Fluorescent Microscope Dealers in Ambala

• LIGHT SOURCE: 12V, 20W halogen illumination

Infinity Optical System (IOS) Siedntopf observation head inclined at 30degree rotatable at 360degree. IPD 55-75 mm, with Diopteric adjustment EYEPIECEWide field eyepiece 10X (Paired) FOV 22mm OBJECTIVES INFINITY CORRECTEDFluorescence objective 4X                                  Fluorescence objective 40X (SL) Fluorescence objective 10X  Fluorescence objective 100X (SL) Oil MECHANICAL  BODY Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION. ABBE condenser NA 1.25 ADJUSTMENT RING. Reverse Angle quadruple nosepiece on ball bearing. Mechanical stage is 185mmX142mm. The Mechanical stage has low positioned co-axial controls on ball bearing guide ways. Epi - Fluorescent illumination : Blue Excitation Light Filter System (400-490nm) Standard                     Green Excitation Light Filter System (510-550nm) Standard100 WHBO Ultra Hi-Voltage Spherical Mercury Lamp, with power supply.Transmitted 6V/30W Tungsten Halogen bulb. Protection Barrier to Resist the Ultra Violet Light with Power Supply & four Fluorescence Free objectives: FL 4X, FL 10X, FL 40X (S), FL 100X (S, Oil). The Epi-Fluorescent attachment can be flexibly equipped with ordinary microscope to be an Epi-Fluorescent microscope. The Fluorescent microscope is used to detect becteria and antigens, early diagnosis of cancer, venereal diseases, immune less diagnosis, examination of botanical materials and the study of viruses etc.

We are engaged in manufacturing, exporting and supplying premium Fluorescent Microscope in Ambala Cantt. (Haryana). Our Fluorescent Microscope has zero aberration and excellent visual clarity. Fluorescent Microscope that we offer is made from good quality components which create its high demand in the market. We can deliver bulk consignments of Fluorescent Microscope in the market.

Centered on the theory of incident light, the design of our fluorescent microscope makes it extremely popular among the clients. The fluorescent microscope is used extensively for research and study in a variety of fields like hematology, biology and cytology to mention a few. Our fluorescent microscopes are precision engineered. technical specifications eye piece 10x 18mmobjectiveachromatic 4x, 10x, 40x, 100x fl-10x, fl-40x and fl-100x spring loadedfluorescent illuminationex490 mm (blue)ex545 mm (green) exciting light filter system, o ordinary light systemabbe na 1.2 uv protection screeninterpupillary distance 55-75 mmdouble plate low position coaxial stageillumination halogen lamp hg hbo-100w mercury lamp 220-230v 60hzoprecise ball bearing quadruple nosepiece

We design highly advanced Fluorescent Microscope that is based on the theory of incident light on the focus. We are well reckoned as one of the key Inverted Fluorescent Microscope Manufacturers and suppliers based in India. Our Inverted Fluorescent Microscope is ideally suited for study and research applications in the domain of biology, cytology, hematology etc Specifications Fluorescent illumination : Ex490 mm (Blue), Ex545 mm (Green) exciting light filter system, O ordinary light System, Interpupillary distance 55-75 mm Eye piece : 10x/ 18mm Precise Ball Bearing Quadruple Nosepiece Objective : Achromatic 4x, 10x, 40x, 100x FL-10x, FL-40x and FL-100x Spring Loaded Abbe NA 1.2 UV protection screen : Stage : Double Plate low position coaxial illumination Halogen Lamp, HG HBO-100W Mercury Lamp 220-230v / 60HzO

Microscope with universal infinity corrected system for brightfield, fluorescence applications and should be useful to dic applications later, built-in-kholer 6v /20w halogen illumination for transmitted light with light preset switch, light intensity led indicator, built in filters (nd6, nd25 etc) & hg hbo-100w mercury lamp attachment for reflected light fluorescence application and filter set for blue excitation. .

