Rotary Gear Pump Dealers in Odhav, Ahmedabad

• Brand Name: Radial Pumps,Radial Pumps
• Driven Type: Electric
• Pressure: Up To 12 Kg/cm2
• Model Number: RGP Series,RGP Series
• Certification: CE Certified, ISO 9001:2008
• Type: Rotary Gear Pump
• Warranty: 1year
• Pressure: Up to 12 Kg/cm2
• Capacity: Up to 200 M3/hr
• Head: Up to 120 mtr
• Discharge Size: 12 mm to 120 mm
• Temperature: Up to 200°C
• Speed: Up to 1440 rpm

• Country of Origin: India
• Type: Rotary Gear Pump
• Certification: ISO 9001:2008
• Application: Gear System
• Condition: New
• Pressure: 10-20Bar
• Warranty: 1year
• Brand Name: comely
• Fuel: oil
• Material: C.I. / S.G

The Double Helical Rotary Gear Pumps, we offer, are highly demanded in the national as well as international market. Befitted with quality-approved parts and endowed with the latest features, our Double Helical Rotary Gear Pumps are the best option available for the buyers! These Pumps promise high performance and noiseless operation. For bulk orders, contact us. Located in Gujarat (India), we are the well-known Manufacturer, Exporter and Supplier of Double Helical Rotary Gear Pump. Specifications : Series : SGP Series Type : Double Helical Rotary Gear Pump Operating Range : Capacity : up to 40 m3/hr Head : up to 100 mtr Pressure : up to 10 kg/cm2 Size : 12 mm to 100 mm Speed : up to 1450 rpm Temp : up to 200 C M.O.C. : CI, CS, SS304 / 316, SS 304 L/316L, Alloy 20, Hast alloy B or C,CD4MCU, etc. Application : Oil transfer, Oil Ind., Bitumen Transfer, Low – High Viscous Liquid like LDO, FO, Soap Solution Handling, Crude Oil, Tar handling, Power Plant, Resin, Adhesive, Silicate, Molasses Handling, Syrups, Glue plant, Glycerin, Food Industries, Milk, Chemical Plants etc.

Geared Rotary Barrel Pump with 3 times discharge per rotation; for every turn of the handle the rotor turns 3 timesIdeal for use where volume fuel dispensing is needed, such as construction sites, workshop, aviation, farms boat etc.Aluminium die cast pump with sintered gear driven die cast rotor & vanesComplete with 3 pc threaded suction tube for use on 50-210 litre drumsRECOMMENDED USE Petrol, Diesel & Kerosene

To Deliver varierty of light and viscous liquid such as oil, fats,Coal tar.Paints,Molasses Highly viscous materials and liquids Paints, Ammonia, Glycerin, Grease etc. Technical Data :- head : up to 120° mtr. Flow : up to 200 m3/hr Temp :up to 250 C M.O.C :Cl,cl/ SS ,SS 304,SS 316 /316L RPM : 1440 RPM Type : Mechanical Seal /Gland Type .

• Brand Name: Metro
• Country of Origin: Made in India
• Power Source: Pneumatic
• Motor Horsepower: 5 HP
• Head: 0-5m
• Phase: 3
• Design Type: ci
• Model Name/Number: m 119
• Motor Speed: 1000 RPM
• Discharge: 100-150 LPH
• Frequency: 50
• Voltage: 230 v
• Type Of Pump: Internal Gear Pump(Gerotor)
• Usage/Application: Industrial
• Material: SS
• Warranty Period: 0-6 Months
• I Deal In: New Only

• Brand Name: Prashant
• Material: Cast Iron
• Size: Standard

• Pressure: 10 kg
• Capacity: Up to 80 m³/hr
• Head: Up to 100 Mtr.
• Discharge Size: Up to 65 mm.
• Temperature: Up to 200°C
• Speed: Up to 1440 mm
• M.O.C.: SS304, SS316

• Type: Rotary Gear Pump
• Certification: ISO 9001:2008
• Application: Gear System
• Weight: 20-300kg
• Color: BLUE
• Condition: New
• Automatic Grade: Semi Automatic
• Driven Type: Electric
• Pressure: 20-40Bar
• Warranty: 1year
• Country of Origin: India
• Brand Name: K-TECH
• Capaicty: Up to 195 M3/hr
• Head: Up to 100 mtr
• Discharge Size: Dn 12 to 200 mm
• Temperature: Up to 200c
• Speed: Up to 1500 rpm

• Brand Name: Industrial Rotary Gear Pumps
• Material: Ss 316
• Application: Viscous liquid
• Type: Rotary gear pump
• Country of Origin: India
• Material: Ss 316

