Navyug Udyog Ambala Cantt, Haryana

ncubator bacteriological memmert type, Kjeldhal digestion & distillation units combined, Kjeldhal distillation units, Kjeldhal digestion units, Soxhlet extraction unit, Autoclave horizontal high pressure, Autoclave verticle, Autoclave portable, Vacuum pump oil free, Vacuum pump, Mortuary chamber, Rectangular centrifuge, Clinical centrifuge, Pipette washer automatic, Melting point app.microprocessor controlled, Melting point apparatus automatic microprocessor, Melting point apparatus, Tissue homogeniser, Laboratory stirrer, Magnetic stirrer with heating system, Water still table model, Water still, Egg incubators, Shaking machine wrist action, Rotary shaker vdrl rotator, Rotary shaker platform type, Reciprocating shaking machine khan rack type, Vortex shaker - cyclo mixer - test tube shaker, Drying oven industrial, Hot air oven universal, Oven vacuum, Orbital shaking incubator, Incubators bacteriological, Slide warming table, Hot plates, Hot plate rectangular, Rectangular muffle furnace (industrial model), Rectangular muffle furnace (laboratory model), Horizontal deep freezer, Deep freezer vertical upright, Fume hood, Bio safety cabinet, Dispensing sampling booth, Laminar air flow horizontal, Water bath incubator shaker, Refrigeration liquid bath-cooling bath, Oil bath (high temp.) with stirrer, Water bath paraffin, Water bath rectangular single wall, Water bath rectangular, Water bath tissue flotation, Serological water bath, Ultrasonic water bath, PRODUCT LIST Key Personnel Mr. Satish Kumar (MD) Mobile:+919416028014

SOXHLET EXTRACTION UNITS Without Glass Part : (MENTEL TYPE) Standard mild steel body and upright fittings. Body finished in stove heating paint and other parts duly chrome plated. Housing provided with heating mantels for surface temp. upto 300°C. Provided individual on-off switches & pilot lamps. 1. A unit of 3 mantels rating 600 watts. 2. A unit of 6 mantels rating 1200 watts. a) SOXHLET EXTRACTION UNITS : (Heater type ) Heaters have individual on-off switches & indicators. Provided with one common energy regulator to control all units. Without glass parts. 1. A unit of 3 heaters. 2. A unit of 6 heaters. b) SOXHLET EXTRACTION UNITS : (Hot plate type) As above but with hot plates. 1. A unit of 3 hot plates. 2. A unit of 6 hot plates c) SOXHLET EXTRACTION UNITS : (Bath type) (i) Single Wall Chamber made of stainless steel 1. A Unit of 3 Baths. 2. A Unit of 6 baths. (ii) Double Wall Inner Chamber Made of Stainless Steel. 1. A Unit of 3 Baths. 2. A Unit of 6 baths. Optional :- Sunvic Energy regulator can be provided with all above units

Double walled construction, inner chamber made out of thick highly polished stainless steel sheet and outer made out of thick mild steelduly finished in stoving enamel paint. The lid is made of stainless steel. The gap between the two chambers filled with glass wool to prevent loss of heat. The temperature is achieved by superior immersion heater and is controlled by capillary type thermostat from ambient to 90oC+ 0.5oC.The shaking mechanism is fitted with variable speed motor couple to shaking tray working on rollers.

Standard double wall fabrication. Inner chamber made out of richly anodized aluminium or highly polished stainless steel sheet and outer made out of thick mild steel sheet finished in white stoving enamel paint or mat finished pastle colour combinations. The gap is filled with special glass wool for temp. insulation. Double wall door with double window for observation in the chamber. Temperature range 5oC above ambient to 80oC + 2oC controlled by a thermostat. L- shaped thermometer is provided for taking temp. readings. Panel is provided with pilot lamps for mains & heaters, On-off switch, temp. Control knob etc. The equipment is workable on 220 V AC 50 Hz single pahse. Heating is achieved from 3 sides. Perforated removable shelves also provided

Useful for accelerated mixing of solutions in test tubes, small flasks or centrifugal tubes etc. The housing is 150x150 mm. The speed is regulated by a speed control device. Short eccentric stroke motor imparts vigorous agitation to the tubes or flasks. Body is strong and finished in stoving enamel paint. The equipment is workable on 220V AC 50Hz single phase.

Standard double wall fabrication. Inner chamber made of richly anodized aluminum or highly polished stainless steel sheet. Exterior fabricated out of thick mild steel sheet duly finished in stove enamel off-white paint or paste mat finish colour combinations. The gap between the walls is filled with-special grade glass-wool for heat insulation. Inner chamber is ribbed for placing shelves at convenient levels. Provided with two or three removable shelves. Special elegant door closing device has been provided. Nichrome wire heating elements -provided on three sides attain quick and uniform heating in range of 50oC to 250oC + 1oC controlled by capillary type thermostat.
