Slip On Flanges Dealers in Ahmedabad

We are a quality-conscious firm and make sure that our offerings are prepared using the world-class raw material and work methods. Also, the material is sourced from the trusted places only. Since, we have stringent quality control policies, our entire range of products are trusted throughout the industry.   Specifications : ANSI B 16.5 from 1/2" to 24" and classes150 to 2500 (complete range).Applications : Used in quick assembly to save the cost, these are also used in less strict requirements in terms of length of pipe section.

• Size: 1/2"up to 36" (Sizes over 36" available on request)
• Classes: 150 lbs up to 2500 lbs

Slip-on flange usually slips over the pipe. Slip-on flange are typically made with an inside diameter of flange slightly larger than the outside diameter of the pipe. This allows the slip on flange to slip over the pipe. Slip-on flanges are welded to provide strength and prevent leakage. Slip-on flange can sometime also have a boss /ring or hub and can be made with a bore to suit either pipe or tube. Ring pipe flanges and hub pipe flanges are both considered slip-on flanges as they both slip over pipe. Slip-on flanges are generally preferred by users over weld neck flanges, as they are cheaper option than weld neck flange and the fact that less accuracy is required when cutting pipe to length. Slip-on flanges are widely being used in shipbuilding, power generation, petrochemical plant, water treatment, dairy plant, pharmaceutical plant etc.Standards: ASME B.16.5, ASME B.16.47 (A/B Series), B16.48-API590, API 605, AWWA C207, BS 10, DIN 2633, MSS-SP-44.

• Certification: ISI Certified
• Color: Silver
• Corrosion Resistant: Yes
• Shape: Round
• Material: Metal
• Flange Type: Plain

• Type: Slip On
• Material: Stainless Steel
• Shape: Round
• Thickness: 10-20mm
• Certification: ISI Certified
• Color: Grey
• Standard: ASTM A105, ANSI B16.5
• Size: 10-20 Inch, 5-10 Inch, 20-30 Inch, 1-5 Inch, 0-1 Inch

• Material: Stainless Steel
• Shape: Round
• Rust Proof: Yes
• Packing Type: Box
• Surface Finished: Polished
• MOQ: As per Requirements

We manufacture a wide range of Slip-on flanges that is a popular type of pipe flanges. These slide over the end of piping and then welded in place. These flanges are ideal for lower pressure applications and can be easily fitted and welded into different pipes. Welding reduces fabrication costs of these pipes. Specifications:     Stainless Steel ASTM A 182, A 240Grade :F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H,   317, 347, 347H,904L, Duplex stainless steel UNS S31803, 2205,   Super Duplex stainless steel   UNS S32750 Carbon Steel ASTM A 105, ASTM A 181 Alloy Steel ASTM A 182, GR F1, F11, F22, F5, F9, F91 Nickel Alloys Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy   C22,C276 Copper Alloys Copper, Brass & Gunmetal Class 150#, 300#,400 #,600#,900#, 1500# & 2500 #

• Country of Origin: India
• Type: Stainless Steel Flanges
• Certification: ISO 9001:2008 Certified
• Warranty: 6 Months
• Shape: Round
• Brand Name: RAJ GURU STEEL
• Grade: 304L
• Corrosion Resistance: Yes
• Material: Stainless Steel
• Color: Bright Finish
• Rust Proof: Yes
• Grade: ANSI
• Packaging Type: Box,Carton,Bag,Packet
• Quantity Per Pack: 10 Pieces,20 Pieces,30 Pieces,50 Pieces
• Size: 0-1 Inch,1-5 Inch,5-10 Inch,10-20 Inch,20-30 Inch,More Than 30inch
• Specialities: Accuracy Durable,Hardend & Temper,High Quality,High Tensile,RUST PROOF
• Technics: Black Oxide,Hot Dip Galvanized,AS PER CLEINT REQUIREMENTS
• Usage: Automobiles Use,Fittings,Industrial Use,Valve
• Surface Finishing: Polished
• Dimension (LxWxH): 175x90x115mm
• Diameter: 0-10mm,10-20mm,20-30mm,30-40mm,40-50mm,50-60mm,60-70mm,More Than 70mm
• Thickness: 0-5mm,5-10mm,10-15mm,More Than 15mm
• Width: 100
• Tensile Strength: 100
• Hardness: 100
• Length: 1000
• Connection: SORF
• Rated Pressure: 150
• Color: Bright polished
• Usage: Industries
• Name: SS FLANGES
• Product details: Stainless steel 150class SORF
• Name: FLANGES

