Textile Machinery Mfg. Co. Gomtipur, Ahmedabad, Gujarat

TRUCKMAN offers powered, hydraulic lifting platforms (Model No.“TL-17M”) designed to meet the growing demand for low-prices lifting tables with high quality. These tables are available in lifting capacity from 250 kg to 5000 kg having table sizes up to 3000 mm in length. The table can lift 800 mm to 3000 mm with the help of multiple scissors. The scissors are used to elevate the table by applying force through a hydraulic cylinder operated by a motorized pump unit or a hand pump. Two limit switches (optional) are provided for limiting the raised height as well as the lowered height. Applications include lifting and transporting of heavy dies or heavy materials. The tables enable an operator to lift, lower and move loads and transfer heavy loads from floor to floor, vehicle to vehicle and machine to machine speedily, says the firm. They are used in engineering industries, water houses and transport companies, and for placing dies on power presses. These tables also find applications in automatic feeding of tin sheets in cutting, printing and maintenance work. Special accessories (optional) include railing to cover the three sides of the table, loading ramp or tilting table, turntable on top of the table to change direction of the movement of the load, roll off guards, runover flap (for vehicle loading), safety stand, safety skirt and emergency stop bar

This Battery Operated Power Pusher is an incredibly versatile multiuse tug for handling heavy load up to 20 ton on shop floor or 50 tons on Rail with built in charger. One Power pusher can handle No. of Carts with ease on shop floor. This has electronic control for forward & reverse travel with variable speed. Different match can be fix to set for specific requirement. This can replace the need for expensive tractor and fork lift truck.

Truck man has developed a mobile hydraulic battery operated floor crane (model no. Tf-b) utilizing battery-power both for movement of the crane on the shop floor and also to power the hydraulic power pack for lifting and lowering the loads. This means a single operator can run the entire operations resulting in enormous cost savings and faster through puts of loads. battery powers a dc traction motor which through gears drives the crane and the travelling speed is upto 6 km/hr. Battery also powers a hydraulic power pack which will lift \ lower loads upto 3000 kgs. And maximum lifting / lowering heights is 2.5 meters. For economy of power pack whereas lowering is by means of a hydraulic release valve for smooth and safe operation, with facility to lock load at any level. these battery operated floor crane can be used for a variety of application such as loading, unloading, lifting, lowering, holding, turning & shifting heavy material.

TRUCKMAN manufacturing material handling Equipments & specialized in the manufacturing of jib cranes from the concept till commissioning. The design is simple, portable, manually operated and capacities range from 250 kg to 5000 kg. Jib Cranes are wall mounted , pillar mounted with swivel facility of 90, 180, 270, 360 degree. The crane span length varies from 1 metre to 5 metre depending upon the load requirements of clients according to the applications. For lifting and lowering either pulley blocks or electric hoists are used and similarly cross travelling can be operated either by manually or electrically from the floor. It is being used in coal sector to large industries, workshops, railways, airport authorities, power plants & steel plants. Truckman cranes are backed by excellent after sales service and the spare parts are readily available at all times.

TRUCKMAN has a wide range of material handling equipments. Offers Hyd. Stacker Model No. SK-15 is suitable for loading, unloading, carrying & stacking of materials in a factory. The TRUCKMAN brand Hydraulic stackers are available in 250 kg to 1500 kg capacities & with lift height 1000mm to 4000mm. Stackers is fabricated of pressed formed / Rolled steel sections. Designed for smooth maintenance free easy operation long life. Hyd. Stackers are available in both fork type or platform type designed Cylinder is coupled to the hydraulic hand pump. The forks or the platform is lifted up by few of the hand pump till it reaches its full height. Lowering is effected by opening the release valve.Lift per stroke is approx 20mm. Mono mast & Telescopic mast models are available. These stackers are fitted with two roller fixed to front legs & two swivel wheels at the rear end. TRUCKMAN also offered Electro Hydraulic Stackers & Battery Operated Stackers.

truckman having a wide range of material handling equipments, offer hydraulic hand operated pallet truck model no. �tp-40mm�, which is easy to operate, silent in operation, need low pulling power and offers maximum maneuverability. it is made from m.s. pressed steel sectional structure. the load is raised by pumping through the handle and lowered with a simple foot operated control highest quality is maintained with hard chrome polished pistons and leak proof double sealed packing. the available range is in capacities of 1000 kgs to 5000 kgs & with fork length of 1100mm to 3000 mm . these pallet trucks are fitted with two m.s. rollers to the front legs & two polymer swivel wheels at the rear end. option is given for cast iron, nylon or polyurethane wheels. battery operated pallet truck is also available.

