Capacitance Decade Box Dealers in Ambala

High quality standard laboratory tool to fulfill the requirement of different values of standard capacitance. Each dial consisting of 10 steps.

Decade Capacitance Box ABBOMEDTM High quality standard laboratory tool to fulfill the requirement of different values of standard capacitance. Each dial consisting of 10 steps.

• Voltage: 250 volts

Capacitance Box Single dial, compact size, housed in metal box with dial and knob. Connections through 4mm socket terminals. Accuracy ± 2.5 %.Maximum voltage 250 volts d.c. 10 nF to 100 nF in steps of 10 nF

DESCRIPTION : Comprising 12 non-polarised and capacitors ranging from complete 100pF to 0.47F(470 F) using standard preferred values, in step ratios of approximately 1:2 Selection is by means of a rotary switch and external connection is via a pair of 4mm sockets. All capacitors are of ± 2% tolerance,250VD.C.Working with values as follows: 100pF,001 F,0022 F, .0047F,.01 F,.022 F, .033F,.047 F, .1F, .22 F, .33F,.47 F

4 Dials , Standard RangeX .001, .01, .1 & 1 MFD      Range .001 MFD  to 11.11 MFD, 250V Max.  All are polyester capacitorsAccuracy  +  1 %

Decade Capacitance Box  5 DAIL   TECHNICAL SPECIFICATIONS:   ·   Capacitance box contains 6 dials for each Capacitance value between 100pF to 10uF. ·   Capacitance box contains each capacitor of 25V with 1% tolerance. ·   Each resistance will be selected by band switch and after each step Capacitance will be added to previous one. ·   One pointer knob is mounted on band switch for selection and to point capacitance value on trainer. ·   Can be find any value of Capacitance between 100Pf  to 10uF. SALIENT FEATURES: ·   Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols. ·   Instruction manual. ·   Instrument Fitted in Metal Box. ·   Instrument Dimensions: 18’’x4’’ ·   Connections are brought out through 4mm banana terminals.

• Voltage: 250 V DC (max.)
• Box : Plastic: 14 x 10.5cm (L x W) approx.

Capacitance substitution box offers selectable values of 220, 470, 1000, 2200, 4700, 10000 pf; 0.022, 0.047, 0.1, 0.22, 0.47, 1.0 µf. The device is housed in plastic box with 4mm safety sockets.

Useful as an oscillator element, wave shaping and resonance experiments, bridge experiments. Designed with pot core stability for standard laboratory use.

• Voltage: 250 volts

CAPACITANCE BOX Fitted in compact metal case, single dial, and knob. Connections through 4 mm socket terminals Accuracy + 2%. Maximum voltage 250 volts d.c.

Use of Capacitance Decade Box: A decade Box is a test equipment which uses resistors, capacitance or inductors to get the specific electrical values. Technical Specifications : Range : 100pF to 11,111µF ( 100pF per step ) Accuracy : 5% capacitors used throughout With five decades of capacitance Voltage limit : 50V DC, non-polarized capacitors Internal residual capacitance : 50pF Accurate and reliable performance Slide switches to allow the user to simply add or subtract for desired value Terminals with multi way binding posts, one to switch shield case ABS plastic housing case, rugged components

• Material: Aluminum, Brass, Metal
• Certification: CE Certified, ISO 9001:2008
• Application: Electronic Use
• Voltage: 110V, 220V
• Display Type: Analog, Digital
• Phase: Single Phase, Three Phase
