Triplex Pumps Dealers in Ahmedabad

Triplex plunger pumps are low-maintenance solutions for high-pressure applications such as hydro testing, car washes, and jetting application. This pump are excellent for testing leakage and integrity from boilers, Pressure Vessels, Metal Casting Parts, Gas Cylinder, Pipes & Tubes Parts. Pump are supply with different metals like brass, forged stainless steel 304, stainless steel 316, duplex steel, nickel bronze, aluminum bronze etc.

We understand that the use of finest grade raw material brings forth high quality product line. In addition to this, we make sure that the material is sourced from the reliable places only. We have trustworthy and well-organized shipping facilities available, along with this, we keep a record of the same as well, and this increases our efficiency and gains the trust of the customers.

• Brand Name: Excel
• Warranty: 1year
• Country of Origin: India

High Pressure Triplex Plunger pumps for Hydrotest,washing and RO applications.

• Pressure: 350 Bar
• Max Flow Rate: 10 to 300 lpm
• Oil Capacity: 1.2 L
• Material: Brass, SS
• Brand Name: Hawk or UDOR Pump

• Capacity: UP TO 300 M3/hr.

MPT series high pressure Triplex Plunger Pumps. Generally used for Car Washer, Reverse Osmosis, Chemical Injection, Boilers Feed Service, Hydraulic Testing, Cleaning of heat exchangers, Boilers, Towers, Chemical Vassels and Shop Floors under high pressure.

The performance data furnished is based on 100% volumetric efficiency considering test media as water at 30° C with the intension to be refered initially for preliminary purposes.

We have in store for our clients, an extensive liquid end series of triplex pumps that are designed by our technical experts that can be used for almost any medium. Depending on the physical and chemical properties of the liquid to be handled or the application to be used in, these pumps are appropriately designed and equipped with cooling, heating or flushing systems. Capacitated with a plunger-cylinder unit, these pumps display excellent arrangement in terms of safety and maintenance. The following features are highlighted by our triplex pumps: High performance non return valves on suction and delivery side Convenient for maintenance Lubricated power end parts by splash type arrangement or forced lubrication Crank shaft is in high quality forged steel & is supported by anti friction bi-metallic bearings Sturdy Balanced design These triplex pumps can be availed by our clients in the following technical specifications: Capacity : Maximum Up to 30 cu. mtr/hr Pressure : Maximum up to 1200 kg/cm2 Material of construction: AISI 316, AISI 304, CI/CS, Brass. Duties(Application) Sectors :- Spray dryer, hydro-testing of equipments, water jet cleaning, metal cutting, car washing etc.   Flow PM Series - Up to 36 Lpm HF Series - Up to 300 Lpm HG Series - Up to 48 to 300 Lpm Pressure HF Series - Up to 200 Kg, per CM squre PM Series - Up to 700 Kg, per CM squre HG Series - Up to 1200 Kg, per CM squre Motor - hp/kw HF Series - Up to 200 Kg, per CM squre PM Series - Up to 700 Kg, per CM squre HG Series - Up to 1200 Kg, per CM squre

Professional approach of meetings various chemical processes. We commit “Technology that saves you money” Triplex Pumps are the result of quality product & services using its full-fledged designing & modern facilities in Ahmedabad. Superior & strict quality control & testing with outstanding pump performance guarantees the products passing through severe processing applications & harshest of chemical substances.   APPLICATION Offers a wide variety of pumping range in industries such as Process Industries for Hydro Cleaning, Hydro Testing, Reverse Osmosis Plants, Spray Dryers, Boiler Feed, Jet Cleaning, Food Processing, Drain & Sewer Cleaning, Chemical Injection & many more applications.     CAPABILITIES Capacity : upto 1000 L/min Pressure : upto 700 kg/cm2 Temperature : upto 300 degree Celsius   ADVANTAGES & FEATURES Extra strong, heavy duty power frames ensures long life A wide variety of valves available to suit different pumping fluids & applications Smooth operations with efficient performance Simple to repair & nominal maintenance cost Spring loaded plunger packing ensures leak free pumping Three piece liquid end block designs avoids any possibility of block cracking

• Max Flow Rate: 17 LPM,21 LPM
• Country of Origin: Made in India
• Automation Grade: Semi-Automatic
• Operation Mode: manual
• Motor Horsepower: 12.5 HP - 20 HP
• Motor Speed: 1440 RPM
• Phase: 3 Phase
• Maximum Pressure: 350 BAR
• Power Source: Electric
• I Deal In: New Only
• Model Name/Number: PXI-17-21-350
• Motor Phase: Three Phase

