SHAH ELECTRONICS Nikol, Ahmedabad, Gujarat

Shade Direction : Down

15W Solar LED Street Light Fixture Item Code : SESTL-SLED-1510 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage12VDC +/- 10% Input Power15Watt +/- 10% Ingress ProtectionIP-65 Lighting Efficiency100 ~ 120 lm/W. LED Type1.1W - 10 nos. Color Rendering Index>= 75 Color Temperature6500K +/- 500K ( White) Circuit Efficiency>= 85%. Protection GearUnder voltage / Over Voltage Protection BodyAluminium Die Cast Body Fixture Dimension (L x W x H in mm.)390 x 130 x 60 Recommended Mounting Height10 Ft. – 15 Ft. Recommended Battery Size12 VDC / 60 Ah (20% DDC Prot.- 2 – Days Autonomy) Recommended Solar Panel Size12 VDC / 60 W ( IEC – 61215 ; IEC – 61730 , -2 ) Recommended Solar Charge Controller12 VDC / 5 Amps

8W Solar LED Lantern Item Code : SELNT-SLED-008126 Features Designed and developed as per M.N.R.E Specification. Luminaries Design as per IS 10322 – 1 , IS 10322 – 4 , IS – 2418-1, IS – 2418-2 Poly Carbonate Body Fixture – Eliminates Problem of Rusting and provides long life to mechanical structure of street light. German Make – Imported High Grade Aluminium Reflector as per DIN EN 10204, DIN 5036 & DIN 67530. Electronic Control Gear for Lamp – Improves Light output and reduces power consumption designed as per EN-61347-1,-2-3. Turns-on automatically when power supply fails. Short Pay Back Period Saving more than 50% Power than conventional. Works on both AC Supply (Charging Adapter provided)  as well as on Solar Panel. Specifications   Operating Voltage12VDC +/- 10% Input Power8Watt +/- 10% Ingress ProtectionIP-65 Lighting Efficiency90 ~ 110 lm/W. LED Type64mW 5mm Power LED - 126 Nos. (UV Free LEDs). Color Rendering Index>= 75 Color Temperature5500K - 6500K Circuit Efficiency>= 85%. Protection GearUnder voltage / Over Voltage Protection BodyPoly Carbonate Body Fixture Dimension (L x W x H in mm.)200 x 200 x 320 Recommended Battery Size12 VDC / 7 Ah. C/20 Discharge Rate @27°C Recommended Solar Panel Size12 VDC / 5 W (As per MNRE Spec) Recommended Solar Charge ControllerBuilt-in.