TRUCKMAN has a wide range of Material Handling Equipments offers a Hydraulic Floor Cranes (Model No. TF-M) with lifting capacities of 500 kg with height 750mm to 2500mm. They provide an efficient low cost alternative to other Materials Handling Equipment. The machine is useful for loading and unloading and shifting heavy and unwidely materials. Designed for maximum maneuverability and tested for 25% overload. The lift is by means of a double acting hand hydraulic pump unit which is fitted with an infinitely controlled release valve. A special hose rapture valve prevents load from falling down in case of hose failure due to accident. The 3000 kg crane is ideal for lifting heavy loads and positioning on to machine tools , as well as other maintenance and assembly jobs. Like the 500 kg model, the jib adjusts to three positions. The jib which has a maximum length of 2000 mm , is lifted by a double acting hand hydraulic pump unit. One man can easily operate the crane. The job is also fitted with a forged heavy-duty swivel hook. The crane is mounted on four polymer wheels with double sealed ball bearing. Other products offered are 360 degree swivel crane & counter weight type floor cranes. TRUCKMAN also offered Electro Hydraulic Floor Crane & Battery Operated Floor Crane.

TRUCKMAN offers the High Lift Pallet Truck newly designed , lightweight, easily maneuverable besides having all the advantages of a conventional hand pallet truck and can be conveniently used as a lifting table. The High Lift Pallet Truck can be used whenever there is a problem of working heights or to overcome different levels. Working at a convenient height reduces time loss & increases output but without any fatigue. High Lift Pallet Truck is offered in standard capacity of 800 kg and fork length 1100mm & width 535mm. It can reach a Max. Height of 800mm. Forks are raised by a hand operated hydraulic pump. The light weight, 3 control position control handle with spring back action facilitates easy pumping and steering. The tolerance , the piston is polished and hardchromed and the unit has high pressure polyurethane seals. Hydraulic unit has few moving parts, and thus easy maintenance and long life. Parts are inter chargeable and available off the shelf. The High Lift Pallet Truck is a versatile work truck, which can be used in all types of work place where efficient materials handling is desired.

the drum stacker developed by tmmc (mhe divn) is designed to lift standard 205 litres barrels and stack the same one above the other or at any other height as may be required in horizontal position. lifting is by means of hand operated pump with facilities for holding, lowering at desired height. these drum stacker are fitted with two m.s. rollers to the front legs & two polymer swivel wheels at the rear end with double sealed ball bearings. it is designed to lift standard 205 ltrs. barrel in horizontal and stack at different desired height. equipment can be modified to suit special applications. also available in a variety of drum lifters and drum jockeys.

TRUCKMAN has introduced a versatile Battery Operated Platform Truck. Chasis is robust construction made out of pressed / rolled steel channel and plate with a strong rubber bumper at front & rear. Salient Features : Drive Motor - A unique differential arrangement gives drive to rear wheel through double reduction with strong roller chain and sprocket attached with drive motor. Electronic Control - For smooth acceleration and power saving an electronic Transistor / Mosfet Chopper Control is provided. There is no energy loss like traditional resistance control and increase Battery working hours. Moreover it prevents electrical and mechanical components from damages. Electrical System - All controls like forward - Reverse-horn-light-emergency cut off and key switch are provided below steering handle on dash board & Hyd. Brake is also provided. TRUCKMAN Battery Operated Platform Truck available in different models & ideal for transporting non-standard nonpalletised loads. The truck is light, quite, compact, safe, easy to handle and needs minimum maintenance. TRUCKMAN also offered Four Wheeler Battery Operated Platform Truck, Tow Truck and Tugger.

Type : Trucks

Material : Cast Iron

Certification : CE Certified

Application : Industrial, Ware House Etc.

Condition : New

Driven Type : Electric

Loading Capacity : 1000-2000kg, 2000-3000kg, 3000-4000kg

Tyres : Solid

Country of Origin : India

truckman battery operated pallet trucks ( model -tp 12 b ) are for use within the shop floor for moving loaded pallets with material. these are made in 1 ton , 2 tons capacities. the lowered height of the fork of 1 ton & 2 tons varied from 90mm to 100mm as standard. the lifted height of fork for capacity 1 ton and 2 tons can be 200mm as standard. this truck is suitable for lifting of heavy materials on shop floors. the battery is of adequate capacity for use for one shift, nonstop. optional higher ampere hour capacity battery can be offered for longer hours. for the capacity of 1 ton and 2 tons , the truck has one single drive wheel with steering. the lift of forks is motorized and an optional hand pump, can also be provided for use in case the motor pump is under repair or maintenance. for 1 ton and 2 tons the steering is directly controlled by a handle.

TRUCKMAN has introduced Access & Work Platform Models, which are available with capacity upto 350 kg. These models are available with single, double scissors up to five numbers to reach up to the height of 10 metres. The maximum platform height is restricted with the length of scissors. The scissors mechanism provides the maximum stability in the maximum height of platform. The lifting muscle is usually by Hydraulic Cylinder commensurate with the lifting capacity. The lifting operation can be provided with various options viz. AC/DC Hydraulic Power Pack. The standard version is having two fixed wheels and two-swivel wheels coupled with screw type parking arrangement. The unit can be moved by manual, differential drive or DC Drive. Application for Overhead Lighting, Crane Maintenance, Rack Storage Systems, Heavy Machine Building, Building Maintenance, Mobile Flood Lighting, Overhead Piping & Aircraft Maintenance, etc.
