THIS AC TEST RIG IS USED TO CONDUCT EXPERIMENT TO FIND ITS EFFICIENCY

The apparatus consists of a storage water tank, embraced by evaporator coil of the cooling unit, cooling cycle comprises of a hermetically sealed compressor, air-cooled condenser, a capillary tube as expansion device and an evaporator cell. The stainless steel water tank is provided with insulation on air Sides and a door are provided at the top. Cold water can be taken out from a top provided and inlet water supply is controlled by a float. Various measurements provided enable students to determine the theoretical and actual COP, power consumption, actual cooling capacity refrigerant flow and compressor volumetric efficiency of compressor. To calculate refrigerant capacity. To Calculate Co-efficient of performance and draw P-H Diagram Utilities Required: Electric supply 5A-220 V AC Water supply and drainage Floor area : 1.3 m x 1.2m

Based in Haryana, we have built a wealth of reputation for manufacturing and supplying the Double Stage Air Compressor Test Rig of superlative quality. Our deft team aligns these Double Stage Air Compressor Test Rigs with the prevailing industry standards to guarantee fail-safe functionality to the buyers. Plus, the prices quoted by us are insignificant in comparison to the quality!   Scope of Experimentations :- To calculate the volumetric efficiency. To calculate isothermal HP. To calculate compression ratio.  Utilities Required :-  Electricity 2 kW. 220V AC, Single Phase.  Floor Area 1.5 x 0.75 m.   Technical Details :- Compressor : Double Stage, Double Cylinder. Capacity 6.9 CFM max. Drive : 2HP/2 phase 5 HP. Spring Balance : Dial type. Manifold Tank : Suitable Capacity. Flow Measurement : Orifice meter with Manometer. Temp. Measurement : Thermometer 2 Nos. Air Tank : Capacity 100 Ltrs. with safety valve shut off valve. Bourdon Type. Pressure Gauge : Bourdon type. Control Panel Comprises of : RPM measurement : RPM Indicator with Proximity sensor. Energy measurement : Electronic Energy meter, L&T make. MCB : For overload protection. Standard make On/Off Switch, Mains Indicator, etc.  The whole set-up is well designed and arranged in a good quality painted structure.

• Brand Name: SUPERB-TECH
• Port: Delhi
• Packaging Details: wooden boxes or packaging
• Place of Origin: Haryana, India
• Model Number: STD-15

The unit of Ice Plant Test Rig consists of a hermetically sealed compressor with air cooled condenser. A capillary is provided next to the condensers followed by medium temperature evaporators. Electrical energy supplied to the compressor can be measured by energy meter. The evaporator is immersed in the SS tank with PUF insulation. The equipment is mounted on a MS Powder Coated base plate with control panel. ExperimentTo calculate the co-efficient of performance of unit Technical SpecificationsCompressor : Tecumseh India Hermetically sealed compressor shall be provided with its standardized electrical accessoriesCondenser : Fins and Tube type air cooled condenserCondenser Fan Motor : Best Indian makeCabinet : The Inner and Outer brink tank shall be fabricated out of Stainless Steel SheetCooling Coil : Water Immersed Type.ICE Cans : G.I. Sheets Ice CansRefrigerant-Freon : 404a Refrigerant GasMeasuring ControlGlass Tube Rotameter to measure the flow liquid refrigerant gas Freon � 404asuction pressure gauge for low pressure measurementDischarge pressure gauge for high pressure measurementDrier, Gas charging valve, Expansions devices � Capillary tube typeElectrical Control Panel : MCB, Voltmeter Digital type, Amp. Meter Digital type, Energy Meter for Compressor input, Switches & Indication LightsDigital Temperature : 1 Nos. Digital Temperature Indicator provided Indicator with Temperature Sensor.Electrical Characteristic : Current AC Single Phase, 50 Hz 220 Volts.Manual : Operation and maintenances manual should be provided along with the supplied equipment.

• Type: Domestic
• Application: Laboratory Use
• Driven Type: Electric
• Power supply: 220V - 50 Hz single phase
• Compressor: Double Cylinder Drive and Belt-pulley
• Refrigerant: R-134a

All components and instrumentation will be mounted on a Mild Steel Sheet panel  9 Chanel  digital indicator with voltmeter and ammeter -  will allow measurement of motor power or evaporation Transformer with dimmer -  will change the load of the evaporator Float flow meter -  for the flow of the refrigerant and for the flow "of water Bourdon type pressure gauge  -  for the refrigerant pressure at the evaporator and for the condenser Dynamometer and tachometer  -  for measuring the mechanical power of the engine Expansion valve  -  thermostatic Type An evaporator -  equipped with electric resistances.A condenser cooled by water. Safety -  condensing pressure and evaporation temperature protected by automatic disconnector. The Ensemble will be grounded. Differential circuit breaker.

