Polarizing Microscope Dealers in Ambala

We are well reckoned as one of the key Trinocular Polarizing Geological Microscope Exporters based in India. Our Trinocular Polarizing Microscope is well equipped with strain plain achromatic optics for transmitted light observation. The built in halogen illuminating system and high quality coated optics ensure optimum image contrast. Technical Specification : Head : Inclined Trinocular HeadBody : Inclined Binocular Body, Rotatable through 360oNose Piece : Perfectly Centered bearing based, Quadruple revolving nose piece.Mechanical Stage : Roatatable Round Mechanical Stage, Divided 0-360o,Sub Stage : Abbe N.A.1.25 condenser, focussable with rack and pinion through 25mm continously visible iris diaphragm with built in swing out filter holder.Anti Fungus Objectives : Parafocal, Achromatic Din objectives;4x/5x, 10x, 40x/45x SL,Anti Fungus Eye Pieces : HIghest quality paired Huy.5x Huy with cross Line and WF 10x with cross Graticule.Focussing : Single Co-axial knob provided based on a four stage gear reduction system for coarse and fine focussing for silk smooth operation.Illumination : Fitted with built in base halogen light source; fitted with 6V-20W Halogens Bulbs; On/Off Switch and light intensity regulator;complete with power cord and plug. Also a set of plano-concave reflector provided for day light use. Total Magnification : 25x to 675x Complete with Above : Nicely packed in wooden box.

• Type: Polarizing Microscope
• Application: Science Lab
• Weight: 3-5kg
• Color: White
• Feature: Easy To Use, Good Griping
• Voltage: 220V
• Condition: New
• Driven Type: Electricity
• Eyepieces: WF10X
• Portable Style: Portable
• Country of Origin: India
• Brand Name: MAYALAB

• Brand Name: Radical
• Eyepieces: HKW10x Paired & WF 10x Cross
• Model: RPL-55T
• Stage: Compact Ball bearing Rotating Stage, 140mm dia., graduation with vernier, lock & stage specimen clip
• Polarizer: Fully rotatable Polarizer on a strain free N.A 1.25 abbe condenser with iris diaphragm.
• Objectives: Stress less flat achromatic DIN Objectives PF4x/0.10, PF10x/0.25 & PF40x/0.65 SL
• Compensator: Gypsum (1st. order red compensating plate, 560nm). Mica (145nm) & Quartz Wedge (I-IV order).

Research Polarizing Microscope are principal piece of equipment used by the Geologists to observe the optical properties of minerals. It has indispensable applications for petrography, crystallography, geology, mineralogy, ceramics, toxicology, chemical microscopy or detecting defects in semi-conductors, finding stress points in metals, glass & textiles etc. Focusing - Coaxial focusing is provided with coarse tension adjustment ring and graduated slow motion knobs. Adjustable safety lock is attached to prevent the breakage of specimen slides.Illuminator - Koehler's Illuminator with pre-centered 20W Tungsten Halogen source & integral electric transformer with intensity control. Input Voltage 220 or 110V.Intermediate Tube - Built-in focusable Bertrand Lens with center adjustment. Built-in Analyzer removable from optical part. Analyzer can be rotated 90º with vernier reading to 6'. Compensator 1 Lambda, 1/4 Lambda & Quartz Wedge can be inserted in the tube as per requirement.Optional Accessories - Detachable Mechanical Stage, Objectives PF20x & PF60X, Micrometer Eyepiece WF10x, Microphotographic Equipment, 30º Inclined Siedentopf Heads. Wooden storing cabinet etc.

• Theory: Stereo Microscope
• Drawtube: Binocular
• Zoom range: 7X-180X.
• Zoom Lens: 0.7-4.5x
• Eye pieces: Wide field 10x or 15x .
• Objectives: 4x, 20x, 40x, 10x

Supply high quality and contrast image with special strain free objective. Transmitted light and reflect light, 24V/100W long life halogen Lamp. Stage with 45 degree located, attachable mechanical stage with large moving .range, high efficiency by no interference when turning objectives. Professional polarizing microscope for geology, petroleum, chemical, polymer, LED field.

• Eyepieces: WF 10X (Pair)
• Objectives: P4X, P10X and P40X.

This labo microscope with the features of easy operation, complete functions and economy, it is an ideal instrument in geology, petroleum, coal, chemicals and physic fields. It is also widely used in academic demonstration and scientific research.