We are offering industrial rotary gear pumps. In order to cement our reputation in the market, we are engaged in offering an excellent range of rotary gear pumps with the aid of advanced technology. These pumps are extensively used for various industrial purposes. Our offered pumps are available in various specifications and are tested on a series of quality parameters to ensure their perfection in all aspects. Moreover, our clients can avail these pumps from us at market leading prices. Reliable engineers are expertise in manufacturing of rotary gear pumps, design of pump is sturdy and parts are with long life, manufacturers & exporters rotary gear pumps, special features: unidirectional flow designs very high suction lifts & low noise level single piece shaft supported by self lubricating bearings on both end for long life of pump pulsation free continuous flow compact & light weight high volumetric & overall efficiency application: lubricating oils, fuels and all liquids which has lubrication properties emptying barrels and tanks of oils to increase fuel oil pressure for oil burner service and fuel injection pressure pressure lubrication and cooling of bearings, oil circulation through cooler, gear lubricants etc

• Brand Name: Hindustan Pumps
• Motor Horse Power: 3 hp
• Max Flow Rate: 225 LPM
• Phase: Three Phase
• Model Number: RG 50
• Motor Speed: 1450 RPM
• Country of Origin: Made in India
• Power: 2.2 kW
• Power Source: AC Powered
• Head: 10m
• Nominal Displacement: Rotary Gear Pump
• Frequency: 50 Hz
• Voltage: 415 V
• Material: Stainless Steel
• Material Grade: SS316
• Suction: 75mm
• Impeller Diameter: 205mm

By keeping the track of the latest market trends, we are engaged in manufacturing and supplying an exclusive range of Rotary Twin Gear Pump. Uses: Used in chemical installations to pump high viscosity fluids. Features: Long operational life Superior functionality Enhanced working life

• Motor Horse Power: 5 HP
• Phase: Single and 3 Phase
• Max Flow Rate: 20-500 LPM
• Brand Name: JIKSAN
• Motor Speed: 2000 RPM
• Power Source: AC Powered
• Model: JRG
• Head: 10 - 100 METER
• Discharge: 50-100 LPH
• Maximum Pressure: 100-150 bar
• Type Of Pump: External Gear Pump
• Features : Easy maintenance, Excellent performance, Smooth functionality

We are manufacturing rotary gear pump for various industrial use i.e. Transferring hot and cold fuels

Rotary Gear Pump Characteristics     Capacity:     All Positive displacement rotary gear pumps are self priming pumps in which the efficiency of transferring the liquid is deter mined by the cavity between the gear teeth.The accuracy in capacity thus depends upon the accuracy of teeth cutting and its profile. The DR series of Durga gear pumps has modified profile teeth cutting yield accurate capacity within the force range. The double helical heringesbone gear design delivers constant volume without any pulsation. It also avoids internal slipage and gives great volumetric efficiency.   Pressure:   All Durga gear pumps are self priming type pump with suction lift of 5 metres at mean viscocity and speed of 1440 RPM. The liquid flows into the pump due to a difference in pressure is called NPSH (Net Positive Suction Head), the accurate calculation of which is very much necessary for the selection of a pump. When the suction lift is more than 5 meters the pump has to be run at slow speed.The discharge pressure indicated by the pump is nothing but the over coming of pressure exerted by the resistance of the pipeline and the shearing force of the Liquid.Thus a gear pump does not develope pressure by its own but work against the system pressure exerted on it.

Applications To Deliver a Variety of Light & Viscous Liquids such as Oil, Fats, Coal, Tar, Paint and Molasses. Highly Viscous or Semi Viscous Liquids like Ammonia, Bleaches, Coal, Tar, Dyes, Fruits Juice, Gasoline, Glycerin, Glue and Grease. Paints, Soap Solution etc..

• Pressure: Up to 10 kg/cm2
• Capacity: Up to 195 m3/hr
• Head: Up to 100 mtr
• Discharge Size: Dn 12 to 200 mm
• Temperature: Up to 200oC
• Speed: Up to 1500 rpm

Applications : To Deliver a Variety of Light & Viscous Liquids such as Oil, Fats, Coal, Tar, Paint and Molasses. Highly Viscous or Semi Viscous Liquids like Ammonia, Bleaches, Coal, Tar, Dyes, Fruits Juice, Gasoline, Glycerin, Glue and Grease. Paints, Soap Solution etc...   Features : Self priming pumps with five mtr. suction lifts. Compact in size, low noise, high efficiency. Easy maintenance, longer life, economical. An inbuilt pressure relief valve. Bush bearing with a heavy shaft. Double helical gears to reduce axial thrust. Continuous duty Handle multiple liquids. Unique design.   Material of Construction : Cast Iron Alloy Steel CE8M