• Material: HDPE
• Finishing: Polished
• Shape: Round
• Color: Grey
• Usage: Industrial
• Size: 32-400 mm
• Certification: ISI Certified
• Type: Slip On
• Country of Origin: India
• Rated Pressure: PN 10

SLIP-ON FLANGES continue to be preferred to welding neck flanges by many users on account of their initially lower cost, the reduced accuracy required in cutting the pipe to length, and the somewhat greater ease of alignment of the assembly; however their final installed cost is probably not much, if any, less than that of welding neck flanges. Their calculated strength under internal pressure is approximately two-thirds that of welding neck flanges, and their life under fatigue is about one-third that of the latter. For these reasons, slip-on flanges are limited to sizes ½" to 2 ½" in the 1500 lb standard and are not shown in the 2500lb standard.

We are indulged in crafting of slip on flanges which are precisely crafted with all expertise. These flanges are made using premium quality materials. This slip on pipe flanges are slipped over the pipe and then fillet welded. Slip on flat face flanges and welding slip on flanges are easy to use in fabricated applications. We provide these flanges at market leading rates. Stainless Steel ASTM A 182, A 240 Grade F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L, Duplex stainless steel UNS S31803, 2205, Super Duplex stainless steel UNS S32750 Carbon Steel ASTM A 105, ASTM A 181 Alloy Steel ASTM A 182, GR F1, F11, F22, F5, F9, F91 Nickel Alloys Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276 Copper Alloys Copper, Brass & Gunmetal Size 1/8" NB TO 48"NB. Class 150#, 300#,400 #,600#,900#, 1500# & 2500 #. ANSI ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 DIN IN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673 B.S BS4504 , BS4504, BS1560, BS10

• Brand Name: raghu ram metals
• Material: Stainless Steel
• Size: in all sizes
• Standard or Nonstandard: Standard
• Place of Origin: Gujarat, India
• Standard: ANSI
• Packaging Details: Wooden Export Packing

A Slip-On Flange is bored sightly larger than the outer Diameter of the matching pipe. The pipe slip into the flange prior to welding both inside and outside to prevent leaks.The British standard flanges manufactured by us pertain to all standards like BS10 1962 Table D,E,F,H IS 6392 Table 5,17,26 IS 1538 in slip. These are manufactured using mild steel both in slip-on and blind type. Our quality slip on flanges are ideal for lower pressure applications. Their ease of fitting and welding reduces fabrication costs. Our professional engineering team is involved in innovating durable and high-quality products to cater to our clients' needs. Detailed Product Description of Slip-On Flange :The slip-on flange has a low hub because the pipe slips into the flange prior to welding. It iswelded both inside and out to provide sufficient strength and prevent leakage.They are ideal forlow pressure applications. Material specifications: Stainless steel:304,304h,304l,310,316,316h,316l, f10,321 Standard dimensions:Strong Ranging: 0.5" to 24" as per ANSI b16.5, bs 4504, bs-10, asme b 16.36. 26" - 72" as per mss sp44, api -605, awwac-207-55, asme b 16.47, bs 3263Standard ratings: Pounds:150,300,400,600,900,1500 and 2500 Standard facing:Raised face, ring - type, flat face, male - female, tongue - groove.welded both inside and out to provide sufficient strength and prevent leakage.They are ideal for low pressure applications. Advantages of slip on flanges:Low cost installationLess time needed to spent on ensuring the accuracy of the cut pipeThey are somewhat easier to alignThe slip-on flanges have low hub because the pipe slips into the flange before weldingThe flange is welded both inside and outside to provide sufficient strengthThey prevent leakage

We offer an extensive range of Slip on Flanges, which is a very popular type of pipe flanges. These flanges slide over the end of piping and then welded in place, ie Welding Slip On Flanges.

We are engaged in manufacturing and supplying of a wide range of SLIP-ON Flanges. conforming to various National & International standards and specifications. The key to our success in modern manufacturing practice, state of the art equipments and precision inspection tools in the hands of our dedicated workforce. We have forging & Hydraulic presses, heat treatment facilities like electric furnaces for annealing, normalizing with temperature recorders which produce the charts proving the process. I addition we have machining centres, testing equipments and finishing equipment capabilities. We closely monitor the products from its raw material stage to its shipping stage without compromising on quality.