• Brand Name: KRISHNA
• K: K
• K: K

We are offering Hydraulic Ram Test Setup. Description:- the set-up is designed to study the hydraulic ram. Hydraulic ram is used for pump little quantity of water to high head from a large quantity of water available at low head. It works on a principle of water hammer stating that “when flowing water is suddenly stopped in a long pipe a pressure wave travels along the pipe creating an effect of water hammer”. The set-up consists of a pipe section fitted with a pulse valve and non-return valve, a supply reservoir on a stand which is connected to an overhead tank, an air vessel above the valve chamber smoothes cyclic fluctuations from the ram delivery. Different pressure may be applied to the pulse valve to change the closing pressure and hence the operating characteristic. The flow rate of useful and waste water is measured using measuring tank and stop watch provided. Pressure and vacuum gauge are connected on delivery and suction side for the purpose of measurement. experiment:-  to find out discharge of useful water and waste water.  to find out the efficiency of the hydraulic ram features:-  closed loop water circulation  compact & stand alone set-up  ms excel sample calculation program on demand  stainless steel tanks and wetted parts  superb painted structure  simple to operate & maintain utilities required:- electric supply: - provide 230 +/- 10 vac, 50 hz, single phase electric supply with proper earthing. (neutral – earth voltage less than 5 vac) 5 a, three pin socket with switch for pump. water supply: tap water connection ½ “ bsp distilled water @ 90 ltrs. (optional)

• Motor: 3 hp, 3 Phase 415 V AC.
• temperature: 0-199.9 °C

Air Compressor Test Rig The test rig consists of a reciprocating air compressor driven by an electric motor. The compressor is two stage compressor with intercooler. Intake air flow rate is measured by using an air box with orifice plate & differential manometer. Pressure gauges are provided to measure pressure after 1st stage, 2nd stage & tank pressure. Temperature sensors are used to measure the air temperature at Inlet, after 1st Stage, Intercooler & 2nd stage. Compressor Speed & Power Consumption are displayed on panel meters mounted at the front. In order to study compressor performance at different speeds Variable Speed Motor with VFD can also be supplied on request. Experimental Capabilities: To investigate performance of Reciprocating Air Compressor. To study effect of delivery pressure on Power Consumption & Compressor Efficiency. To determine mechanical efficiency of reciprocating compressor. To determine Free Air Delivery (FAD) for Air Compressor.

• Brand Name: ALPHA CHEM
• Model Number: ALPHA CHEM-3974

4 Stroke 4/3 Cylinder Petrol Engine Motor Driven Alpha Chem is manufactures,exporter & suppliers of 4 Stroke 4/3 Cylinder Petrol Engine Motor Driven. 4 Stroke 4/3 Cylinder Petrol Engine - Motor Driven Actual Cut Section Working Model With Valve Timing Attachment.

• Model: AMEL001

IC engines are widely used in automobile, domestic and industrial sector. They are classified according to cycle, number of cylinders, arrangement of cylinders, fuel used, type of ignition, valve arrangement, cooling system. Test rigs are used to find out the performance of an IC engine. It consists of an IC Engine, dynamometer, fuel measuring, air intake measuring and various other arrangements.

• Voltage: 220 V
• Brand: Ether
• Material: Stainless Steel
• Power Source: Electric
• Item Code: 1598

We are offering venturi meter and orifice meter test rig. Technical details: product venturi meter & orifice meter apparatus venturi meter material clear acrylic compatible to 1"dia. Pipe orifice meter material clear acrylic compatible to 1" dia. Pipe. Water circulation fhp pump, cromptonsharp make flow measurement using measuring tank, capacity 40 ltrs. Sump tank capacity 85 ltrs stop watch electronic control panel onoff switch, mains indicator, et

Code: EEZ0008 Air Water Heat Pump Test Rig. Air Water Heat Pump Test Rig ManufacturerExperiment:    To watch the working foremost of warmth pump cycle.    To decide Precise cooling C.O.P, Carnot C.O.P., Theoretical C.O.P., Precise heating C.O.P., Relative C.O.P., Ton of Refrigeration And so on.    To decide the effectivity of the warmth pump device.    Study the working of refrigeration cycle additionally.Experimental Setup :    Compressor : ½ Tone, Hermetically sealed compressor, Make Emmelsion – Coplend/identical.    Condenser : Coiled Tube Warmth Exchanger acts as a condenser. Copper coil is merged in water tank to chill down the fuel temp. Steady water drift circulation is required to extract the warmth of gases.    Growth software : Thermostatic enlargement valve.    Evaporator coil : Air Cooled evaporator constituted of copper pipe & Aluminum fins of matching capability with fan.    Rotameter : For measuring liquid waft of Refrigerant    Power Meter : For energy size of compressor.    Power Gauge : 2 Nos. for H.P., L.P. size    HP/LP cutout : 1 No. to swimsuit compressor.    Provider valve needle sort : 1 No.    Thermostat : 1 No.    Appropriate filterPanel :    12 Channel Digital Temperature Indicator    Dimmerstat : 230 V. AC single segment for heating keep watch over    Primary On/Off Swap.    Voltmeter : zero – 250 V.    Ammeter : zero – 15 A.