Single Face LED Airport Guidance Sign Boards Item Code : SE–AGS–LED–1F Features   Designed and developed as per ICAO Annex 14 and FAA Standards. Virtually eliminates runway shutdowns due to LED light source. Direct replacement for existing sign. Creates a highly uniform distribution of light, eliminating hot spots and shadows. Operates on ferroresonant or thyristor CCRs that are designed in compliance with FAA  / ICAO-ANNEX-14 requirements. Operates on 3-step, 5-step and 6.6A series circuits. Eliminates re-lamping expenses and reduces on-going maintenance costs. Improved safety — low, regulated DC voltage inside sign. Sign lumen maintenance of 70% (L70) minimum for greater than 5 years (assuming sign operates an average of 12 hours per day) Type of Sign Illumination                     : Trans illuminated signage with retro reflective sheets / regular sheets. Lamp Type                                                  : LED. Sign Power Input                                     : Style-3 signs designed for operation from an airport series lighting circuit with a current range of 2.8 to 6.6 amperes or a current range of 8.5 to 20 amperes using Isolation Transformer In-between. (As per FAA - AC No: 150/5345-44F - Clause 4.1.4 – Sign Power.) Wind Load and Frangibility                 : Legs provided with breakable coupling for frangibility; As per FAA - AC No: 150/5345-44F - Clause 4.8.3.2 Wind Load and Frangibility Test can withstand wind speed of and jet blast of 90 m/s. As per ICAO Annex 14 Ch. 11 Clause: 11.7.6. Water Ingress Protection                     : As per FAA - AC No: 150/5345-44F - Clause - 4.8.4.5 Rain Test. Low Temperature Tolerance              : As per FAA - AC No: 150/5345-44F - Clause - 5.6.2.3 Low Temperature Test. High Temperature Tolerance             : As per FAA - AC No: 150/5345-44F - Clause - 5.6.2.4 High Temperature Test. Luminance Ratio                                      : Between red and white elements:  1:5 to 1:10 (For Mandatory Signs) (As per ICAO Annex 14 – Appendix-4 Clause: 5). Between adjacent grid points: not more than 1.5:1 (for grid spacing 7.5 cm) (As per ICAO Annex 14 – Appendix-4 Clause: 8). Between adjacent grid points: not more than 1.25:1 (for grid spacing 15 cm) (As per ICAO Annex 14 – Appendix-4 Clause: 8). Maximum and Minimum Luminance over whole sign face: not more than 5:1(As per ICAO Annex 14 – Appendix-4 Clause: 8). Arithmetic Average Value of Sign Luminance of  ( As per ICAO Annex 14- Appendix-4 Clause:4 (a) ) Red Background               :   30 cd/m2 Yellow Background         : 150 cd/m2 White Background          : 300 cd/m2  Sign Board Frame Work                       : Signage frame work contains thick anodized 2 mm thick aluminium profile work with stiffening support.  Sign Board Back Cover                          : 2 mm thick Aluminium sheet Back cover.  Sign Board Face                                       : The signage face is made of 4mm thick poly carbonate glass with computerized cutting and pasting of regular vinyl or Retro-reflective vinyl of make 3M or equivalent.   Emergency Change Over                    : Signage Board with Built in Change over Circuit for Main and Stand-by C.C.R for automatic change over operation in case of Line / C.C.R Fault.  Operating Temperature                      : Temperature: -40°F to +131°F (-40°C to +55°C)

4W LED Dome – Round Recess Mounting Spot / Down-light Item Code : SESPDL-LED-0403 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage120VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power4.32Watt +/- 10% LED Efficacy120 ~ 140 lm/W. LED Type1.22W High Power LED - 3 Nos. Color Rendering Index>= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Profile Fixture Dimension ( L x W x H in mm.)85 x 85 x 45 : Cut-out : 70 x 70 mm Recommended Mounting Height85 x 85 x 45 : Cut-out : 70 x 70 mm

Type : Outdoor Light Fittings

Application : Outdoor Use

Color : Blue, Green, Pink, Red, White, Yellow

Voltage : 110V, 220V

Packaging Type : Paper Box, Plastic Bag

Power Source : Battery, Electric

Feature : High Brightness, High Quality, Low Consumption, Suitable For Indoor Or Outdoor

Light Source : LED

Phase : Single Phase

Frequency : 45-65Hz

Shade Direction : Down

Color : Shah Electronics

Color Temperature : 6500K +/- 500K ( White) and 3000K +/- 500K ( Warm-White)

26W LED Surface Mounting Light Fixture Item Code : SERWL-LED-2610 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Powder Coated C.R.C.A Sheet Metal Body Fixture – Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power26Watt +/- 10% Power Factor>= 0.90 PF Total Harmonic Distortion= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyPowder Coated C.R.C.A Sheet Metal Body Fixture Dimension ( L x W x H in mm.)620 x 105 x 80 Recommended Mounting Height15 Ft. – 22 Ft.

We are offering led surface mounting light fixture. Item code : serwl-led-2610 features designed and developed as per european standards en-60598-1,en-60598-2-3, en-60598-2-4 & en-60968 instant start, no flicker, no noise, low work temperature, low power consumption. powder coated c.r.c.a sheet metal body fixture – eliminates problem of rusting. optimal thermal design to provide extended life to leds. bug free light - uv free led light – eliminating bug problems – reduces frequent glass cleaning expenses. ce marking approved as per european standards - for further details please refer to ce marking certificate. short pay back period saving more than 80% power than traditional fixtures.   13W LED Surface Mounting Light Fixture Item Code : SESF-LED-1309 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power12.9Watt +/- 10% LED Efficacy120 ~ 140 lm/W. LED Type1.22W High Power LED - 9 Nos. Color Rendering Index>= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Profile Fixture Dimension ( L x W x H in mm.)132 x 132 x 100 Recommended Mounting Height10 Ft. – 12 Ft.

