Rotary Unions Dealers in Ahmedabad

• Type: Rotary Unions
• Material: Brass
• Application: For Rotary
• Condition: New
• Pressure: High Pressure
• Country of Origin: India
• Brand Name: HEXOTO
• Brand Name: Hexoto

 Rotary Union Right Hand / Left Hand shaft Thread Available size 1/4″ to 2″ Housing Brass Shaft S.S (Stainless steel) Seals Carbon Filled PTEF Telfon Rpm 1/4″ to 3/4 =3500 rpm, 1″ to 2″= 1000 rpm Maximum Flow Mono Flow / Dual Flow Media Water, Oil, Gas, Chemical, Air

Dual passage slow speed radial seals, rotor supported between iolite bearings,also suitable fpr triple passage service with tandem arrangment.

• Brand Name: Carbon Rotofluid

In mono flow water rotary union, There are two type of rotary union is available as per below. 1) Threaded Type (RH/LH Thread) 2) Flange Type Technical Parameter:- Size is available: 1/4" to 3" BSP Maximum Speed: 3000 RPM Maximum Pressure: 1.0 MPA Maximum Temperature: 120 C Material: With brass body and SS Rotor Feature of this product:- - Plane sealing design - Multiple spring design - Balance design with external spring - Self supporting design - Standard antimony impregnated graphite or carbon graphite sealing technology - Precision Ball bearing support - High concentricity - Applicable to high speed design - Ease of maintenance Except for the above product specification, company product can also be customized accordingly to the customer requirements. Kindly feel free to contact us for the detail catalouge, Drawing and any clarification is required. We are ready to serve you.

The U series is the most widely used version, supported by 2 ball bearings and available with graphite (for filtered air and water) or silicon carbide (for oil and water) seals. Available in one or two way versions and sizes ranging from ¼” to 2½”.

• Material: Aluminium, Brass, Stainless Steel, Copper
• Color: Silver
• Brand: Metro
• Media: WATER
• Surface Treatment: Galvanized
• Material Grade: SS 304
• Size: 3/4 inch

Operating Data : For size 1/4" Port (20,000 RPM) : Max Hydraulic Pressure 1500 PSIMax. Speed 20,000 RPM MaxFlow Rate 4.3 GPM For size 3/8" Port (15,000 RPM) : Max. Hydraulic Pressure 1000 PSIMax. Speed 15,000 RPMMax. Flow Rate 12 GPMMax. Temp. 160o F Features : Self supported rotary UnionMonoflow designCompact carbide mechanical sealIn-built with ABEC7 highly precision angular contact bearingsTreated steel rotorAluminum alloy housing & end elbow duly hard anodized directly interchangeable with any brand of OEM self supported rotary unions