We Offer Research Polarizing Microscope. Large Rectangular Heavy Base Having Electrical Fittings Concealed Inside. Body microscopes are Available with Monocular, Binocular & Trinocular Heads with 45º Inclined Observation Tubes. Interpupillary Distance & Dioptric Adjsutments are Provided in Binocular & Trinocular Heads. Nosepiece centrable Precise Ball Bearing Quadruple Having Objective Mounts & Ribbed Grip for Easy Rotation. Stage compact Ball Bearing Rotating Stage, 140mm Dia., Graduation with Vernier, Lock & Stage Specimen Clips. Focusing coaxial Focusing is Provided with Coarse Tension Adjustment Ring and Graduated Slow Motion Knobs. Adjustable Safety Lock is Attached to Prevent the Breakage of Specimen Slides. Illuminator koehler's Illuminator with Pre-centered 20w Tungsten Halogen Source & Integral Electric Transformer with Intensity Control. Input Voltage 220 or 110v. Intermediate Tube built-in Focusable Bertrand Lens with Center Adjustment. Built-in Analyzer Removable from Optical Part. Analyzer Can Be Rotated 90º with Vernier Reading to 6'. Compensator 1 Lambda, 14 Lambda & Quartz Wedge Can Be Inserted in the Tube as per Requirement. Compensator gypsum (1st. Order Red Compensating Plate, 560nm). Mica (145nm) & Quartz Wedge (i-iv Order). Objectives stress Less Flat Achromatic Din Objectives pf4x0.10, Pf10x0.25 & Pf40x0.65 Sl eyepieces hkw10x Paired & Wf 10x Cross polarizer fully Rotatable Polarizer On a Strain Free N.a 1.25 Abbe Condenser with Iris Diaphragm. Accessories vinyl Dust Cover, Duster, Cleaning Brush, Filters, Spare Bulb & Fuse with Operating Instructions Manual. Packing in Full Mould Styrofoam Container. Optional Accessories detachable Mechanical Stage, Objectives Pf20x & Pf60x, Micrometer Eyepiece Wf10x, Microphotographic Equipment, 30º Inclined Siedentopf Heads. Wooden Storing Cabinet Etc.

RXLr-4 POL Polarizing Microscope is a principal piece of equipment used by the geologists to observe the optical properties of minerals. It has indispensable applications for Petrography, Crystallography, Geology, Mineralogy, Ceramics, Toxicology, Chemical Microscopy or detecting defects in semiconductors or finding stress points in metal, glass, textiles, etc. It permits orthoscopically or conoscopically to examine and identify the structures and characteristic of material with highly resolved distinctive images under various magnifications. Compact ball-bearing rotating stage, 140mm diameter, graduated with vernier, lock and stage specimen clips. Compensator : Gyps 1l (1st order red compensating plate, 560 nanometers) Mica 1/4l (145 nanometers) and Quartz Wedge (I-IV order) Built-in focussable Bertrand lens with center adjustable. Built-in analyzer removable from optical path. Analyzer can be rotated thro 90° with a vernier reading to 6'. Compensator 1l, 1/4l. Quartz Wedge can be inserted in the tube as per requirement. Fully rotatable Polarizer on a strain free N.A. 1.25 abbe condenser with iris-diaphragm. Nosepiece - centreable on roller bearing. Illuminator - Koehler's illuminator with pre-centred 30W tungsten halogen source and integral electric transformer with intensity control is concealed inside the base. Input voltage 220 or 110 Volts.Supplied complete in a box with following optical combination. Objectives - PF 4x / 0.10, PF 10x / 0.25 and PF 40x / 0.65 SL RFI. Eyepieces - HKW 10X (Paired) and WF 10x Cross. RXLr-4POLT Polarizing Microscope alongwith incident illumination : It has the same features as that of RXLr-4POL with additional incident illumination of either 12V/50W or 12V/100W.

