Photo Meters Dealers in Ambala

• Automation Type: Automatic
• Power Source: Electric

• Display: LED
• Usage/Application: Laboratory
• Size/Dimension: 475 x 285 x 130 mm
• Average Time: 10 Minutes
• Detection: Silicon Photodiode
• Flame System: LPG and Dry Oil Free
• Power: 220 VAC 50Hz
• Reproducibility: +/- 2
• Weight: 7.5 Kg
• Model No.: S- 931
• Counts Sensitivity: 5 ppm

• Country of Origin: India
• Type: Optics
• Certification: ISO 9001:2008 Certified
• Condition: New
• Certification: CE Certified
• Feature: Durable
• Application: To compare the illuminating powers (luminous intensities) of two given sources of light using Lummer-Brodhum.
• Voltage: 220V
• Finish: Polished

The unit is encased in a special aluminium case with standard stem of 9mm dia. It is fitted with high class optics. Light from two different sources falls on either side of a uniform opaque white screen. This light is reflected by side reflectors (Special prisms) and passes through the Lummer Brodhum cube. The field of view can be seen through a telescope and the light intensities are compared directly. The photometer is mounted in a swivel bracket for proper adjustment with two-nose lamp house & electric bulb is in a metal cased with cord & pin finished optical block.

Flame photometers digital flame photometer digital clinical flame photometer.

• Country of Origin: India
• Type: Digital Actophotometer
• Voltage: 220V
• Condition: New
• Driven Type: Electric
• Color: Black & White
• Usage/Application: Laboratory
• Shape: Rectangular
• Features: 4 Digit Counter

Microprocessor Flame Photometer With Sodium And Potassium (k) Filter.  ALPHA CHEM- 310 Microprocessor Flame Photometer With Sodium And Potassium (k) Filter. Readout: 24x4 line LCD display, auto ignition system, Detector: Silicon photo diode, Filter: Narrow Band interface Glass filters nebulizer: Bak Light, Axial Flow Type, Flame System: LPG and Dry oil free air., Up to 5 point calibration, direct read  out in ppm and mg/I, Auto filter selection, auto ignition, single aspiration, RS 232 interface, with   Power Supply: 230V+10%AC, 50HZ.   Optional: Ca & Li Filters can be Provided on extra cost.    • Alphanumeric 4 line Display

• Application: Laboratory
• Feature: Durable, Stable Performance
• Warranty: 1Years
• Model: GWL1010
• Dimension: 150 x 100 x 100 mm

Grease spot disc held between two wooden screens with 45 mm dia aperture, mounted with 2 inclined plane mirrors approx. 90 mm square.   Pin Hole Camera Two rectangular, open ended, light proof wood boxes. One slides into the other & contains a frosted translucent glass plate upon which image is formed. The other box has a pin hole opening at the closed end. Dimensions 150 x 100 x 100 mm approx. Also available as a kit.

We are offering actophotometer. Digital actophotometer (activity cage) is designed to study the spontaneous or induced or locomotors activity in small animals like mice or rates. In this apparatus, we have used the optical sensors and emitters to record the horizontal movements of the animals on a six digit digital counter display.

• Application: Laboratory Use
• Color: Grey
• Feature: Fine Finish
• Voltage: 220V
• Automatic Grade: Automatic
• Driven Type: Electric

• Automation Grade: Automatic
• Capacity: 0.5 ml.
• Weight: 7.5 Kg (approx.)
• Dimensions: 290 x 255 x 210 mm (L x B x H) (Approx.)
• Power: 230 VAC + 10% AC,50 Hz
• Atomizer: Axial Flow Type
• Curve Accuracy: <2% error when 3 ppm Na/K and 5 ppm, Li are set as maximum Standards
• Detection: Silicon Photodiode
• Flame System: LPG and Dry Oil Free Air
• Sensitivity: Na: 0.5 ppm, K: 0.5 ppm

• Brand: AMESYS INDIA
• Material: Aluminum
• Color: White, WHITE AND BLUE,WHITE AND BLUE,BLUE AND WHITE
• Automatic Grade: Automatic
• Application: Industrial
• Size: Multisizes
• Feature: Accuracy
• Voltage: 220V
• Operating Temperature: 50-100D/C
• Certificate: CE Certified
• Type: Digital Flamephoto Meter, DIGITAl FLAMEPHOTO METER,DIGITAL FLAMEPHOTO METER,DIGITAL FLAMEPHOTO METER
• Country of Origin: India
• Display: Local
• Warrenty: 1 Year
• Warranty: 1 YEAR

Microprocessor Flame Photometer With Sodium And Potassium (k) Filter : Alpha Chem is manufactures,exporter & suppliers Microprocessor Flame Photometer With Sodium And Potassium (k) Filter. Readout: 24x4 line LCD display, auto ignition system, Detector: Silicon photo diode, Filter: Narrow Band interface Glass filters nebulizer: Bak Light, Axial Flow Type, Flame System: LPG and Dry oil free air., Up to 5 point calibration, direct read out in ppm and mgI, Auto filter selection, auto ignition, single aspiration, RS 232 interface, with Power Supply: 230V+10%AC, 50HZ. Optional: Ca & Li Filters can be Provided on extra cost. Alphanumeric 4 line Display

The Digital Flame Photometer that we offer is rugged, reliable and accurate instrument to determine concentration of Na, K, Li & Ca Solution in clinical lab and soil laboratories. Salient Features Simple & easy to OperateNarrow Band Interference FiltersDual Channel DisplayNa & K at Single Aspiration

We are a leading manufacturer, exporter & supplier of actophotometer. The actophotometer is an improved and solid-state type equipment with six photo cells for ensuring spontaneous and induced activity with digital totalizes or counter. In addition, the actophotometer is available at competent prices from the market.

