Penetrometer Dealers in Ambala

Semi Automatic Cone Penetrometer : Used to determine the moisture content at which clay soils pass from a plastic to a liquid state. Two Version are available. One the standard one & the other is semi-automatic with timer where the cone is allowed to free fall for a period of 5 seconds including one each of 50 gm. & 100 gm. weight, one penetration cone, preset counter & measuring cup.

• Model Number: ALPHA CHEM-1371
• Brand Name: ALPHA CHEM

Soil Cone Penetrometer : Alpha Chem is manufactures,exporter & suppliers Soil Cone Penetrometer. Soil Cone Penetrometer : For determining the liquid limit of soils. This is specially useful to obtain reliable and accurate results of those soil which have low plasticity index. The percentage moisture contents determined when cone with half angle of 15-30 minutes under a total sliding weight of 148 gm penetrates 25mm gives the liquid limit.

Static Cone Penetrometer, 30KN (300KGF) Capacity For Testing Lab     NAUGRALABS LABORATORY PRODUCT NAME: STATIC CONE PENETROMETER, 30KN (300KGF) CAPACITY FOR TESTING LAB NaugraLabs Laboratory Product Code: NLE-Export-116035 Description and Specification for Lab Tenders Static Cone Penetrometer 30KN (300KGF) Capacity.  The drive is by means of a rack and pinion manually through a gearing arrangement. The gear box and pinion are fixed on two handles, sprockets and chain arrangement. The movement of the rack is guided by a bracket ( attached to the rack) and two pillars. The penetration resistance i.e. the pressure is indicated on hydraulic gauges through a hydraulic measuring head. Two pressure gauges of 15cm dia dial and 2 capacities 0-160kg/cm are provided. An automatic cut-off valve, to protect the low capacity gauge from being overloaded is provided. The 2 valve can be adjusted and locked at desirable values between 20 to 60cm . A provision is made to anchor the unit to the ground (with the help of four anchors supplied with the unit) and there is a provision for lateral 2 movement of the unit so that subsequent tests could be performed without shifting the entire anchorage. A 10cm penetration cone with friction jacket is provided along with fifteen mantle tubes (non-uniform having an effective length of 1 m each with sounding rods for finding out the cone (point) resistance or jacket friction. civil lab equipments manufacturer   Soil Test Instruments Lab equipment manufacturers,exporters and Soil Test Instruments Lab suppliers

• Brand Name: SCIENTICO
• Supply Ability: 5000 Piece/Pieces per Month
• ANY: ANY
• Port: ICD,TKD

  Used to determine the moisture content at which clay soils pass from a plastic to a liquid state. Two Version are available. One the standard one & the other is semi-automatic with timer where the cone is allowed to free fall for a period of 5 seconds including one each of 50 gm. & 100 gm. weight, one penetration cone, preset counter & measuring cup.

• Cement and concrete testing lab: Mortar Mixer
• Cement and concrete testing lab: Pozzolana Cement Mortar Permeability Apparatus
• Cement and concrete testing lab: Pulveriser

It is used for finding out the rate of hardening of mortars sieved from concrete mixtures, by means of penetration needles of different cross-sectional areas. Salient features specifications :the instrument consists of a barrel housing a calibrated spring and a stem graduated from 0-70 kg x 1 kg. Six interchangeable penetration needles of areas 645, 323, 65, 32 and 16mm sq. Are provided. The penetration resistance is measured by the force exerted to penetrate the mortar by 25mm and is indicated by a sliding ring on the stem, which is graduated. Needle shanks are marked at every 12.5mm. Compete in a wooden carrying case.

• Material: Mild Steel
• Brand: Eletech-Eletech Lab Instruments
• Model No: ELI-1921
• Automation Grade: Manual
• Display Type: Analog
• Category: Civil Lab
• Tag: Universal Penetrometer

• Weight: 100 gm
• Diameter: 116mm
• Penetrometer: 590 mm

Soil Cone Penetrometer is used to determine the liquid limit of soils. It provides reliable and accurate results of soil with low plasticity index. The percentage of moisture contents can be determined by observing cone( half angle for 5 seconds under a total sliding weight of 100 gm )penetrates (25mm) giving the liquid limit.
