Temperature Detectors Dealers in Ahmedabad

We manufacture customise rtd pt 100. We specialise in bearing rtd, winding temperature rtd & autoclave rtd.

• Type: PT 100(100 ohm at 0°C)*
• Model: TSRE
• Element: Single
• Body Material: Fibre Glass epoxy
• Accuracy: Class A/B/2B

The Stator winding temperature detector (RTD) are used to measure winding temperature of large Motors, Generators etc. These sensor are sandwiched between the windings of Motors/Generators. Unlike on/off devices, It allows continuous measurement of winding temperature. The NEMA recognizes this kind of sensor as a standard protection for motor and generator Insulation. Normally, these RTDs are of wire wound and sensing element extends through out the length of the detector. These feature will provide average temperature reading. Normally six sensors are recommended for each motor, Two per Phase. This RTD are generally flat type in construction and are available in various sizes. Main Features Slim dimensions to get inserted in between windings Bifilar wound slot resistance thermometer design that prevents induction voltage resulting in measurement errors Resistance to shock, vibration and pressure Withstand of VPI(Vacuum Pressure Impregnation) Process High Dielectric Strength ATEX /IECEx approve model available for equipment used in hazardous area

• Sensor Type: 2 Wire / 3 Wire / 4 Wire
• Wiring Configurations: Simplex / Duplex
• Detectors: PT100 / PT1000
• Class: Class-A / Class-B / 1/3 DIN / 1/10 DIN
• Termination: Terminal Block / Transmitter / Indicator / Cable
• Temperature Range: -200°C to + 600°C

Context Plus XP95 temperature (heat) detectors have a common profile with ionisation and optical smoke detectors but have a low air flow resistance case made of self-extinguishing white polycarbonate. They monitor temperature by using a single thermistor network which provides a voltage output proportional to the external air temperature. The response to temperature increases of the standard temperature detec tor (part no: 55000-400IMC) enables the detector to be utilised as an EN54 Grade 2 heat detector. To provide a device for use in ambient temperatures of up to 55°C, a high temperature detector (part no: 55000-401IMC) is also available. This has similar characteristics to the standard temperature detector at 25°C but reaches a 55 count (alarm) at 90°C.

Resistance Temperature Detectors, Pneumatics Fittings, Pressure Switch

Resistance Temperature Detector, High Temperature Thermocouples
