Tablet Dedusting Machine Dealers in Ahmedabad

It will be fixed under the outlet of tablet compression machine & it will be clean & polished all the tablets pherical vibratory system & give us polished & dust free trablets. Available with Brushing & without Brushing Model with MOC : SS 316.

De-Burring Machine Deburring Machine is an effective equipment for removal of dust and burr from manufactured tablets in an accurate and precise process. The machine operates noiselessly and effectively de burr tablets to the required finish. It is equipped with a height adjustment feature that enables it attain the height of any tableting machine. The contacts parts are made with Stainless steel 304 grades making them durable and hygienic in operation. Parts are easily removable for cleaning and maintenance. De-Dusting Machine The machine offers reliable dedusting process to end with a clean and particle free tablet. It is made with a complete stainless steel frame easy to clean and operate. It offers full suction of the excess powder and may also be equipped with an additional brushing unit. The height of the unit is also adjustable according height of the packing line. De-dusting machine is easily movable from one station to another and has high energy efficiency.

Application De-Duster is pharmaceutical processing equipment that removes the fine surface dust from tablets by using a vibratory effect. This machine can be linked directly to any type of high-speed tablet press.   In Elevating Dedusterthere are vibrated uphill type sieves. The tablets enter the bottom inlet of perforated sieve from directly Tablet Press then they are gently vibrated and the tablet to move forward, upward, turning and rotating along the spiral up hill path of the perforated plate to outer at top of the sieve.Inspiral deduster there is vibrated spiral path perforated sieve. The tablets enter in centre of perforated sieve from directly Tablet Press then they are gently vibrated and the tablet to move forward, turning and rotating along the spiral path of the perforated plate to outer peripheries.   Features All contact parts AISI 316 & non-contact parts AISI 304. Geometrically designed tablet route to ensure remove dust and burrs. Easy to install with all types of Tablet Press with an inline metal detector. Option for Spiral OR Elevating-Up hill type Deduster. Adjustable height. Easy and simple dismantle for cleaning of all contact parts. Design is cGMP – Current Good Manufacturing Practices compliance.

Tablet Coating Machine, Mass Mixer Machine

• Power: 0.25 HP / 3 Phase / 1440 PM
• Output (for 8 mm Tablet): 5,000 to 2,50,000 tablet / HR.
• Max. Tablets Diameter: 25 mm
• Mini. Tablets Diameter: 5 mm
• Overall Dimensions: 400 mm (L) x 400 mm (W) x 800 (H)

  PROTON DE-BURRING & DE-DUSTING MACHINE   Salient Features   cGMP model. Noiseless & maintenance free unit. All contact parts can be easily washed and / or sterilised. Electric power requirement less than other machines of the kind. No lubrication required. Tablet conveying route is so geometrically designed that tablet burrs can break easily. Telescopic design for height adjustment. Suitable for online application for all types of tablet press machine.

• Output / per hour: 5000 - 25000 ( Depending upon size & speed )
• Power: 0.25 HP / 3 Phase / 1440 RPM
• Max. Tablet Diameter (mm): 25
• Min. Depth of Fill (mm): 5
• Dimension L x W x H (mm): 800 x 400 x 400
• Net Weight (kgs) (Approx.): 115

Salient Features Noise less and maintenance free VIBRO type GMP model. Very low electric power consumption. All contact parts of SS 304. Components can be easily washable and/or sterilized. Easy cleaning, no tool required. No moving components, hence almost maintenance free. The machine is having Hydraulic Power pack for pressure loading and overload release. A hydraulic gauge is also provided on lower guard for easy view. Tablet conveying route is so geometrically designed for arrangement of tablets on their burrs which can break easily. Efficient DE Burring & DE Dusting and full suction output is concentrated on de dusting zone for flushing out powder. With brushing unit (optional).