We are a leading manufacturer and wholesale supplier from Haryana, who are engaged in processing Actophotometer that are designed using advanced technology while including LSI Electronic Digital Circuitry. It consists of a Perspex sheet which is fitted with nickel coated brass rods and the control panel is accurately designed with shock strength and digital voltmeter. Actophotometer has detachable cords which makes it easy to handle and store. Furthermore a dropping tray is provided which helps in easy cleaning of the device. Avail Actophotometer from us at competitive prices.   Operating Instructions : Insert the mains lead into the mains socket and the socket provided on the left hand side of the cabinet. Switch the Instrument ON with the help of the switch marked Mains of the front panel.  The red indicator above the ON switch starts glowing and indicates that the mains voltage is available. Also the four digit display marked COUNT starts displaying either all Zero’s or some count. Press the Reset switch once. Now the COUNT is 0000. Insert the animal into the chamber. Switch the Shock ON with the help of the Switch marked ON near the voltmeter. The green indicator starts glowing. St the Shock Strength value on the Voltmeter with the help of SHOCK STRENGTH to the desired value according to the experiment. Now because of the Shock available on the grid, the animal starts moving here and there. This movement is recorded on the Four Digits Counter and is displayed on the front panel marked with COUNT. Interrelate the count value with the experiment requirements being performed.   Precautions: Keep the instrument clean and dry. Do not handle the instrument with wet hands. Do not try to touch the grill when the SHOCK STRENGTH is on. Handle the Perspex box carefully.

FLAME PHOTO METER SPECIFICATIONS No. of Filters Na & K (Ca & Li optional) Range Na:0-100, Ca:20-100, K:0-100, Li:10-100ppm Sensitivity Na : 5 ppm, Ca : 10 ppm, K: 5 ppm , Li : 10ppm Read out 2½ Digit bright LED Display Accuracy ± 2% upto ± 5% above 40 ppm Repeatability ±2Count Detector Silicon Photo diode Filters Narrow band interference glass filters Nebuliser Black BAKELITE, axial flow type Flame Sys. LPG and dry oil free air Warm up Time 10 minutes

• Brand Name: Radical
• Weight: 4kg
• Digital Flame Photometer: Table Top

Features:  Simple & Easy to Operate Narrow Band Interference Filters Accurate Na, K, Ca, & Li Determination Mixing Chamber Designed For Stable Flame Concentric Non-Corrosive Nebulizer Auto Ignition Digital Flame Photometer is a simple & easy to operate instrument for determination of Sodium, Potassium, Calcium & Lithium. It is an ideal instrument for soil testing labs. The instruments are supplied in two units viz. Main Unit and Compressor Unit. The Main Unit comprises of digital displays, detector, filters and nebulizer. The compressor unit supplies the compressed air to the main unit Air at a given pressure is passed into the atomiser. The suction produced by it, draws the sample solution into the nebulizer and is sprayed as fine mist into the flame. The light emitted by the element at the characteristic wavelength is isolated by the narrow band interference filters, which then falls on to the silicon photodiode. After signal conditioning of the photodiode output, it is sent to digital converter and the results are displayed directly in ppm/meq units. The narrow band interference filters are mounted on a rotating disc fitted within the Main Unit. Appropriate filter can be selected by rotating this disc with the thumb. The oil free compressor with regulator maintains a stable airflow.

• Strength: 50 mA
• Display Type: Digital
• Feature: Durable
• Power Source: Electrical
• Usage: Laboratory
• Warranty: 1 Year

Actophotometer is used for monitoring spontaneous & induced ambulatory activity of laboratory animals. Actophotometer is provided in a powder coated sturdy body with Bakelite meters & superior quality design. It consists of six built-in photo sensor and 4-digit digital counter to indicate the loco meter activity. It also incorporates electric shock of up to 100 volts for activating animals. The stimulus is variable from 0 to 100v & indicating on meter.

Made of two blocks of translucent material with dimensions 25 x 20 x 12.5 mm, separated by a sheet of opaque material. Mounted on a base, with window for viewing. Fitted on a stem length 75 mm, on stand. When two sides of the blocks are exposed to uneven illumination, the block shows difference in color.

• Power: 230 VAC 10% 50 Hz AC
• No. of Filters: Na & K (Ca & Li optional)
• Range Na  : 0-100 ppm, Ca:20-i00 ppm, K:0-100 ppm, Li: 10-100 ppm
• Sensitivity Na: 5 ppm, Ca : 10 ppm, K : 5 ppm , Li : 10 ppm
• Read out: 2 Digit bright LED Display
• Accuracy:  2% upto 40 ppm, 5% above 40 ppm
• Repeatability: 2 Count
• Detector: Silicon Photodiode

We offer digital flamephotometers, a handheld instrument which is fabricated from supreme quality raw material. Our experienced engineers utilize improved technology in manufacturing that ensures high performance of the range. It is simple in construction and easy to operate. The instrument possesses following features: Flame photometer unit No. of filters Na & k (ca & Li optional) Na & k (ca & Li optional) Range Na: 0-100 ppm ca: 20-100 ppm Narrow band interference filters Dual channel display K: 0-100 ppm Li: 10-100 ppm Na: 0-200 meq/l ca: 0-2 meq/l Na & k at single aspiration K: 0-100 meq/l Li: 0-10 meq/l Sensitivity Na: 5 ppm ca: 10 ppm
