Visual Inspection Equipment Dealers in Ahmedabad

Construction of S.S. matt finished body This is basically a inspection conveyor widely used for inspection empty bottles Special glass helps to show bottle in big size after washing of bottle to find out if any particles or dust or water is still there. Machine is synchronized with filling machine Vibration Free, Jerk Free, Noise less construction with the help

• Country of Origin: India
• Automation Grade: Automatic
• Number Of Operator: 2 X 2 OR 3 X 3
• Motor Power: 0.50 H.P.
• Direction of Movement: Left to Right
• Output: Up to 1500 Container/Minute
• Dome Diameter: 250 mm (1 Nos.)

Features: Construction AISI S.S. 304 Quality. Special Self-aligning bearing ensure smooth and trouble free operation. Suitable for different type of container. S.S. elegantly matt finished body. Reduction gear ensures jerk free and noiseless operation.

• Brand Name: Prism
• Machine Type: Automatic
• Material: Stainless Steel
• Features: Designed as per cGMP - Current Good Manufacturing Practices compliance,A machine structure is made from AISI 304 with matt finish.High-speed visual inspection with high output.Length can make as per customer requirement.PVC black & white board as per GMP

• Power: DC 5V
• Image sensor: CMOS image sensor
• Storage Memory: 1 to 4G PUSH-PUSH Type SD Card (Not support SDHC Type) (Support FAT)
• Resolution: 640h×480V
• Operational Interface: 8 key
• Tip diameter: 3.9,5.5,8,10,12,16,20mm(option)
• Inset tube length: 1,2,3,5,10,20,30m(option)
• S/N ratio: 42db
• Exposure: Automatic
• White balance: Fix
• Field of view(FOV): 67°
• Depth of Field(DOF): 1.5cm
• Light source: 4 white LED
• Display: 3.5
• Monitor: 640×480 pixels
• Interface: Mine USD 1.1/AV out/ AV in
• Battery: Rechargeable Li-polymer battery(3.7V)
• Video out format: NTSC&PAL
• Recording medium: 2GB SD card×1 support to 4GB SD card

• Type: Inspection Machine
• Weight: 100-1000kg
• Voltage: 110V
• Automatic Grade: Automatic
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1year

• Brand Name: Accuplus
• Power: 18650 Rechargeable Lithium Battery , Real-Time Online Charging
• Model Number: Accu ME+
• Is It Flexible: Flexible
• Lighting Type: Front-LED Light
• Operating Temperature: -10 To 50C
• Features: Optimum performance, Operational fluency

We offer vision inspection system. Bestowed by a modernized infrastructure facility, our organization is manufacturing, supplying and export a wide gamut of optimum quality vision inspection system which are manufactured and designed using fine quality material and as per international quality standards. Offered range of vision inspection system can be availed from us reasonable price. mv system is used in a wide range of manufacturing industries such as: medical devices pharmaceuticals automotive parts disposable consumer goods electronic components packaging plastics scratch card printing and much more   machine vision system helps you in various ways like as: to improve inspection accuracy high speed provides excellent production efficiency high consistency measures dimensions within thousandths-of-an-inch accuracy high reliability and resolution increased control over quality management flexible installation easy user interface for reduced operator burden eliminate customer complaint return of investment

Inspection table is equipment consisting of a three-track conveyor with a hood with lighting arrangement and visual inspection background of alternate black & white color. Inspection table have stainless steel structure with moving S.S. slat chain. Structure made out of S. S. square pipe & supported on adjustable bolts.   The central conveyor belt brings the bottle from the capping machine conveyor. These bottles are automatically bifurcated on the two adjoining conveyor belts & further on the side tables for operators sitting on either side of the table. The operators in turn pick up the bottles & visually inspect the bottles in the alternate white & black background to check for any particles in the liquid filled, sealed & breakage of bottle. After inspection the bottles are placed in the central track, which is transfer for labeling.

