Instrumentation Equipment Dealers in Makhupura, Ajmer

• Color: Grey
• Application: Control Panel
• Size: Multisizes
• POWDER COATED PANELS WITH SWITCHGEARS LIKE MPCB CONTACTORS LED INDICATIONS & OPERATING PB AND SENSORS: BUILDING SOFTWARE AS CLIENT APPLICATIONS

Automation Panels: 1. only PLC like Siemens, Delta, Omron, Mitshubishi 2. PLC with Opto Isolation (From a few 6 to 250 DI/DO with Analog AI/AO 3. Micro Controller based Panels (Opto Isolated 8 Digital Inputs, 6 Digital Outputs, 4 Analaog Inputs/Outputs 4 PLC with HMI for Industrial Application 5 We also interface PLC output with Opto-isolated AC cards at 230V ac

For temperature measurement in the range, -200ã�â°c to + 850ã�â°c resistance temperature detector (rtd) is preferred to thermocouple and other sensors because of its higher accuracy, reliability, compact size and faster response. Rtds find use in almost all industries like plastic and rubber processing, food industries, pharmaceuticals, chemical & petrochemical plants, and power plants. It is also used in diesel engines & ships, process control and laboratories for temperature measurement and control. Rtds are available with single or double resistance elements and in 2, 3 or 4 wire circuits. Various types of protection sheaths for protection of the element and screw-in threaded bushes either fixed (welded) or adjustable by screws (for non-pressure application) or by compression fitting (for pressure application) for mounting are available. Features: ã¯ï¿½â· high accuracy and stability ã¯ï¿½â· wide temperature range; -200ã�â°c to +850ã�â°c ã¯ï¿½â· fast response & high insulation resistance ã¯ï¿½â· needs only copper cables for long runs.

• Accuracy: 0.5 %FS
• Features: Full-sealed construction, Full stainless steel construction, compact size, easy installation
• Rated Supply Voltage: 2-wire 15
• Protection Type: IP 65
• Model Name/Number: TP7700
• Brand: TIPL

• Type: Pt100, Pt200, Pt1000
• Feature: Higher Accuracy & Stability,
• Configuration: Simplex/Duplex
• Connection: 2/3/4 wire
• Insulation: Mineral/Ceramic Insulated
• Sheath Material: SS316
• MI Cable Sheath Diameter: 2, 3,3.2, 4.8,6, 8 mm
• Termination: Head /Cable/ Connector
• Process Connection: Threaded / Welded/ Flanged

• Country of Origin: Made in India
• Brand Name: TIPL
• Model Name/Number: TTFUH
• Accuracy: High accuracy (< 0.1% FS) and loaded with advanced functions
• Protocol: HART or Profibus Protocol
• Protection class: IP66
• EMC: Electromagnetic compatibility (EMC) according to IEC 61000-4-3
• Isolation: upto 2kV between Input & Output
• Stability: Excellent Long-term stability 0.05% of span/year

• Brand Name: TIPL
• Power Supply: 18-36VDC
• output signal: 4 - 20mA/RS485
• Model Name/Number: K-GP/AP
• Accuracy: 0.1% / 0.25% / 0.5%
• Operating Range: 50 k Pa - 100 M Pa

• Type: Temperature Data Logger
• Material: Aluminum, Cast Iron, Plastic, Stainless Steel
• Weight: 100-200gm, 200-300gm, 300-400gm, 400-500g
• Color: Brown, Green, Grey, White
• Voltage: 3-6VDC, 6-9VDC, 9-12VDC
• Condition: New, Used
• Application: Industrial
• Display Type: Digital
• Power Source: Battery, Electric
• Feature: Accuracy
• Warranty: 1Year, 2Years
• Automation Grade: Automatic, Fully Automatic, Manual, Semi Automatic

Apfc Panels, Electrical Panels, Electrical Switchgear Parts, Apfc Panels

• Type: Thermocouple
• Material: Stainless Steel
• Length: 2.5mtr, 3.5mtr
• Color: Metallic
• Application: Industries
• Power Source: Electric
• Feature: Durable, Fine Finished

Ceramic thermocouples have a Wide range, specially ceramic sheath with a protection sheath of SS grade tube material as knowing holding sheath which is used as mounting & protection of ceramic sheath, Ceramic thermocouples are specially manufactured for high temperature as continues temperature measuring this type thermocouple are used in Ceramic & Glass industries.  Detail Type “R” (Pt.Rh.13% - Pt.) and Type “S” (Pt.Rh.10% - Pt.) are used to measure temperature up to 1600°c Maximum. Thermo element pair is protected by two or three ceramic sheaths of various types depending upon working temperature and environmental conditions. Ceramic protection tube type KER 610 –with 60%, 80% Al2O3. Type KER 710 –recrystalised – high alumina tube with 99.9% Al2O3 available in 24 mm, 20 mm, 15 mm, 12 mm, 10 mm dia. Holding tube made of SS304 are used to hold ceramic sheath with head complete with ceramic terminal block with nickel plated terminals.

MI Thermocouple cables (Type K,J,N) SimplexDuplex in SS316, SS310 or Inconel 600 Sheath in Dia 1 to 8mm is available. Copper Sheathed Compensating MI Cable (for type RS thermocouples) & SS Sheathed MI RTD Cables are also available.

Temperature Transmitters, Temperature Element, gas analysis equipment

PCC Panel, Ship Wiring Cable, plc programming

APFC Panel, Power Distribution Panel

Access Control System, Avazonic HQIS Dome Camera, IP Cameras

High Temperature Thermocouples, Digital Temperature Indicator

pyrometer, Sensors, Rtd Temperature Sensor, Thermocouple, pid controllers

Flameproof RTD Sensor, Cast Iron Thermowell, Aluminum Bath Thermocouple

Electrical Control Panels, Electrical Control Panel