1W LED Spot Light Item Code : SESPT-LED-11 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. es?c p Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50 / 60 Hz +/- 4% Input Power1.3Watt +/- 10% LED Efficacy90 ~ 110 lm/W. LED Type1.15W High Power LED - 1 Nos. Color Rendering Index>= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Profile Fixture Dimension ( L x W x H in mm.)70mm Dia. Cut-out Recommended Mounting Height10 Ft. – 12 Ft.

Wattage : 3 W

26W LED Kitchen Light Fixture Item Code : SEKL-LED-2610 Features   Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Powder Coated C.R.C.A Sheet Metal Body Fixture – Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power26Watt +/- 10% Power Factor>= 0.90 PF Total Harmonic Distortion= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyPowder Coated C.R.C.A Sheet Metal Body Fixture Dimension ( L x W x H in mm.)620 x 370 x 160 Recommended Mounting Height15 Ft. – 22 Ft.

Wattage : 9 W

Material : Aluminium

Shape : Round

IP Rating : IP55

38W LED Flame Proof Fixture Item Code : SEFLM-LED-3830 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power38Watt +/- 10% Power Factor>= 0.90 PF Total Harmonic Distortion= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Die Cast Body Fixture Dimension ( L x W x H in mm.)265 X 265 X 370 Recommended Mounting Height20 Ft. – 25 Ft.

5W LED Dome – Recess Mounting - S.S. Item Code : SEAG-LED-0557 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage230VAC +/- 10% Operating Frequency50 Hz +/- 4% Input Power5Watt +/- 10% LED Efficacy90 ~ 110 lm/W. LED Type64mW 5mm Power LED - 57 Nos. Color Rendering Index>= 75 Color Temperature6500K +/- 500K ( White) and 3000K +/- 500K ( W-Wh) Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodySS Finish / White Powder Coated – Round, Square. Dimension ( L x W x H in mm.)165 X 165 X 100 Recommended Mounting Height10 Ft. – 12 Ft.

3W LED Dome – Recess Mounting - W.P.C Item Code : SEAG-LED-0302 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power2.6Watt +/- 10% LED Efficacy90 ~ 110 lm/W. LED Type1.2W High Power LED - 2 Nos. Color Rendering Index>= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Profile Fixture Dimension ( L x W x H in mm.)92 X 92 X 80 : Cut-out Dia.: 70 mm. Recommended Mounting Height10 Ft. – 12 Ft.

80W LED Dome – High Bay Item Code : SEHBD-LED-8060 Features Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption. Aluminium Die Cast Body Fixture - Eliminates Problem of Rusting. Optimal thermal design to provide extended life to LEDs. Bug Free Light - UV Free LED Light – Eliminating Bug problems – Reduces frequent glass cleaning expenses. CE Marking Approved as per European Standards - for further details please refer to CE Marking Certificate. Short Pay Back Period Saving more than 80% Power than traditional fixtures. Specifications   Operating Voltage110VAC ~ 270VAC +/- 10% Operating Frequency50/60 Hz +/- 4% Input Power80Watt +/- 10% Power Factor>= 0.95 PF Total Harmonic Distortion= 70 / >= 80 Color Temperature5000K – 7000K / 3000K – 5000K Voltage Tolerance Range90 VAC to 300 VAC Circuit Efficiency>= 85%. BodyAluminium Profile Fixture Dimension ( L x W x H in mm.)430 X 430 X 220 Recommended Mounting Height25 Ft. – 28 Ft.

Power Factor : >= 0.95 PF

36 Watt LED Airport Approach/Search Light Fixture Item Code : SEARP-LED-3627 Features   Designed and developed as per European Standards EN-60598-1,EN-60598-2-3, EN-60598-2-4 & EN-60968 Instant start, No flicker, No noise, Low work temperature, Low power consumption, good for eyes. Aluminium Die-Cast Body with Yellow Coating - Eliminates Problem of Rusting. 360° Degrees Horizontal Rotation Adjustment. 45° Degrees Vertical Rotation Adjustment. Short Pay Back Period Saving more than 80% Power than traditional fixtures.
