Amarjit Scientific India Punjabi Mohalla, Ambala, Haryana

Microscope frame for transmission and reflection mode polarization microscopy with built-in filter holders, High Power LED Light with power supply, High Power LED light with power supply Built in Transmitted light filters, Minimum 4 position centrable & detachable nosepiece , Stroke: Min 22mm. Fine Stroke: Min 100µm Minimum.

Binocular version with 45 degree inclined monocular tube rotate-able through 360 degree. Interpupilary distance adjustment ring 54-74 mm & dioptric adjustment, All part pressure die cast to provide long life and good mechanical strength.Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation.

The monocular version with 45 degree inclined monocular tube rotate-able through 360 degree, All part pressure die cast to provide long life and good mechanical strength, Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation, 4x,10x,4045x (s. L. ), 100x oil immersion (s. L. ).

Stage Fixed square stage 120 x 120 mm  size with mechanical stage having travel range 30 x 76 mm with graduated scales and vernier. Illumination Plano concave mirror on gimble mount. Optionally available attachable 20w lamp for 220v or 6v, 20w with transformer.

Para focal, precentred, high numerical aperture, high resolution, Para focal, precentred, high numerical aperture, high resolution, All metal constructed body with properly balanced , inclinable arm up to 90 degree for easy viewing, Separate coarse fine focusing knobs, Full square stage 112 x 112 mm size with stage clips.

Technical specification OPTICS:a. Apochromatic Optics with five step magnification changer.b. Magnification Range 2.4x-40x or morec. Max Field of view should be more than 180mm.OBJECTIVE:a. Working distance f=250 mm and 400 mm.b. Fine focusing for 300 mm.BINOCULAR TUBE:a. Inclinable binocular tube f=170 mm or higher.b. Inter pupillary distance adjustment from 55 mm to 75 mm.EYEPIECES:a. Pair of wide field push-in eyepieces 10x or 12.5x with rubber sleevesb. diopter setting -5D to +5D. ILLUMINATION:a. Coaxial fiber optic / direct Xenon or LED illumination system.b. In LED equipped systems: single lamp.c. Dual lamp system with quick change over in case of Xenon.d. Continuously lamp intensity adjustment by control knob near to the surgeon.STAND:a. Stable and sturdy floor stand on four lockable castors, column (height: minimum 1.6m).b. Spring-balance articulated arm, carrier arm, power supply unit.OTHERS:a. With lateral Handgrips for all knobs, dust cover.b. integrated full HD (1080p) camera & full HD recording system. Camera should have play back function for videos & photoc. Microscope is CE Marked & ISO Certified

A versatile dissecting microscope for demonstrations, close study of small organism and fine dissection work. A high-eyepoint lenses 10x and 20x magnification, which can be comfortably used by spectacle wearers, are mounted on a jointed arm allowing the whole stage area to be scanned. The wide glass stage has two spring clips and a reversible substage mirror/opal face illuminator giving good lighting of objects in daylight or under artificial light. The rack and pinion mechanism is enclosed within the stage support pillar and operated by a knob on either side of the pinion spindle. Detachable rests on either side of the stage provide a steadying support for hands during fine dissection. A wooden storage and carrying case with fitting for lenses, hand rests and microscope. Dimension overall height 180mm. Stage 70 x 90 mm.

Binocular observation head inclined at 45°, rotateable through 360°, interpupilary distance adjustment ring 54-74mm, dioptric adjustment ring on the left having adjustable dioptric scale. All part die cast to provide long life & good mechanical strength. Coaxial focusing control with ball bearing guide way & large knobs. Pre focusing auto focusing lock & tension adjustment ring, High eye point wide field 10x, (f. N. 20) or 15x paired.