PressureJet pumps are triplex (three plungers), positive displacement, triplex plunger pumps. We offer both the triplex piston and triplex plunger pumps. With the positive displacement design, each revolution of the crankshaft creates a direct motion in the plunger rods [piston] resulting in a positive output of flow from the pump. This output from the pump [flow] is in direct relation to the speed (here, strokes / minute) of the pump. The plunger diameter and stroke length determine the amount of liquid handled with each stroke and revolution. The discharge pressure is created by the restriction placed upon the flow through nozzles or restrictions downstream. Our triplex plunger pumps deliver a smooth, constant flow and pressure. These high pressure triplex plunger pumps can also be powered by a vari-drive to adjust the flow as needed with changes in demand. The downstream restriction will require adjustment or a valve to regulate the change in flow.   During the suction stroke, the plunger moves to the left, causing the check valve in the suction. Reciprocating positive displacement pump operation line between the reservoir and the pump cylinder to open and admit water from the reservoir. During the discharge stroke, the plunger moves to the right, seating the check valve in the suction line and opening the check valve in the discharge line. The volume of liquid moved by the pump in one cycle (one suction stroke and one discharge stroke) is equal to the change in the liquid volume of the cylinder as the plunger moves from its farthest left position to its farthest right position.

• Type: Plunger Pump
• Certification: ISO 9001:2008
• Application: Industrial,Marine,Power,Hydro Testing, Pipeline Leakage Testing
• Condition: New
• Driven Type: Electric
• Pressure: High Pressure,Low Pressure
• Warranty: 1year
• Country of Origin: India
• Brand Name: EXCEL
• Structure: Heavy & Durable

• Product Name: TRIPLEX PLUNGER PUMP
• Application: Spraying Polyethylene Glycol
• Color: BLUE

Triplex Plunger PumpsHead      : 600 Kg/Cm2Flow       : 2500 Lph Temperature  : 110 °CLiquid     : Spraying Polyethylene GlycolM. O. C   :Pump Head-SS 316

The company is a chief High Pressure Triplex Plunger Pump Manufacturer, Exporter, and Supplier in India. The High Pressure Triplex Plunger Pump, provided by us, is available to the clients in compliance with the client’s needs in terms of flow rate and pressure. The High Pressure Triplex Plunger Pump is used for various applications, such as Washing, Water Jetting, Sewage Cleaning, Hydro Blasting, etc. Designed with pre-set packing and concentric ceramic plungers, our High Pressure Triplex Plunger Pump provides high pressure up to 1000 Kg/ Cm2. Features Extra heavy-duty power frame for uninterrupted life Spring loaded plunger packing for ensuring leak-free pumping services A three-piece liquid end block design avoids any possibility of block cracking Easy to maintain, simple to repair & nominal maintenance needed in case of breakdown Accessories Unloading valve Nozzle for spray Safety relief valve Pressure regulating valve Trigger gun/ handle bar High pressure hose

• Type: Automatic
• Certification: CE Certified
• Weight: 40-50kg
• Condition: New
• Power: 10hp
• Driven Type: Electric
• Warranty: 1 Year

Applications : Chemical Injection Hydro Jetting and Cutting Cement Grouting Detergent Slurry Hydrostatic Testing Salt Water Injection Boiler Feed Reverse Osmosis Mechanical Separation Process Water Disposal Ammonia Scrubber & many other applications

• Capacity: up to 1000 Liters / Minute
• Pressure: up to 500 Kg/cm2
• Temp up to: 300 * C
• M.O.C: SS-304, SS-316, SS-316L, Carbon Steel etc.

Unique Features PHT series High Pressure Triplex Pumps are design for continuous Duty and always ensure trouble free operations. Extra strong heavy duty Power Frame – ensures uninterrupted smooth long life. A wide variety of valves are available to suit different pumping fluids & applications. A three piece liquid end block design avoids any possibility of block cracking. Spring loaded plunger packing always ensure leak free pumping service. Reversible valve seats double the normal life of valve seats thus become long lasting. Quiet , Smooth in operation. Totally dependable, reliable & efficient performance. Easy to maintain, simple to repair & nominal Applications : PHT- Series High Pressure Triplex Pumps are Used in following applications Reverse Osmosis Spray Drier Hydro Testing Chemical Injection High Pressure Homogenizing Food Process sing Cylinder Feeling in Gas Plants like liquid Co2, Nitrogen etc. High Pressure Jet Cleaning in Cement, Chemicals, Papers & Pulp, Plastics, Railways, Shipyards, Steel Plants, Pipes, Automobile etc. industries for cleaning of Rotary Cement Kilns, Condensers, Conveyors, Heat Exchangers, Vessels, Autoclaves, Pulp Vats, Rollers, Latex Tanker, Mixers, Rail Coaches, Ship Hulls, Decks, Steel Plates & Bars, Steel Pipes & Tubes, Fermenting Tubes etc.
