Automatic Barbed Wire Making Machine Dealers in Amritsar

• Country of Origin: India
• Type: Automatic Barbed Wire Making Machine
• Weight: 1000-2000kg
• Color: Grey
• Voltage: 380V
• Condition: New
• Automatic Grade: Automatic
• Warrenty: 1 Year

the group of barbed wire with unidirectional twist require take up unit of rotary type and this is placed below the table of the barbing unit and mounted on the stands on which the prem barbing unit stands. the necessary transmission of power off the barbing unit is also incorporated. take-up unit for the reverse twist prem barbed wire as also mono barbed wire is same and can be supplied either twin take up or single take up unit. this take up unit is mounted on brackets on the stand at the front end of the prem barbed wire unit, the end from which the finished barbed wire emerged. the necessary power transmission of the barbing unit is incorporated. UTILITIES OF BARBED WIRE:-   (1) Barbed wire is used to protect land, farm, houses, playgrounds, college’s compound, universities, gardens from animals and thieves. (2) By using barbed fencing, you can save your crop, property from the animals and thieves. So nobody can enter in your property without main entrance.

With years of experience in this domain, we are indulged in providing a premium range of Automatic Barbed Wire Making Machine. We are a distinguished Manufacturer, Exporter and Supplier of Automatic Barbed Wire Making Machines from Punjab. Extensively used for barbing, twisting, cutting, feeding and coiling, the Automatic Barbed Wire Making Machine is equipped with sturdy gears and levers. We offer Automatic Barbed Wire Making Machine at pocket friendly prices. Features : Rust proof body Long service life Impeccable functionality Excellent performance   Technical Specifications : Robust in Structure, trouble free , easy to operate and capable of making wire of two ply and four bards. Barbed wire machine is of indigenous production, manufactured exclusively out of indigenous material under specialized and skilled management by Indian craftsman. The operations are so automatic that the operator is to stand by and watch the operations till the bobbin is full. Then the machine is stopped is replaced and restarted.

• Barb Spacing: 75 mm, 100 mm, 150 mm
• Output: 120-240 Barbs/Min
• Production Capacity: 600 -800 Kg

The group of barbed wire with unidirectional twist require take up unit of rotary type and this is placed below the table of the barbing unit and mounted on the stands on which the Bumra barbing unit stands. The necessary transmission of power off the barbing unit is also incorporated. Take-up unit for the reverse twist Bumra barbed wire as also Mono Barbed wire is same and can be supplied either twin take up or single take up unit. This take up unit is mounted on brackets on the stand at the front end of the Bumra barbed wire unit, the end from which the finished barbed wire emerged. The necessary power transmission of the barbing unit is incorporated.

• Shipping Dimensions :: 1970 x 1360 x 1150 mm
• Net / Gross Weight: 1100 / 1400 Kgs
• Model:: GBW
• Strand and Point Wire :: 12/12 SWG (i.e. 2.5 - 2.8 / 2.5 - 2.8 mm diameter)
• Tensile Strength :: Hard Bright, fully hot dip galvanized wire with under 30 to 55 Kg. F / mm
• Production Capacity :: 500 Kgs / 8 Hrs. shift for 12/12 SWG wire with 140 to 220 barbs / min. Capacity to coil bundles of 400 meters (bundle size 16" dia. x 10" width. weight: 40/50 Kgs)
• Barb Spacing :: 3" to 4" pitch, adjustable with additional gears in winding unit (optionally supplied)
• Motor :: 5 HP / 960 RPM
• Net / Gross Weight :: 1100 / 1400 Kgs.
• Shipping Dimensions :: 1970 x 1360 x 1150 mm
• Shipping Volume :: 3.10 m3

• Body Material: Stainless Steel
• Production Capacity: 500-600 kg/shift
• Voltage: 240 V
• Usage/Application: Wire Making
• Automation Grade: Automatic
• Machine Weight: 1400 Kg Approx
• Power: 5 HP
• Frequency: 50 Hz
• Machine Dimensions: 1970 x 1360 x 1150 mm
• Wire Diameter Range: 2.5 - 2.8 mm
• Brand Name: GEW
• Speed: 960 RPM
