Horizontal Laminar Airflow Dealers in Ambala

• Material: Stainless Steel

Details :  Switches : Microprocessor based switches for blower, LED light & UV light With LCD back light display. (UV light with Timer) Pre-filter : 99.00% down to 5 micron. HEPA Filter : ISO 14644 Class5(Class100) 99.97%-99.99% down to 0.3 micron. Mesh guard for protection of HEPA filter. Airflow : Frontward Horizontally Noise Level : 60 decibel ± 5%. Velocity : 0.35-0.50m/sec. Work Table : Made up of stainless steel 304gr. Cock for gas on work table. Side Panels : 6mm±.5mm thick acrylic sheet. Front door : Made of acrylic. UV Lamp : 15/30W, make Philips Holland, Illumination : LED White Light. Pressure : Digital Manometer 0-50mm range with filter failure alarm. Power Supply : 230V ± 10V/50 Hz single phase A.C. Cabinet : Stainless Steel 304 grade. Heavy Duty Blower : Dynamically balanced with 0.25 HP Electric Motor Mounted on anti vibration pad 1440 RPM motor.

• Working Chamber Size: 2 ’x 2’ x 2'

Laminar Air Flow Horizontal of air through coarse pre- filters (upto 5 microns) and Hepa filter (down to 0.3 microns) for filteration of biological and particulate contaminants. A constant uni-directional air flow is drawn from atmosphere and passed through pre and hepa filters on the work surface. Fabricated out of reinforced ply board which is clad in from out side laminated sheet and inner exposed areas are finished in epoxy paint. Table top covered with non-glaring laminated sheet or stainless steel sheet (optional). Side panels are fixed and are made out transparent acrylic sheet. The front door is folding type and made of thick acrylic sheet. (optional) Stand is built in type or detachable. Blower unit has AU or equilavent motor and is dynamically balanced with minimal sound & vibration level. Fluorescent lighting is also provided. A suitable UV tube is provided for sterilization. An acrylic block type manometer to measure static pressure in the chamber has been inustalled.Two way gas tap for gas line has also been provided

  Clean Air Equipment provides dust free environment ideal for Tissue Culture, Microbiology, Biotechnology, Pathology Labs, Pharmaceutical & Electronic industry. Technical Specifications: To provide clean air to working platform horizontally. Sturdy-Duraboard-construction Elegant Sunmica finish Silent motor & blowers Vibration free unit Stainless steel working platform HEPA filter efficiency 99.97% down to 0.3 micron Pre-filter efficiency 99% down to 5 micron UV germicidal lamp 15W/30W Fluorescent illumination Static pressure manometer Cock for gas Foldable acrylic transparent door Plastic grill for protection of HEPA filter Removable covers to attend motor-blower-filters Sizes: 60 x 60 x 60cm 90 x 60 x 60cm 120 x 60 x 60cm 180 x 60 x 60cm Other models also available are given below: Laminar Air Flow Portable Laminar Air Flow Vertical Inoculation Chamber Laminar Air Flow Horizontal M.S. Laminar Air Flow Horizontal S.S.

Switches for Blowers, Flourescent light & UV light. · Pre –filter 99.00% down to 5micron. · HEPA Filter ISO 14644 Class 5 (Class 100) 99.97%-99.99%   Down to 0.3 micron. Mesh guard for protection of HEPA filter. · Airflow Frontward Horizontally. · Noise Level 60 decibel ± 5%. · Velocity 0.35-0.50m/sec. · Work Table Made up of Stainless Steel 304gr. Cock for gas on work table. · Side Panels 6mm ± .5mm thick acrylic sheet. · Front door made of acrylic. · UV Lamp 15/30W, make Philips Holland. · Illumination 20/40W, Flourescent tube with diffuser. · Pressure inclined Manometer 0-50mm range. · Power Supply 230V ± 10V/50Hz single phase A.C. · Cabinet made of 19mm thick Duraboard covered with sunmica from   outside and epoxy painted from inside. · Heavy Duty Blower Dynamically balanced with 0.25HP   Electric motor mounted on anti vibration pad 1440rpm motor. Model Particular LIC-05 Size 60x60x60cm LIC-06 Size 90x60x60cm LIC-07 Size 120x60x60cm LIC-08 Size 180x60x60cm

• Material: S S 304
• Size: 4x2 inch
• Usage/Application: Laboratory
• Air Flow: He.pa filter
• Height: 5 fit

• Brand Name: BSE
• Power Supply: 200
• Material: Mild Steel
• Air speed: 0.3-0.6m/s
• Power: 20
• Frequency (Hz): 50hz
• Efficiency: 99.99%0.3um

We are a Manufacturer, Supplier and Exporter of Horizontal Laminar Air Flow. The range of Horizontal Laminar Air Flows offered by the company is manufactured using acrylic material of the best quality. We make Horizontal Laminar Air Flow available at the best prices in the market. In addition, these Horizontal Laminar Air Flows are ideally used in different industrial and laboratory applications. Features 19 mm thick board covered with sun mica from outsideWorkbench covered with stainless steelSides of workbench covered with transparent acrylic sheetFront acrylic door of collapsible typeProperly balanced blowers fitted on 1/5 H.P. electric motorStatic pressure manometer, cock for gasHEPA filter efficiency 99.97 to 0.03 micronPre-filter provided on the bottom to supply pre filtered air to the blowersOne fluorescent tube and one U.V germicidal tube provided over workbenchStatic Pressure manometer fitted on topBack cover fixed with screws for convenient removal for attending blowers, filters and motor when needed

Horizontal laminar flow made of full stainless steel top and body. Front panel made of toughened glass in two pieces one piece fix and the other sliding upwards. Build with U. V. Germicide light and white light and adequate illumination. Fitted with Hepa filter and pier filter. Hera filter efficiency rating 99. 9% downto 0. 3 microns. motor blower assembly. Cock for gas air or vacuum line. Pressure differential manometer. Working area 48″ wx24″ dx24″ h.

Horizontal laminar flow made of full stainless steel top and body. Front panel made of toughened glass in two pieces one piece fix and the other sliding upwards. Build with U. V. Germicide light and white light and adequate illumination. Fitted with Hepa filter and pier filter. Hera filter efficiency rating 99. 9% downto 0. 3 microns. motor blower assembly. Cock for gas air or vacuum line. Pressure differential manometer. Working area 48″ wx24″ dx24″ h.

Horizontal Laminar Airflow, Vertical Autoclave, Portable Autoclave

Horizontal Laminar Air Flow, Centrifuge Machine, Mercury BP Apparatus

Horizontal Laminar Air Flow, Binocular Microscope, laminar air flow vertical

Horizontal Laminar Air Flow, Bio Safety Cabinet