The setup is designed to study the performance of gear pump. Set up consists of a gear pump having a pair of meshed gears coupled with electrical motor, supply tank, measuring tank & pipe fittings for closed loop oil circulation. Pressure and Vacuum gauges are connected on delivery and suction side of pump for the purpose of measurement. The flow rate of water is measured using measuring tank and stop watch provided Experiments To determine overall efficiency and pump efficiency of the gear pump. To plot Head vs. Discharge, Pump efficiency vs. Discharge Utilities Required Electric supply Provide 230 +/- 10 VAC, 50 Hz, single phase electric supply with proper earthing. (Neutral – Earth voltage less than 5 VAC.), 5A, three pin socket with switch for pump. Oil supply Oil @ 30 liters

• Capacity: 1/3 Ton
• Evaporator: Made of Stainless Steel,Insulated with ceramic wool/P.U.F.
• Expansion Device: Capillary Tube,Compatible Capacity.
• Electric Supply: 5A-220 V,AC
• Floor area: 1.5 m x 1 m
• Compressor: Hermitically sealed compressor.
• Agitator: Compatible capacity.
• Rotameter: Range 6 to 60 LPH
• Digital Voltmeter: 0-300 V
• Pressure Gauges: 2 Nos. Safety Control overload and over current protectors for compressor and Time delay circuit.
• Temperature Sensor: RTD PT-100 Type.
• Condenser: Air cooled compatible to 1/3 Ton compressor
• Condenser Cooling fan: Compatible capacity with permanent lubricated motor.

• Type: Centrifugal Pump Test Rigs
• Voltage: 230 V
• Condition: New
• Application: Industrial Use
• Driven Type: Electric
• Motor Power: 0-10 Hp
• Automation Grade: Automatic

The Window Air Conditioning Test Rig unit is required to conduct experiments and demonstrate the process of cooling of atmospheric air. The unit will be fitted with all instruments facilities so that temperature, pressure etc. may be measured at different points in the air conditioning syste

• Refrigeration and air conditioning lab: Split Air Conditioner Test Rig
• Refrigeration and air conditioning lab: Ice Plant Trainer
• Refrigeration and air conditioning lab: Lab Water To Water Heat Pump
• Refrigeration and air conditioning lab: Single Stage Air Compressor Test Rig

Product description:we are engaged in the manufacturing, trading and exporting of superior quality water cooler test rig at a nominal market price. These products are manufactured under proper guidance using latest technology, advanced machinery and quality tested raw materials. Offered lab equipment is appreciated for their seamless finish, optimum performance and longer functional life.

• Type: Air Conditioning Test Rig
• Voltage: 220V
• Condition: New, Used
• Application: Industrial Use
• Power: 0-5 Hp
• Driven Type: Electric
• Automation Grade: Automatic

Apparatus consists of a close circuit through which water is circulated continuously by means of a centrifugal pump of 25 mm x 25 mm with 0.5 H.P. motor to make the supply from sump tank. A sump tank 125 cm long, 80 cm wide and 40 cm high fabricated on MS. angle frame with 3 mm thick M.S. sheet is provided. Inside of the tank is lined with FRP. A drain valve of 15 mm size is provided in the bottom of the tank. A supply tank 50 cm x 50 cm and 100 cm high fabricated with SS. sheet with over flow arrangement, gauge glass tube and 15 mm size drain valve is provided. Inside of the tank is lined with FRP. The tank has the provision for fixing the supply pipe of 50 mm dia of which other end is connected to the ram. The tank is supported on a stand fabricated from MS. angle.