• Application: Forensic Lab, Science Lab
• Weight: 0-500gm, 1-3kg, 3-5kg, 5-10kg, 500gm-1kg
• Color: Black, Creamy, Dark Grey, Grey, White, Z-Black
• Voltage: 110V, 220V
• Condition: New, Used
• Driven Type: Battery
• Feature: Actual View Quality, Contemporary Styling, Durable, Easy To Use, Good Griping, Power Angle View, Traditional Bushnell, Uv Protective
• Warranty: 1yrs, 2yrs, 5yrs

• Brand Name: Radical
• Eyepieces: HKW 10X, WF 10x Cross
• Magnification: 10x
•  :
• Objectives: PF 4x, 0.10, PF 10x, 0.25
• Minimum Order Quantity: 1 No(s)

• Country of Origin: Made in India
• Voltage: 220 V
• Brand: Almicro
• Usage/Application: Laboratory
• Rotatable: 360 Degree
• Objectives: 5x, 10x and 45x
• Is It Portable: Portable
• Frequency: 50 Hz
• Eye Piece: 5x (with cross) & 10x (with occular)

• Rotatable circular stage: dia 130mm
• Illumination: by 50mm dia plano-concave mirror interchangeable with sub-stage electric illuminator
• Achromatic objective: P4x, P10x, P40x(s) & eye-pieces WF10x, H5x with cross line and H10x with micrometer scale.
• Power supply: 220V AC 50Hz
• Finish: Hard powder coated
• Packaging: The microscope is packed in polished plywood cabinet with lock and key,dust cover and cleaning cloth
• Item Code: PLS-22

Product Overview:• High Quality Professional Trinocular Polarizing Microscope! • Great for Geology, Petrology, Mineralogy, Toxicology, Pharmaceutics, and Forensic Medicine! Specification: • Built-In Bertrand Lens with Capability for Removal from Optical Path. • Built-In Analyzer with Capability for Removal from Optical Path. Rotatable 90 Degrees with Graduation Marks every 1 Degree for the full 90 degrees. • Transmitted Light Polarizer, with Capability for Removal from Optical Path. Fully Rotatable 360 Degrees with Graduation Marks every 5 Degrees for the full 360 degrees.• Selectable between Brightfield and Polarizing Light. • Easily switch between Plane Polarized and Cross Polarized Illumination.Camera/Video Trinocular Port:• Has Trinocular Photographic Port for taking Photographs or Video! • Take Quality High Resolution Digital Images with your Camera!• Attach your Digital Video Camcorder for Stunning Video!• Bring Digital Images and Video into your Computer and Email! • Other accessories, not included, may be needed for taking Digital or Film Photos, Digital Video, as well as attaching CCD Cameras for Output to a Display Monitor. Eyepieces a

stand -rigid & heavy single mold aluminum die-cast stand. observation head- binocular head inclined at 45o and rotatable in 360o.  eyepiece -10x wf (paired) anti-fungal eyepiece. H6x (paired) extra.  nosepiece - quadruple ball bearing revolving nose piece  objectives- 4x/0.10, 10x/na 0.25, 40x/na 0.65(sl) & 100x/na 1.25(sl) oil imm. stage - circular rotatable stage 360o. polarizing attachment-  full wave & ¼ wave compensating plates, bertrand lens, sliding type removable analyzer from optical path and 360° swing out polarizer. focusing - separate coarse and fine knobs reading up to 0.002mm.  condenser- na 1.25 fitted with iris diaphragm and blue filter holder.  illumination- halogen 6v-20w with variable intensity control.  power- ac input 100v-240v, 50/60 hz iso 9001, ce approved. packaging contents- styrofoam molded, nylon dust cover,

Microscope frame for transmission and reflection mode polarization microscopy with built-in filter holders, High Power LED Light with power supply, High Power LED light with power supply Built in Transmitted light filters, Minimum 4 position centrable & detachable nosepiece , Stroke: Min 22mm. Fine Stroke: Min 100µm Minimum.

We offer Simple Polarizing Microscope. Simple Polarizing Microscope (SPM-600) Student Polarizing microscope (SPM-600) It has been designed extensive routine work of industries as well as scientific examination in Geochemistry, Mineralogy, Petrography, Metallographic, Biology, and branches of Pharmacology BODY: Economical and learning Student Polarizing Microscope comes with stable Horse-shoe type base body. OBSERVATION TUBE: Monocular fixed 90°straight tube. OR 45° Inclined monocular tube. Its tube Length 160mm. FOCUSING SYSTEM: It has separate Coarse & Fine Focusing knobs Mechanism NOSEPIECE: Triple revolving nose piece with positive click stops SPECIMEN STAGE: Round and 360 degree rotatable GYPSM plate with two stage clips for holding the specimen slides. It comes with the attachment of BERTAND LENS, ANALYZER, FULL & HALF WAVE COMPENSATOR inside the tube .
