Flexible Control Cables Dealers in Alwar

Flexible Control Cables

Get Price Quote

Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• PVC Insulation• Cores twisted• PVC outer sheath, grey   Standard References BS EN 50525-2-51 DIN VDE 0285-525-2-51 BS EN 50288-7 Special Features Low bend diameter Highly flexible Space saving construction Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads

Flexible Control Cables

Get Price Quote

Cable Structure• Class 5 bare copper conductor as per IEC 60228 and IS 8130• ZHLS Insulation• Cores twisted• ZHLS inner sheath, black• ZHLS outer sheath, black   Standard References IEC 60502-1 Special Features Low bend diameter Flexible Execllent fire retardance Low halogen content Excellent electrical properties Good oil resistance Low smoke and toxicity Improved mechanical strength and abrasion resistance Application Range Industrial machinery and air conditioning systems For general purpose installations in dry environment subjected to low mechanical loads Areas where human or animals are present Tunnels and transportation Suitable for outdoor installations Suitable for power applications Suitable for direct burial Technical Data Temperature Range  -15°C to +70°C Nominal Voltage  0.6/1.0kV Test Voltage  3000V Insulation Resistance  Min. 200Mohm-km Min. Bending Radius  8 x cable dia Short Circuit Temperature  Upto 160°C Flame Retardance  As per IEC 60332-1