• Brand Name: UNICON
• Model Number: UI-2463

We are offering kaplan turbine test setup description:- kaplan turbine is an axial flow reaction turbine named in honor of dr. B. Kaplan, a gennan engineer. This turbine is suitable for low head. The power produced by a turbine is proportional to qh. As the head (h) decreases the j discharge (q) must increase to produce the same power. The present set-up consists of a scroll casing housing a runner. Water enters the turbine through the stationary guide vanes and passes through the runner axially. The runner has a hub and airfoil vanes, which are mounted on it. The water is fed to the turbine by means of centrifugal pump. The runner is directly mounted on one end of a central ss shaft and other end is connected to a brake arrangement. A transparent hollow cylinder made of acrylic is fitted in between the draught tube and the casing for observation of flow on to the airfoil vanes. This runner assembly is supported by thick cast iron pedestal. Load is applied to the turbine with the help of this brake arrangement so that the efficiency of the turbine can be calculated. The set-up is supplied with control panel. A draught tube is fitted on the outlet of the turbine. The set-up is complete with guide mechanism. Pressure and vacuum gauge are fitted at the inlet & outlet of the turbine to measure the total supply head on the turbine. Experiment:- • to study the operation of a kaplan turbine • to determine the output power of kaplan turbine • to determine the turbine efficiency utilities required:- ● water supply and drain. ● electricity 15 kw, 440v ac, three phase technical specifications: - model hm 109 (1.33 hp) hm 109 (5 hp) output power 1.33 hp 1 kw 5 hp 3.75 kw discharge 1500 lpm (approx.) 5000 lpm (approx.) supply head 5 m 5 m rope brake dynamometer dia 200 mm dia 300 mm sump tank capacity 300 liters. capacity 600 liters. Water circulation centrifugal pump capacity 7 hp, three phase capacity 20 hp, three phase speed 1500 rpm (approx.)

• Brand Name: Scientico
• Material: Stainless Steel
• Voltage: 230 V
• Automation Grade: Automatic
• Phase: Single Phase
• Current: 5-10 Amp
• Current Type: AC

• Brand: Eletech-Eletech Lab Instruments
• Model No: ELI-1902
• Speed: 1200 RPM
• Diameter of the turbine: 52 mm
• Water Pump Max Height: 70m
• Water Pump Max Pressure: 7 Bar
• Power requirement: 440V AC
• Category: Civil Lab
• Tag: Francis Turbine Test Rig

• Material: Stainless Steel.
• Country of Origin: Made in India
• Brand: Labappara
• Item Code: LBPTR-536
• Usage/Application: Industrial
• Model Name/Number: LAB-20256
• Sump Tank Capacity: 120 Ltrs.

• Voltage: 230
• Automation Grade: Automatic
• Power Supply: AC
• Phase: Single
• Compressor Type: Hermeticaly Sealed
• Condenser Type: Air Cooled
• Space Required: 2 m x 1 m
• Evaporator Type: Electric
• I Deal In: New Only

To, visualise the operation and estimate B. H. P. & W. H. P. and various efficiencies of pelton turbine. Pelton wheel connected to a rope brake. Water supplied by centrifugal pump & flow measured by venturimenter & mercury manometer. Water jet is directed over the buckets by a nozzle & a spare operating inside the nozzle controls the water flow.

• Pump: Double acting, Single Cylinder Capacity 1 HP, Speed 250 RPM (max.), Head 5kg/cm2 (max.)
• Drive: HM 04 AC : AC motor with step cone pulley arrangement HM 04 DC : DC motor with DC drive for variable speed.
• Supply Tank: Capacity 50 Ltrs. MOC SS
• Measuring Tank: Capacity 30 Ltrs. MOC SS fitted with Piezometer Tube & scale
• Pressure Gauge: Bourdon Type
• Piping: GI / PVC
• Stop Watch: Electronic
• Control Panel: With required electrical instrumentation RPM Indicator with Proximity Sensor Electronic Energy Meter On /Off switch Main indicator etc.

The setup is designed to study the performance of gear pump. Set up consists of a gear pump having a pair of meshed gears coupled with electrical motor, supply tank, measuring tank & pipe fittings for closed loop oil circulation. Pressure and Vacuum gauges are connected on delivery and suction side of pump for the purpose of measurement. The flow rate of water is measured using measuring tank and stop watch provided. RANGE OF EXPERIMENTS   To determine overall efficiency and pump efficiency of the centrifugal pump. To plot Head vs. Discharge, Pump efficiency vs. Discharge FEATURES   Closed loop water circulation Compact & stand alone set up Stainless Steel tanks and wetted parts Superb Painted structure Simple to operate & maintain   UTILITIES REQUIRED   Electric supply 230 +/- 10VAC,50Hz,1 phase Water supply Tap water connection ½” BSP Distilled water @ 80 liters (optional) Floor Area 1.5 x 1.5

• Material: Mild Steel
• Application: Laboratory
• Voltage: 220-240V
• Automation Grade: Semi-Automatic
• Pump Capacity: 1 HP
• Vacuum Gauge: 0 to -760 mm of Hg

Offered engine is manufactured with utmost perfection by making use of optimum quality components and contemporary technology in tune with set market norms.
