Electric Cable Making Machine Dealers in Amritsar

A famed name, the company is entrusted with a task of making available high quality lot of Barbed Wire Making Machine. Buyers are required to place orders; timely deliveries of consignments are our primary concern.

We are offering allied brand barbed wire making machine. Adjustibility of parts easy maintenance operator has wasy approach in setting all arms, cutters making the machine parts fool-proof it ensures easier dismantling, assembling, loading, unloading as well consequent view over flow of formed wire.

• Country of Origin: India
• Type: Automatic Barbed Wire Making Machine
• Weight: 1000-2000kg
• Color: Grey
• Voltage: 380V
• Condition: New
• Automatic Grade: Automatic
• Warrenty: 1 Year

the group of barbed wire with unidirectional twist require take up unit of rotary type and this is placed below the table of the barbing unit and mounted on the stands on which the prem barbing unit stands. the necessary transmission of power off the barbing unit is also incorporated. take-up unit for the reverse twist prem barbed wire as also mono barbed wire is same and can be supplied either twin take up or single take up unit. this take up unit is mounted on brackets on the stand at the front end of the prem barbed wire unit, the end from which the finished barbed wire emerged. the necessary power transmission of the barbing unit is incorporated. UTILITIES OF BARBED WIRE:-   (1) Barbed wire is used to protect land, farm, houses, playgrounds, college’s compound, universities, gardens from animals and thieves. (2) By using barbed fencing, you can save your crop, property from the animals and thieves. So nobody can enter in your property without main entrance.

• Automatic Grade: Fully Automatic
• Production Capacity: 500-600 kg/shift
• Power: 5 HP
• Material: Mild Steel
• Packaging Size: Length-9, width-4, height-5 (in feet)
• Barb spacing: 2, 3, 4, 5, >5, 6 Inch
• Machine Weight: 1650 Kg Appx.
• Wire Type: GI Wire
• Gauge: 12 to 16 Gauge

Capable of making G.I. Wires of 3 types. Main ply two lines of 12G With 4 barbs made 12G wire at distance of about 3” or 75mm apart. Main ply two lines of 12G with 4 barbes made of 14G wire at distance of about 3” or 75mm apart. Main ply two lines of 14G with 4 barbes made of 14G wire at distance of about 3” or 75mm apart   Installation : The installation of the machine is quite simple and easy as that of any other machine,care being taken that the stands of the machine is securely bolted to the foundation and machine is properly aligned and leveled accurately.

• Type: Automatic
• Brand Name: J.J.

1. Main ply two lines of 12G with 4 barbs made 12G wire at a distance of about 3� or 75mm apart. 2. Main ply two lines of 12G with 4 barbs made 14G wire at a distance of about 3� or 75mm apart. 3. Main ply two lines of 14G with 4 barbs made 14G wire at a distance of about 3� or 75mm apart.

With years of experience in this domain, we are indulged in providing a premium range of Automatic Barbed Wire Making Machine. We are a distinguished Manufacturer, Exporter and Supplier of Automatic Barbed Wire Making Machines from Punjab. Extensively used for barbing, twisting, cutting, feeding and coiling, the Automatic Barbed Wire Making Machine is equipped with sturdy gears and levers. We offer Automatic Barbed Wire Making Machine at pocket friendly prices. Features : Rust proof body Long service life Impeccable functionality Excellent performance   Technical Specifications : Robust in Structure, trouble free , easy to operate and capable of making wire of two ply and four bards. Barbed wire machine is of indigenous production, manufactured exclusively out of indigenous material under specialized and skilled management by Indian craftsman. The operations are so automatic that the operator is to stand by and watch the operations till the bobbin is full. Then the machine is stopped is replaced and restarted.

Features : simple, sturdy & robust in designeasy to operatecapable of making barbed wire of two ply and four barbsindigenous productionassembled with multiple gears and loversaccurately timedperforms the multiple function of feeding, barbing, twisting, cutting & coilingworks without the aid of manual labor technical specifications : capable of making g.i. Wires of 3 types :main ply two lines of 12g with 4 barbs made 12g wire at distance of about 3” or 75mm apart.main ply two lines of 12g with 4 barbes made of 14g wire at distance of about 3” or 75mm apart.main ply two lines of 14g with 4 barbes made of 14g wire at distance of about 3” or 75mm apart.production : 500 to 600 kgs per shift of 8 hours.electric motor : 5 hp. X 960 rpmspace required : 15 ft. X 12 ft.weight : 1000 kgs approx.acessories : 4 nos. Wire stands. Installation : it is easy and simple to install the machine. The machine’s stands should be securely bolted to the foundation and the machine should be accurately aligned and leveled.