• Voltage: 415V
• Material: Mild Steel
• Output: Up to 100 to 200 Kg / hr
• Frequency: 50Hz
• Power Source: Electric

• Material: SS
• Voltage: 230 V
• Automation Grade: Semi-Automatic
• Phase: Single Phase

• Country of Origin: India
• Type: Tablet Dedusting Machine
• Weight: 100-500kg
• Voltage: 440V
• Condition: New
• Automatic Grade: Semi Automatic
• Driven Type: Electric
• Motor: 0.5HP

STERIAL De Burring and De Dusting Pharma Machine can be equipped with rotary tablet press machine. It is an ideal pharma machine for fine de-dusting of tablets and for upward movement of tablets with automatic dust removing system. Salient Features: ·         Contact parts ss316 & Non contact parts ss304 ·         Noiseless and maintenance free design ·         Height adjustable suitable for tableting machine outlet Dies & Punches ·         Can be easily attached with Metal Detector Unit   Silent Features: ·         Numbers of tray can be change

• Max Dia. of Tab: Up to 40 mm
• Max. Output: 174,000 Tab/hr* for 8 mm tab. dia.
• Electricals**: 0.5 HP, 1Ø , A.C.

• Model: KEEDD
• Output* (for 8 mm tablet): 5000 to 2,50,000 tab/ hr
• Power supply: 0.18 KW, 3 phase, 415 VAC, 50 HZ
• Max. tablet diameter: 20 mm
• Min. tablet diameter: 4 mm
• Conveying height differential: 235 mm
• Net weight: 110 kg
• Gross weight: 190 kg
• Overall Dimension: 550 x 45 x 115 mm Min/ 130 Max
• Case Dimension: 65 x 55 x 130 mm

• MODELS: CPMDB-80
• Max Dia of Tablet: Up to 40 mm
• Max. Output: 200,000 Tab/hr* for8 mm tab. dia
• Electricals**: 220 V, 1 Ø,50 Hz, 1 Amp, A.C.

  Simple, tiny table top unit suitable for straight attachment to the tableting machine’s spout for de-burring and de-dusting of tablets. The unit consists of inlet, outlet, stainless steel vibratory screens, Poly carbonate cover, vacuum connection nozzles, compressed air connection and magnetic coil housed in stainless steel body.

"Cemach" Elevating type De-burring & De-dusting Machine has three main function: De-dusting of tablets, cleaning of tablets through compressed air and movement of tablets upward. The machine can be equipped with Tablet Press, not only for fine De-dusting of tablets, but also for upward movement of the tablets with auto removing dust.

• Input voltage: 220 V Single Phase / 110 V Single Phase
• Motor: 02 nos., 0.25 Hp, 220 V, 3Ph
• Tablet runway: 4.5 meter ( approximate )
• All contact parts: SS 316
• “U” type ribbon: Silicon rubber
• Acrylic guard: 310 mm O.D. x 5 mm thick
• Castor wheel: 2” size, wheel of PU material
• Power Supply: Single phase, 220 V 50 Hz / Single phase, 110 V 60 Hz.
• Charging spout: 175 mm x 50 mm
• Charging Height: 710 to 860 mm ( plus 150 mm extension piece)
• Dis. charging Height: 870 to 1030 mm ( plus 150 mm extension piece )
• Output per hour (8mm Tablet): @ 2,50,000 Tablet / Hr.

• Output *: 5,000 to 2,50,000 tablet / Hr.
• Main Electric Motor: 0.25 Hp. / 1440 RPM / 3 Ph.
• Max. Tablet Diameter: 25 mm
• Min. Tablet Diameter: 5 mm

Components can be easily washed or sterilized. Designed for effective De-Burring and De-Dusting Noiseless & Maintenance free unit. Adjustable height to suit any tableting machine outlet. Minimum electric power consumption. Suction outlet concentrated on De-Dusting zone ensures maximum flushing of removed dust.

• MODELS: CPMDB-80
• Max Dia of Tablet: Up to 40 mm
• Max. Output: 200,000 Tab/hr* for8 mm tab. dia
• Electricals**: 220 V, 1 Ø,50 Hz, 1 Amp, A.C.

Simple, tiny table top unit suitable for straight attachment to the tableting machine’s spout for de-burring and de-dusting of tablets. The unit consists of inlet, outlet, stainless steel vibratory screens, Poly carbonate cover, vacuum connection nozzles, compressed air connection and magnetic coil housed in stainless steel body.

