Projection Microscope Dealers in Ambala

• Country of Origin: India
• Application: Forensic Lab, Science Lab
• Weight: 1-3kg
• Feature: Durable, Easy To Use, Good Griping
• Voltage: 110V
• Condition: New
• Eyepieces: WF10X
• Focus: 2-4mmRevolution
• Vision Angle: 0-5Degree
• Magnification Range: 50- 250X

• Packaging Type: plywood box

Microscope Body is heavy duty, inclined monocular type with sturdy base. Equipped with Coarse & Fine Focusing systems with Quadruple revolving Nose Piece. Plain stage (120x120mm) with graduated Mechanical Stage for X-Y movements of specimen slide. Built in light by 6V-20W halogen lamp with continuously variable light intensity control. The whole system of condenser & light arrangement is moveable up & down by rack & pinion to get the optimum results. Projection Doom of screen size 150 mm is Rotatable through 360°. Objectives: Achromatic 10x & 20x/40x (SL) Projection Eye Piece: 10x (Huy) Packed in a thick and attractive plywood box.

With 200mm dia graduated screen 360 degree rotatable, quadruple revolving nose piece. Total magnification ranging 100x to 800x or 125x to 1000x, workable on 220volts AC mains optional stage micrometer slide for measuring, optical combination. Objectives : 5x, 10x, 20x, 40x/45x

• Application: Forensic Lab
• Weight: 1-3kg
• Color: White
• Voltage: 110V
• Driven Type: Battery, Electricity
• Feature: Contemporary Styling, Easy To Use
• Warranty: 12 Months
• Objective: M10x, M20x, M40x
• Portable Style: Portable

With screen diameter 195m, graduated 360o, rotateable screen, solid state intensity control system, mechanical stage, objectives 5x, 10x, 20x, 40x, or 60x magnification 125x to 1000x complete in cardboard box.

• Brand Name: Radical
• Color: White
• Name: Projection Microscope

Projection Microscope PRM-12  A dual purpose instrument having halogen projection bulb workable on 220V AC. Equipped with an efficient cooling fan inside, 150mm diameter built-in fine grain glass screen,. On screen magnification upto 400x. Supplied complete with Vinyl cover, in cardboard box.

We provide to the esteemed clients precisely engineered Projection Microscope, which is at par with international quality accepted standards. These Projection Microscopes find wide application in research labs and college and school laboratories. Our Projection Microscopes are categorized by various special features like portability, light in weight and for providing eye comfort to the user. TECHNICAL SPECIFICATIONSObservation Body : Monocular Fixed Straight Tube, length 160mmNosepiece : Triple revolving nosepiece with accurate centering and positive click stopsStage : Mechanical stage of 135x120mm. Low co-axial drive controls for X-Y movement and cross movement 50X75mm, fully graduated vernier scaleIllumination : 20W halogen lamp, 220/110Volts. Lamp slots provided for natural cooling of the illuminatorObjectives : Achromatic 4X - 10X- 40XSLEyepieces : Huygenian 10X and 15XScreen : 150mm diameter Glass Projection Screen is provided can be rotated over 360-degrees on Microscope tube

• Weight: 20kg
• Objectives: 5x, 10x, 20x, 40x.

An advanced versatile projection microscope for measurement of dimensions of precision mechanical components different types of yarns in textile industries and research institutes. Equipped with Halogen bulb of 24V/150watt with built in solid state transformers working on 220V AC mains. Graduated screen, diameter 200mm, rotable through 360o.Built in fresnel lens with loop and arrow arrangement. Co-axial mechanical stage having Micro movements on X & Y knobs, working on Ball bearing guideways. Focussing through coarse and fine motion knobs. Quadruple nose-piece. Duly packed in sturdy card board box.

• Brand Name: ALPHA CHEM
• Model Number: ALPHA CHEM-1025

Advance projection microscope : this microscope is very useful for routine observation and complex type measurements of specimen magnified on screen, group observations, discussions and teaching. Specifications:- equipped with a 195 mm diameter special material graduated screen built-in base illuminator & diaphragm which is directed to the condenser which again is reflected through a mirror to the objective and compensating eyepiece for projection on to the screen again by a reflector graduated mechanical stage is also provided on the large stage for backward and forward movements within 30mm& 40mm scales read by verniers to 0.1mm screen-head is rotatable through 360o with cross scales vertically and horizontally within 140mm a quadruple nose-piece carries has four objectives : 5x, 10x, 20x & 40x giving magnification from 125x to 1000x. A: magnification from 125x to 1500x. B : incorporated with binocular head. C : screen of 150 mm diameter.

• Brand Name: Amesys India,amesys india,amesys india
• Driven Type: Battery, Electricity
• Color: White,white,white
• Condition: New
• Power: 100W
• Application: Science Lab
• Size: 150mmx200mm
• Feature: Durable, Good Griping
• Voltage: 110V
• Packaging Type: AMESYS INDIA
• Portable Style: Portable
• Type: Projection Microscope,Projection Microscope,Projection Microscope
• Weight: 1-3kg
• Warranty: 1yrs
• Country of Origin: India
• Eyepieces: WF10X
• Focus: 0-2mm/Revolution
• Objective: M10x
• Magnification Changer: Positive Precision Click Stops
• Vision Angle: 0-5Degree
• Magnification Range: 50- 250X
• Battery Backup: 4-6hr/1 Time Charging
• Warranty: 1year
• Warranty: 1year
• Country of Origin: made in india