• Body Material: Stainless Steel
• Production Capacity: 500-600 kg/shift
• Voltage: 240 V
• Usage/Application: Wire Making
• Automation Grade: Automatic
• Machine Weight: 1400 Kg Approx
• Power: 5 HP
• Frequency: 50 Hz
• Machine Dimensions: 1970 x 1360 x 1150 mm
• Wire Diameter Range: 2.5 - 2.8 mm
• Brand Name: GEW
• Speed: 960 RPM

We are offering Welded Wire Mesh Machines to our clients which are highly efficient. These products are applauded for their superior design, efficiency and easy installation. These have a long service life with easy operational feature. Our supervisors make sure to carry out a strict quality check to ensure the quality and the durability of this machine Also we offer it in most economical rates.Features: Rust proof High efficiency Easy installation

The machine is extremely rigid to withstand overloading. The High Speed Winding Unit revolves at approximately 180 RPM. It produces both IOVA (Type A) and GLIDDEN (Type B) double ply Barbed Wire with 2 Point, 4 Point consecutively. he machine is designed in it's heavy structure using closed Grain Cast iron and steel. Easy Parts adjustments and easy Maintenance. Operator has an easy approach in setting all arms, cutters by making the machine parts fool proof. It ensures easier dismantling, assembling, loading, unloading as well as consequent view over flow of formed wire. The machine can also produce wire from 12/14 or 14/14 SWG Wire at the cost of production capacity.

3" to 4" pitch also adjustable with additional gears in winding unit whichever could be supplied only under special demand . Our major emphasis are upon its adjust ability of pars and easy maintenance. Operator has an easy approach in setting all arms, cutters by making the machine parts fool-proof. It ensures easier dismantling, assembling, loading unloading as well as consequent view over flow of formed wire. All the adjustable parts are altogether accessible and machine standards.

Cable blowing machine can blow OFC in PLB ducts 40 mm Dia to 50 mm dia at an velocity of 70 meters per minute and machine can accommodate cable size 14 mm dia to 25 mm dia of any configuration either armored or unarmored, machine is run by air drive system powered Ingersoll Rand and machine weighs only 38 kgs. It is very easy to lift from one work point to other point easily, operations of machine is very simple requires only two lever control and can be handled by semi-skilled person. We have sold so many machines in India, Middle East countries, African and Srilanka. Duct Collate size: multi collate sizes for 32mm, 40mm and 50mm in combined pack. The machine also comes with only 40 mm duct collate and 50 mm duct collate.

• Shipping Dimensions :: 1970 x 1360 x 1150 mm
• Net / Gross Weight: 1100 / 1400 Kgs
• Model:: GBW
• Strand and Point Wire :: 12/12 SWG (i.e. 2.5 - 2.8 / 2.5 - 2.8 mm diameter)
• Tensile Strength :: Hard Bright, fully hot dip galvanized wire with under 30 to 55 Kg. F / mm
• Production Capacity :: 500 Kgs / 8 Hrs. shift for 12/12 SWG wire with 140 to 220 barbs / min. Capacity to coil bundles of 400 meters (bundle size 16" dia. x 10" width. weight: 40/50 Kgs)
• Barb Spacing :: 3" to 4" pitch, adjustable with additional gears in winding unit (optionally supplied)
• Motor :: 5 HP / 960 RPM
• Net / Gross Weight :: 1100 / 1400 Kgs.
• Shipping Dimensions :: 1970 x 1360 x 1150 mm
• Shipping Volume :: 3.10 m3

barbed wire machinery, bolt making machines, Screw Making Machines

Reliable performance, easy to install and easy to operate makes our mesh wire making machine the preferred choice among customers. We are renowned manufacturer, exporter and supplier of mesh wire making machine from amritsar, punjab, india. The mesh wire making machines we make available are manufactured from excellent quality components and using advanced technologies to ensure optimum durability and corrosion resistance. Customers can purchase the machines in various technical specifications and at competitive rates.

Wire Nail Polishing Machine, U Nail Making Machine

barbed wire machines, Roll Forming Machines, bolt making machines

Automatic Head Trimming Machines, Head Slotting Machine
