.  No bottle no filing system The bottle height gauge is adjustable for quick setting Noise level and power consumption is very low. The conveyor, star wheel and platform turret contains single synchronized motor    OPTIONAL FEATURES : No cap no container arrangement. Motorized height adjustments system. Acrylic cabinet.   UTILITY REQUIREMENT : Electrical Supply : Three Phase + Neutral + EarthingElectrical Load : 1.5 KW

DESCRIPTION Automatic ROPP cap sealing machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.   SALIENT FEATURES No container no cap arrangement. S.S. elegantly matt finished body. Single motor synchronizes conveyor, star wheel, & platform turret. Adjustable height of conveyor belt, to align with other machine of the line. Sealing pressure can be varied to suit different gauges and size of caps. Specially designed hopper is provided to increase storage capacity of bowl. Low noise level, low power consumptions. Self-lubricating UHMW- PE guide profile for low friction wears surface, smooth and noiseless conveying. Drain tray around the machine platform. SS cladding or hard chrome platting of all exposed parts to ensure long life and resistance against corrosion. Synchronized A/C drives to synchronize, Conveyor, Star wheel and Platform turret & capping bowl. Universal coupling for quick and easy setting of In-feed worm. Adjustable bottle height gauge for easy and quick setting.

• Model Number: DARCS-60
• Out put: Up to 60 / Containers per minute
• Electrical Ratting: I HP, 440 Volts, 3 Phase, 50 Hz.
• ROPP Cap Diameter: 22 mm to 56 mm, with help of change parts
• Container: A) 22 mm to 100 mm (Diameter) B) 50 mm to 210 (Height) option for other bottle height available
• Height of conveyor: 750 mm to 840 mm
• Overall Dimensions: 915 mm (L) X 610 mm (W) X 1300 mm (H)
• Gross Weight in Kgs: 450 Kgs Approx
• Change Parts requirement: A) Container size : Star wheel, Back guides B) Cap size : Pluger, Delivery Chute, Vibratory Bowl (For Two nearest cap size is common can use)

“No Container -No Cap arrangement". Single motor syncronises conveyor, star wheel and platform turret. Adjustable height of conveyor belt. All contact parts are made out of Stainless steel. Sealing pressure can be varied to suit different gauges and size of caps. Specially designed hopper is provided to increase storage capacity of bowl. Low noise level. Low power consumptions. Star wheel is equipped with safety clutch for automatic stoppage of machine in case of jamming over loading.

• Type: Filling Machine
• Packaging Type: Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch
• Voltage: 415 Volts
• Automatic Grade: Semi-Automatic
• Brand Name: Shree Bhagwati Machtech (India) Pvt. Ltd.
• Certification: An ISO 9001 2000 Company
• Weight: 350kg
• Port: India
• After-sales Service Provided: Engineers available to service machinery overseas
• Power: 1 HP
• Dimension(L*W*H): 1800*1000*1500mm
• Supply Ability: 100 Set/Sets per Month
• Cap Sealing Machine: Semi Automatic ROPP Cap Sealing Machine
• Place of Origin: Gujarat, India

The filled containers moving on conveyor belt and fed into an in feed star wheel by in-feed-worm. While moving in feed star wheel , bottles pick up caps one by one from delivery chute. The descending rotary sealing one heads hold bottle's neck with desired pressure   The sealing is done in a programmed roll-on-manner, accurate positioned of the caps is done mechanically by means of a rotating unscramble, to direct the caps correctly into the chute, when the chute is filled up the rotating unscramble drive is disengaged, hence, there is no chance to damage of caps.   The sealing roller takes place due to rotating sealing head and transfer movement of sealing & threading rollers due to sealing cam. The sealed containers are discharged by exist star wheel on conveyor.     Features Very compact, rigid & modular construction. All exposed parts are of S.S304 or hard chrome plated or brass for a corrosion free long life. S.S slat conveyor. S.S Elegantly Matt Finished Body. Vibratory Bowl.

Automatic ROPP Cap Sealing Machine - Single Head Application & Process : Automatic ROPP Cap Sealing Machine is used to sealing bottle in pharmaceuticals, food, dairy, agro chemicals, Beverages industries. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body, consists of, Automatic conveyer belt, Cap feeding unit, Single head capping unit with cam and gear motor drive. Filled bottle is automatic move toward capping head on slat belt and during moving, picks cap from rotating type feeding unit. Capping head is moves up & down with rotation to thread on cap to sealing of bottle and after sealing move bottle for further process on conveyer. Salient Features : Machine designed with cGMP standard. Machine structure is made from S.S.304 Quality with matt finish. Single motor synchronizes conveyor, star wheel, & platform turret. No container No cap system. Sealing pressure can be adjusted for different size of caps and gauges. Low noise level, low power consumptions. Self-lubricating UHMW-PE guide profile for low friction wears surface, smooth and noiseless conveying. Adjustable height of conveyor belt, to align with other machine of the line. Synchronized A/C drives to synchronize, Conveyor, Star wheel and Platform turret & capping bowl. Adjustable bottle height gauge for easy and quick setting.

Ropp Cap Sealing Machine Is Used To Apply The Pilfer Proof ROPP Cap Aluminium Cap On Bottle. It Can Deliver The Output Up To 50 Bottles Per Minute.Our Range Of Multi Head Rotary Ropp Cap Sealing Machine Comes In Various Configuration According To Production Capacity Requirement Like 4 Head Ropp Cap Sealing Machine , 6 Head Ropp Cap Sealing Machine, 8 Head Ropp Cap Sealing Machine ,12 Head Ropp Cap Sealing Machine.

"GMP" Automatic ROPP Cap Sealing Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.