• Condenser: A High Quality Glass Condenser in Front of Screen
• Mechanical Tube: Length 160mm
• Optics: Eyepieces: 10x Huygenian
• Objective Achromatic: 5x, 10x, and 40, Spring Loaded
• Nose Piece: Triple Revolving Nose Piece
• Transformer: Workable by 12 v 21 Watts, Built in the base
• Mechanical Stage: Brass

The microscope is most suitable for group discussion as well as for teaching .  Screen: Grainless Optical true 150mm outer circular dome, 360º rotatable for mounting on microscope  Condenser: A high quality glass condenser in front of screen  Mechanical Tube: Length 160mm  Optics: Eyepieces: 10x Huygenian  Objective Achromatic : 5x, 10x, and 40, spring loaded  Nose Piece: Triple revolving nose piece.  Movement : Coarse motion through rack and pinion with precise and accurate fine movement. Fixed square stage 102 x 102 mm.  Transformer: Workable by 12 v 21 Watts, Built in the base.  Mechanical Stage:  Brass  Lamp Assembly: Fixed lamp, built in base of high illumination with high power condenser and screen it will work as micro view projector. With lamp, transformer, but without it work as microscope. The viewing of biological microscope slide is distinct and enlarged. Sharp, clear and evenly illuminated image in full colours, visible to the whole class free of distortion.    Spare for above:   Lamp 12 Volts 21 watts Graduated Mechanical Stage.

The Projection Microscopes that we offer have an excellent design that enables accurate and clear results. these projection microscopes that we offer are easy to use and light in weight. our range of projection microscopes has made us a favored name in the market. the microscopes are used in several applications. used in schools laboratories medical institutions salient features screen : antiglare hard glass 200mm dia screen focusing mechanism : coarse motionnose piece : a reverse type nose piece running on ball bearing balls ensures smooths motion objective : objective 5x, 10x, 40x, 60x imported hard control & anti fungal treatment lenses mechanical stage : co-axial mechanical stage light source : 12v 100watt halogen bulb with solid state variable light control.

• Application: Forensic Lab, Science Lab

We are offering projection microscope. Specially design for sugar factories for measuring the size of sugar crystal. From : 0.2mm to .001mm supplied with calculation chart. Salient features screen : antiglare hard glass 200mm dia screen. Focusing mechanism : coarse motion nose piece : a reverse type nose piece running on ball bearing balls ensures smooths motion. Objective : objective 5x, 10x, 40x, 60x imported hard control & anti fungal treatment lenses. Mechanical stage : co-axial mechanical stage. Light source : 12v 100watt halogen bulb with solid state variable light control.

• Brand Name: WESWOX
• Color: White
• Magnification: 10x,20x,40x having projection bulb 12v-100W and 160mm dia built in screen.
• Country of Origin: India
• Model Number: MP-380

We are offering projection microscopes. Our firm specializes in offering a wide assortment of projection microscopes. The offered projection microscope is precisely developed under the direction of our professionals using advance technology keeping in mind the all standards of industry. Our projection microscope is available in varied models & other specifications in order to meet the specific demand of customers. This projection microscope is tested on set various parameters to eradicate all fault in it. Features: optimum performance less maintenance easy operation & magnified view key features: compact, dust proof construction light weight, functional design & quality optical components. Model:mp-380 observation screen 160 mm dia. Ground glass screen, easily removable to enable projection of specimens on the wall screen. Nosepiece triplequadruple nosepiece with positive click stop. Objectives 10 x, 20 x, 40 x (sl) object stage fitted with two phosphorus chrome plated stage clips to hold specimen slides. Focussing system focusing is done by vertical movement of stage, coarse adjustment by rack & pinion illumination having projection bulb 12 v-100 w with intensity control unit workable on 220 volts ac mains. Packaging complete in a cardboard box. Optional accessories the concomitant accessories - a spare bulb, fuse, vinyl cover & power cord are housed in a drawer on the side wall of the microscope.

• Country of Origin: India
• Type: Projection Microscope
• Condition: New
• Portable Style: Portable
• Brand Name: Almicro
• Illumination: It Comes Equipped with 12v 100w Halogen Lamp.
• Nose Piece: Triple revolving nosepiece with positive click stops.

ALMICRO Projection Microscope (KW-500)  This Microscope is meant for group discussion & teaching a group of students.  SPECIFICATIONS :  Illumination : It comes equipped with 12V 100W Halogen Lamp.  Stage :  110 x 110mm square stage is provided with stage clips to hold the slide (optional Mechanical Stage).  Focussing :  Focussing control knob on both sides of the instrument is conviniently located for easy operation of the rack and pinion with 15mm range.  Nose Piece : Triple revolving nosepiece with positive click stops. Screen & Wall Projection : 160mm dia. optically true ground glass screen is provided to have high resolving power. The screen housing is hinged to the body frame and can be removed to one side to have projection on the wall or screen in a dark room.  Objectives : Packing : This Microscope is equipped with three Achromatic objectives 5x,10x & 20x.

Our projection microscope has heavy duty body, coarse & fine focusing system &triple revolving nosepiece. A plain stage 1 20x1 20mm with two spring clips to hold the slide can be provided with attachable graduated mechanical stage (optional accessories) For the clear observation of slides, a 150mm diameter screen attached to the microscope tube.

• Brand Name: Innolab India
• Driven Type: Electricity
• Color: White
• Condition: New
• Power: 100W
• Application: Laboratory Use
• Size: 150mmx200mm