We are offering kfl 30 binocular fluorescent microscope. c shaped , infinity optical system (ios) siedentopf binocular tube, 30° inclined, 360° rotatable, ipd 55-75 mm, with dioptric adjustment on left ocular wide field eyepiece wf 10x22mm paired with eye guards infinity fluorescent objectives 4x, 10x, 40x (spring loaded) and 100x (spring loaded, oil immersion) quintuple reverse angle nosepiece (ball bearing type) stage rectangular 180 x 148mm double plate with mechanical stage cross travel 76 x 50mm on ball bearing with co-axial control, spring clip double slide holder sub-stage abbe condenser na 1.25 with aspheric lens. iris diaphragm and special day light blue filter, mounted co-axial coarse and fine focusing mechanism with tension control and unique auto focus lock illumination system 6v-20w halogen with intensity control. Universal power supply (100v-240v) iso 9001, ce approved. epi fluorescent attachment the epi-illumination is through 100 watt high pressure mercury lamp in a lamp house attached to the fluorescence filter block. The exciting light spectrum range is 350mm – 580mm. The fluorescent light spectrum range 420mm – 650mm technical features two exciting light waves b (blue light) and g (green light) comprising of : exciting filter (ex) comprising of - blue light (ex-490), green light (ex-545) color separation prism (dm) comprising of - blue light (ba530), green light (ba590) position of ordinary transmission light (central) illumination box with power supply unit 220 volt & hbo, super high – pressured spherical mercury vapor lamp 100w. Orange coloured plastic screen to safeguard the operator from uv light.

siedentopf trinocular observation head inclined at 30o and 360o rotatable. Diopter adjustment ring on ocular tube. Interpupillary distance from 53 to 75mm. Wide field eyepiece 10x (paired) fov 22mm anti-fungal and with eyeguards. reverse angle quadruple (4-position) nosepiece revolves on ball bearing (tilted backwards). Soft rubber knurled grip on nosepiece. Fluorescent infinity plan achromatic objectives 4x/ 0.10.10x/ 0.25.40x/ 0.65.100x/ 1.25 double layer graduated mechanical rectangular stage with size 210mmx140mm (better), cross travel 75(x) x 50(y) mm on ball bearing co-axial controls, driven right and spring clip specimen holder, on left. Low position co-axial coarse and fine focusing control on ball bearing guideways with pre focusing lever & tension adjustment ring. substage abbe condenser centerable, na 0.9/1.25 with aspheric lens. The epi-illumination is through led illumination. The fluorescent light spectrum range 420mm – 650mm. One exciting light waves b (blue light)  comprising of : exciting filter (ex) comprising of - blue light (ex-490) color separation prism (dm) comprising of - blue light (ba530) position of ordinary transmission light (central) illumination box with led lamp, power supply unit 220 volt orange coloured plastic screen to safeguard the operator from uv light. Universal power supply (ac input 85v~265v, 50/60 hz). packed in moulded styrofoam box with instruction manual, cleaning cloth, dust cover, mains cable. 3 year warranty, european ce approved.-optional accessories: wf 20v fov 16mm. Provision for extra filter block uv & v. 5megapixel cooled ccd color live camera, resolution: 2-5 megapixel,  power: usb bus  bit depth: 12-bit digitization and processing / 012-bit rgb uncompressed output  mater clock: 24mhz  enclosure: die cast aluminum  microscope interfacing: stainless steel c-mount  sensor technology: ccd  pixel array: 1600 h x 1200 v  sensitivity: 31.0 dn/(nj/cm²) at unity gain with ir filter pixel size: 4.4 μm x 4.4 μm  signal-to-noise ratio: 65db  imaging area: 7.04mm x 5.28mm; 8.8 mm diagonal (1/1.8”)  electronic shutter type: global  frame rate: 8.2 fps at full resolution  maximum exposure time: 419 seconds  os compatibility: 32- bit and 64-bit window 7. 32-bit window vista and xp,ir filter: bp680  video attachment 0.45x, c-mount adapter for use with tv cameras on trinocular head and photoport, with factor 0.45x  holder  to fix video attachments image analysis software