• Feature: Accuracy, Durable, Easy To Use, Fine Finishing
• Condition: New
• Brand Name: Ahpat
• Color: Silver
• Material: Stainless Steel
• Pixel: Standard
• Water Proof: Yes
• Light Type: LED

• Country of Origin: Made in India
• Voltage: 230-420 V
• Brand Name: Siddhivinayak Engineering
• Features: Condition:New,Dimension:as per the requirement,Color:as per the Requirement
• Power Source: Electric
• Frequency: 50 Hz
• Phase: 3 Phase

OPTICAL VISUAL AMPOULE INSPECTION MACHINE MODEL: AHIM 6 SALIENT FEATURES: • All contact parts in stainless steel.and approved engineering plastics. • Spinning of ampoule/vial.Magnifyed view with back lighting • Clear view of six ampoule/vial. • Modular and compact ejection system. • Rotation of spinners can be adjusted to give desired vortex on liquid • Easy access for cleaning and maintenance. • Large inspection to transport time ratio.. • Facility of repeat cycle. • LED as well buzzer assisted safe rejection. • Counters for good and reject products. OPERATION: • The filled ampoules are loaded in to the infeed chute/ hopper from where they are transferred in batches by an index wheel onto a linear transfer rack. • The rack transfers the ampoules onto the inspection station, where spinners spin the ampoules at a predetermined RPM so that a vortex is formed. Illumination from behind the ampoules assists in light refraction of particles/fibers . • An operator views six ampoules through a magnifying glass. • The ampoules are rejected by pressing rejection switches ergonomically located for operator convenience. A numbered light positioned just above the magnifying lens within the operator's field of vision lights up indicating a rejection In case a recheck is desired before checking the next lot, a facility for repeat cycle is provided. • The ampoules batch is then transferred onto the rejection station where the ampoules rejected at the inspection station are automatically ejected out. A numbered light lights up above the lens indicating a positive rejection taking place. In addition a rejection LED as well buzzer assists in tracking the actual rejects of objects. • The accepted ampoules are transferred onto the collection station where there are collected in a tray. • MACHINE IS SUPPORTED WITH DOUBLE BACKGROUND OPTION TO DETECT BLACK AS WELL WHITE PARTICALS

• Country of Origin: Made in India
• Warranty: 1 year
• Material: SS
• Automation Grade: Automatic
• Model: AEVRS-200
• Usage/Application: Automatic rejection system

We are offering automatic visual vial inspection machine. Model no. nkins - 120 nkins - 250 direction left to right left to right electrical supply 1.0 hp 1.5 hp power characteristics 230 volts, single phase, 50 hz. 230 volts, single phase, 50 hz. Dimensions 3065 mm (l) x 1030 mm (w) x 315 mm (h) 4290 mm (l) x 1230 mm (w) x 1300 mm (h) net weight 450kgs. (approx) 700kgs. (approx) gross weight 625kgs. (approx) 1075kgs. (approx) input specification 5 ml to 30 ml 5 ml to 30 ml

APPLICATION & PROCESS : Visual Bottle Inspection Machine is used for visual Inspection of filled bottles to checked for non required foreign particles & leak checking and to ensures maintain quality standard of products as per requirements in Pharmaceuticals & Foods Industries. Inspection table is equipment consisting of a three-track conveyor with a hood with lighting arrangement and visual inspection background of alternate black & white color. Inspection table have stainless steel structure with moving S.S. slat chain. Structure made out of S. S. square pipe & supported on adjustable bolts. The central conveyor belt brings the bottle from the capping machine conveyor. These bottles are automatically bifurcated on the two adjoining conveyor belts & further on the side tables for operators sitting on either side of the table. The operators in turn pick up the bottles & visually inspect the bottles in the alternate white & black background to check for any partials in the liquid filled, sealed & breakage of bottle. After inspection, good bottles are placed in the central track, which is transfer for labeling. SALIENT FEATURES : Designed as per cGMP - Current Good Manufacturing Practices compliance A machine structure is made from AISI 304 with matt finish. High-speed visual inspection with high output. Length can make as per customer requirement. PVC black & white board as per GMP norms Belt drives through gear motor with variable frequency drive. Provides guide for chain of UHMW self lubrication. Adjustable height of conveyor belt, to align with other machine of the line Self-alignment bearing for easy maintenance. Rigid Vibration free Construction for trouble free performance.

• Country of Origin: Made in India
• Brand Name: Laxmi
• Model: LVIM 60, LVIM 120, LVIM 240
• Power Supply: 1.5 to 3 HP, 3 Phase, 50 Hz
• Conveyor Height: 800 - 500 mm or as per the requirement
• Input Specification: Vial Dia: 23 To 38 mm, Vial Height : up to 70 mm
• I deal into: New only
• Made in: India
