Reciprocating Pump Test Rig Dealers in Ambala

• Weight: 100-400kg, 400-600kg
• Condition: New
• Application: Industrial Use
• Power: 1-3kw, 5-7kw, 9-12kw
• Driven Type: Electric
• Motor Power: 10hp, 4hp, 8hp
• Automation Grade: Automatic

he present Reciprocating Pump Test Rig is a self-contained unit operated on closed circuit basis

• Fuild mechanics and machinary equipment: Centrifugal Pump Test Rig
• Fuild mechanics and machinary equipment: Kaplan Turbine Test Rig
• Fuild mechanics and machinary equipment: Francis Turbine Test Rig
• Fuild mechanics and machinary equipment: Pelton Wheel Turbine Test Rig

Product description: reciprocating pump test rig (variable speed) description : the present reciprocating pump test rig is a self-contained unit operated on closed circuit basis containing a sump tank. The set-up consists of a double acting, single cylinder reciprocating pump coupled with a dc motor power input to the dc motor is varied by means of a thyristor controlled dc drive to vary the rpm of motor. A rpm indicator with proximity sensor indicates the rpm of pump. Flow of water is measured by using measuring tank and stop watch. Vacuum gauge is fitted on suction line and pressure gauge is fitted on delivery line to measure the pressure.

• Brand Name: ETHER
• Usage: Laboratory
• Material: Stainless Steel

The setup is designed to study the performance of reciprocating pump. Set up consists of a reciprocating pump coupled with electrical motor, supply tank, measuring tank & pipe fittings for closed loop water circulation. Pressure and Vacuum gauges are connected on delivery and suction side of pump for the purpose of measurement. The flow rate of water is measured using measuring tank and stop watch provided Experiments To determine overall efficiency and pump efficiency of the reciprocating pump. To plot Head vs. Discharge, Pump efficiency vs. Discharge Utilities Required Electric supply Provide 230 +/- 10 VAC, 50 Hz, single phase electric supply with proper earthing. (Neutral – Earth voltage less than 5 VAC.), 5A, three pin socket with switch for pump. Water supply Tap water connection ” BSP Distilled water @ 80 liters (optional)
