High Pressure Autoclave Dealers in Ambala

• Thickness: 10-15mm
• Packaging Type: Carton Box
• Usage: Laboratory Use
• Specialities: Corrosion Resistance, Accuracy Durable
• Chamber Volume: 5-10 Litre
• Material: Stainless Steel
• Color: Silver

Optional :  Automatic low-water level cut off-device. Pressure Control Switch.

• Type: Vertical
• Material: Stainless Steel
• Certification: CE Certified
• Color: Metallic
• Voltage: 240V
• Surface Finishing: Power Coated
• Power: Kw
• Application: Laboratory Use

A versatile, electrically heated sterilizer under saturated steam of Adjustable pressure of 10 to 20 psi. double walled construction with boiler & steam jacket made of thick stainless steel and gap is filled with high grade glass wool to bring the temp. loss to a minimal level.The outer chamber is made out of thick mild steel.The lid is made of thick stainless steel plate (joint less) or gunmetal plate and can be sealed by a jointless neoprene rubber gasket by wing nuts through hinged bolts by engaging slotted lugs on rim of the cover. Provided with dial pressure gauge, air steam release cock, spring loaded safety valve adjustable to any required point from 10 psi to 20 psi with accuracy + 3 psi. A drain cock has also been provided. A double safety valve has also been provided along with inlet. Supplied complete but without dressing bins. but presented in a horizontal position and without steam jacket. The outer body made of mild steel, inner chamber made of stainless steel.

A versatile, electrically heated sterilizer under saturated steam of Adjustable pressure of 10 to 20 psi. double walled construction with boiler & steam jacket made of thick stainless steel and gap is filled with high grade glass wool to bring the temp. loss to a minimal level.The outer chamber is made out of thick mild steel.The lid is made of thick stainless steel plate (joint less) or gunmetal plate and can be sealed by a jointless neoprene rubber gasket by wing nuts through hinged bolts by engaging slotted lugs on rim of the cover. Provided with dial pressure gauge, air/ steam release cock, spring loaded safety valve adjustable to any required point from 10 psi to 20 psi with accuracy + 3 psi. A drain cock has also been provided. A double safety valve has also been provided along with inlet. Supplied complete but without dressing bins. Chamber Size & load            Capacity (approx.)   Dia x Depth   a. 250x450mm    2KW                    22ltrs.   b. 300x500mm    3KW                    40ltrs.   c. 350x550mm    4KW                    50ltrs.   d. 400x600mm    5KW                    78ltrs.   e. 450x600mm    5kW                     98ltrs.   f. 550x750mm     6kW                  152ltrs.   Optional:-   i) Automatic low-water level cut off- device.   ii) pressure Control switch.   iii) Water lever arrangement.   iv) Dressing bins for various size.

• Chamber Volume: 20-25 Litre
• Material: Aluminium
• Voltage: 220 V
• Frequency: 50 Hz
• Phase: Single
• Pressure Range: 15 psi to 18 psi
• Brand: Avni Scientific Co.
• Usage/Application: Laboratory
• Diameter: 300 x 300mm

• Material: stainless steel.
• Capacity: 152 ltrs.
• Chamber size (dia. X depth): 550 x 750 mm
• load: 6 kw
• Modal: AE-145A

High Pressure Autoclaves (Vertical) (DIV-077) AUTOCLAVE ALUMINIUM (STERILIZER) VERTICAL PRESSURE TYPE TURNING TYPE NON-ELECTRIC ELECTRIC *Autoclave Aluminum (Sterilizer) Vertical Pressure Type Seamless. *Sterilizing Temperature 120° C-131° C. *Sterilizing Time 25-30 Minutes or As Desired. *Heating Element 2000 Watts, 220240 Volts AC. DIV-077-Capacity: 21 Ltrs. DIV-081-Capacity: 24 Ltrs. DIV-086-Capacity: 26 Ltrs. DIV-095-Capacity: 30 Ltrs. DIV-104-Capacity: 37 Ltrs.

• Brand Name: SCIENTICO
• Place of Origin: Haryana, India
• Instrument classification: Class I, Class II, Class III
• Supply Ability: 1000 Piece/Pieces per Month
• Packaging Details: hard wood packing
• Properties: Medical Materials & Accessories

• Autoclave - vertical and horizontal: Horizontal High Pressure Double Wall Autoclave

We are a leading manufacturer, exporter & supplier of high quality triple wall vertical high pressure autoclave. Also offering autoclave, autoclave portable, autoclave anaerobic jar & vertical autoclave, rectangular autoclave,pressure cooker type autoclave, vertical autoclave double wall , vertical autoclave triple wall. Horizontal high pressure double wall autoclave rectangular high pressure double wall autoclave. Triple wall construction i.e. Working chamber, water chamber and outer jacket made from high grade stainless steel with mirror finish . Lid made of heavy duty stainless steel plate. Having appropriate pressure gauge, stop cock , safety device, steam release valve, water inlet and outlet valves. Fitted with water level indicator and comes with stainless steel basketand low water cutoff device & pressure control switch .