• Output (for 8mm tablet)*: 5,000 to 2,50,000 tablet / Hour

De-Dusting, De-Burring and Conveying by Vibration: The tried and tested vibration Basis of these De-Dusters. Fine-tuning of the oscillating magnets with the spring assemblies causes the tablet to move forward, turning and rotating along the perforated spiral. This removes dust and burrs resulting from pressing are gently broken off.Direct De-Dusting and Transport for any Tablet Press: The De-Dusters can be used with any Tablet Press from any manufacturer.Simple Disassembly for Cleaning: Loosening a Locking screws allows all the components mounted on a central shaft to be easily removed. The outer cylinder is pulled off after opening a collar. All components may be cleaned dry or wet, allowing optimal cleaning to be achieved in accordance with GMP standards.

This machine is used to compile the dust and other particles which basically come out of the compression machine. This machine is basically mounted directly at the end of compression machine. “Duke” Tablet Dusting is basically a pharmaceutical equipment that clear away the fine surface dust from tablets through the vibratory effect. In this machine there is basically a vibrated uphill type sieves. It is specially designed on vibratory motor principle. This machine is basically a vacuum cleaner which has got suction side as well and this suction side is mostly used for cleaning purpose only. This machine is connected to the tablet through a hosepipe from where the De Dusted powder is extracted out and collected.   Characteristic Features The De Dusting disc penetration diameter is about 3mm. It has got SS316 contact parts in it. Designing of this machine is totally encapsulated. This machine is easy to clean and handle. Their is basically proper path of moving the tablet. In this machine height adjustment can also be done with four wheels. This machine is of compact size that is it takes minimum floor area occupation. Maintenance of this machine is quite less as compared to the other extracting machines. This machine is geometrically designed ensure to remove dust and burrs. It is completely made from the stainless steel . It can be easily attached with the Metal Detector Unit. In this machine all the components may be cleaned dry or wet which allows optimal cleaning to be achieved in accordance with GMP standards.

• Max. Tablet Diameter: 25 mm (40mm on Demand)

Highest possible effective de-dusting & de-burring of the tablets by means of vibratory effect. Discharged tablets from the Tablet Press are entered to the top of the Tablet De-Dusting Machine and finally passed through elegantly designed perforated spiral which gently vibrated to release the layer of surface dust & remove the edges. Geometrically designed tablet conveying route to ensure easy removal of dust & burrs. All contact parts are easily accessible for washing. Compliance with cGMP standards with all products contact parts made of SS 316. Unique design for de-dusting & de-burring of tablets. Easy to Install, noiseless & maintenance free unit. Less electric power consumption compare to other units of its kind.

• Output *: 5,000 to 2,50,000 tablet / Hr.
• Main Electric Motor: 0.25 Hp. / 1440 RPM / 3 Ph.
• Max. Tablet Diameter: 25 mm
• Min. Tablet Diameter: 5 mm

Components can be easily washed or sterilized. Designed for effective De-Burring and De-Dusting Noiseless & Maintenance free unit. Adjustable height to suit any tableting machine outlet. Minimum electric power consumption. Suction outlet concentrated on De-Dusting zone ensures maximum flushing of removed dust.

• TECHNICAL SPECIFICATION: Model
• CMDEL-500: Output
• 1,74,000 Tablets / Hr. for 8mm dia. Tablet: Max. Tablet Diameter
• Up to 40 mm: Power Supply

“CEMACH” Elevating type De-burring & De-dusting Machine has three main function: De-dusting of tablets, cleaning of tablets through compressed air and movement of tablets upward. The machine can be equipped with Tablet Press, not only for fine De-dusting of tablets, but also for upward movement of the tablets with auto removing dust. FEATURES This works on the principle of vibration, which causes elevating type movement of the Tablets. All Contact Parts are made of highly mirror polished S.S.316. All seals in powder contact are supplied in food grade nontoxic white rubber or white silicon rubber. The stand is made from stainless steel whose height is adjustable for charging height (discharge from tableting machine) from 700 to 850 mm..