• Application: Forensic Lab, Science Lab
• Weight: 0-500gm, 1-3kg, 3-5kg, 5-10kg, 500gm-1kg
• Color: Black, Creamy, Dark Grey, Grey, White, Z-Black
• Condition: New, Used
• Power: 100W, 10W, 1Kv, 200W, 20W, 500W, 50W, 5W
• Driven Type: Battery, Electricity
• Feature: Actual View Quality, Contemporary Styling, Durable, Easy To Use, Good Griping, Power Angle View, Traditional Bushnell, Uv Protective
• Warranty: 1yrs, 2yrs, 5yrs
• Portable Style: Non Portable, Portable

We are offering fluorescent microscope. Specifications: optical system - infinite optical system . viewing head- compensation free trinocular head inclined at 30â°, interpupilary 48-75mm . eyepiece wf 10x18 . nosepiece- backward quadruple nosepiece

Monitoring the ongoing latest market developments, we are involved in offering a wide range of Multi Viewing Microscope. Offered microscope is mainly used to view single sample by multiple users at the same time. This microscope is manufactured by our skilled professionals using quality-assured components that are procured from reliable sources of the market. Further, this Multi Viewing Microscope is made available in different standards and custom made designs as per client diverse requirements. Features: Can easily rotate Provide clear view of image Equipped with night bulb Smooth coaxial knob for focus adjustment

• CODE: RFM-1

Fluorescence Microscopes in which the advanced principle of incident light excitings is employed, offers bright & clear fluorescence imaging and good contrast. It is an ideal instrument for research of Biology, Tumology, Cytology, Immunology, Haematology, Venereal Disease examination, Fluorescence microscopy etc. At the same time, it is also used in following ranges, such as analysis of sedimentary rock, inspection of impurity of semiconductor, environmental protection and microchemistry.

FLUORESCENT MICROSCOPE : JS-51 Fluorescent Microscope is used for capillary examination. This technique is a new, highly sensitive rapid method of diagnosing malaria. It is also useful in the diagnosis of filariasis and leptospirosis. The principle of this method is the malaria parasite picks up fluorescent stain into their nucleus and cytoplasm, so that its morphologic characteristics can be examined by fluorescent microscopy.The nucleus appears green and the cytoplasm reddish orange, The Capillary is coated with Acridine orange on its inside. Parents Blood is loaded into this capillary and centrifuged at 12000 rpm for 5 minutes. The Blood components settle at different levels in the capillary. These different layers are displayed in the picture.Examination of the area just below granulocyte-RBC junction helps to detect the malarial parasites, as these are concentrated in this are upto 1000 times. Examination of Lymphocyte / monocyte layer using transmitted light helps to detect the schizonts, and gametocytes which gets concentrated in this layer very easily. Method of Examination:The granulocyte layer is then seen under 62x oil objective. By changing the light source to fluorescent light the parasitic forms can be seen as greenish orange stained structures. Using only transmitted light the parasitic forms are seen as block pigmented structures as shown in the preceding photomicrographs. Additional Information: Item Code: JS-51 Pay Mode Terms: T/T (Bank Transfer) Packaging Details: This microscope we prefer for the personal delivery and the demonstration but still if it is not possible then it is securely packed in two different thermocol boxes.

Fluorescent Microscopes, Binocular Microscopes, projection systems

Fluorescent Microscopes, Binocular, Binoculars, Fluorescent Microscope

We are offering fluorescent research microscope. microscope with universal infinity corrected system for bright field, fluorescence applications and should be useful to dic applications later, built-in-kholer 6v /20w halogen illumination for transmitted light with light preset switch, light intensity led indicator, built in filters (nd6, nd25 etc) & hg hbo-100w mercury lamp attachment for reflected light fluorescence application and filter set for blue excitation. Ex490nm (blue), ex545nm (green) exciting light fitter system, o ordinary light system, interchangeable trinocular with inclined 30 degree for observation, ceramic coated scratch proof co-axial stage with left or right hand low drive x & y control with torque adjustment, universal abbes condenser for bright field,applications & uv protection screen

Fluorescent Microscope, Uv Spectrometer, science microscope