• Chamber Volume: 10-15 Litre
• Material: Stainless Steel
• Shape: Vertical
• Usage/Application: Laboratory
• Insulation Wall: Single Wall
• Automation Grade: Fully Automatic
• Power Consumption: 3 KW
• No. Of Trays: 1 Tray
• Product Type: Autoclaves
• Features: Sturdiness, Resistance to corrosion, Flawless performance

High pressure vertical steam sterilizer is used for sterilizing, surgical instruments dressing materials linen rubber, plastic material by means of saturated stream under pressure of 15 to 20 P.S.I. (adjusted) apart from health services it is also used in scientific research laboratories, educational institutions and universities. The triple wall unit has inner chamber steam jacket and outer wall made of S.S. duly argon arc welded. The space between outer wall and steam jacket is filled with high grade glass wool to minimize the temperature loss, all sterilizers are hydraulically tested up to 40 P.S.I the lid is made of thick S.S./ gunmetal and closed by wing nut type closing arrangements fitted with a gasket made of neoprene rubber, water level arrangements to indicate water level, pressure gauze , steam release cock , spring loaded safety valve which can be set at any selected point from 10 P.S.I , +_ 3 P.S.I and drain cock.. Supplied complete with cord and plug to work on 220 volt. 50 Hz. AC supply. Available in following sizes.  Dia x depth. Load a)250 x 450 mm. 1.5 K.W. b)300 x 500 mm. 2.0 K.W. c)350 x 550 mm 3.0 K.W. d)400 x 600 mm 4.0 K.W.

• Brand Name: Jlab
• Model Number: Jlab1011
• Place of Origin: India

Construction: - Triple walled construction, all the three walls are made of thick high grade stainless steel sheet of SS-304 grade. The lid is made of stainless steel sheet. The unit is fitted with radial locking system with paddle lifting device, made of MS chrome plated. Provided with built- in safety valve, pressure gauge, pressure release valve and water level indicator. The pressure is adjustable from 5 psi to 20 psi with automatic pressure control switch, which controls the pressure with an accuracy of +- 1 psi. Supplied complete with stainless steel basket, chord and plug. Mode of Heating: - Electrically heated by special flange typeimmersion type heaters bearing ISI mark, to work on 220 volts single phase 50 cycles. Working Pressure: - The pressure inside the chamber is variable from 5 psi. to 20 psi. But the normal recommended pressure for sterilization process is 1.2 kgfcm sq.g ( 15 psi - 17 psi). Working Temperature : 121° C . Hydrotest Pressure : 2.5 kgfcm sq.g ( 35 psi).

• Brand Name: Vinayak Enterprises
• Shape: Vertical
• Chamber Volume: 10-15 Litre
• Insulation Wall: Single Wall
• Automation Grade: Fully Automatic
• Usage/Application: Laboratory
• Power Consumption: 2 KW

• OPTIONAL: 1. Automatic low-water level cut off-device., 2. Pressure control Switch.Etc

AUTOCLAVE VERTICAL HIGH PRESSURE (TRIPLE WALLED) (PSAW-145A) Most useful for sterilizing the loaded material under a steam pressure of 10 to 20 psi (adjustable). It has inner chamber, steam jacket and outer wall made of S.S. duly argon arc welded. The space between outer wall and steam jacket is filled with high grade glass wool to minimize the temperature loss. The lid is made of thick stainless steel and closed by radial type closing arrangement. Fitted with a gasket made up of neoprene rubber, safety value. Drain cock, water inlet, water level indicator, steam release value, pressure gauge, pedal lifting device and S.S. basket. Supplied complete with cord and plug to work on 220440 volt A.C. Supply. And supplied without dressing bins. Chamber Size Load Capacity in Dia x Depth (Approx.) 250x450mm 2KW 22ltrs. 300x500mm 3KW 40ltrs. 350x550mm 4KW 50ltrs. 400x600mm 5KW 78ltrs. 450x600mm 5KW 98ltrs. 550x750mm 6KW 152ltrs.

TAI-907 HORIZONTAL RECTANGULAR HIGH PRESSURE AUTOCLAVE
