Inspection Systems Dealers in Ankleshwar

The filled ampoules are loaded in to the infeed chute from where they are transferred in batches by an index wheel onto a linear transfer rack. The rack transfers the ampoules onto the inspection station, where spinners spin the ampoules at a predetermined RPM so that a vortex is formed. Illumination from behind the ampoules assists in light refraction of particles/fibers . An operator views six ampoules through a magnifying glass Salient features: •All contact parts in stainless steel.and approved engineering plastics. •Spinning of ampoule/vial.Magnifyed view with back lighting •Clear view of six ampoule/vial. •Modular and compact ejection system. •Rotation of spinners can be adjusted to give desired vortex on liquid •Easy access for cleaning and maintenance. •Large inspection to transport time ratio.. •Facility of repeat cycle. •PLC assisted failsafe rejection. •Counters for good and reject products. Technical Specifications: Output(Ampoules) : 60-72/minute Output(Vials) 48-56/minute Electrical Ratings : 3ph. 415V. 50 cps. (4 wire) 0-75 HP main motor 0-25 HP spinner motor Net Weight : Approx. -450 Kg. Handling Range (in mm) : Diameter Min. 9 Max. 15 mm Height Min. 60 Max. 116 mm

Inspection table is used to inspect the abnormalities in filling. Inspection table is equipment consisting of a three-track conveyor with a hood with lighting arrangement and visual inspection background of alternate black & white color. Inspection table have stainless steel structure with moving S.S. slat chain. Structure made out of S. S. square pipe & supported on adjustable bolts. Salient Featuers of Online Bottle Visula Inspection Machine A/c frequency variable drive. Direct gear drive. Length can be made as per customer requirement. PVC black & white board as per GMP norms. UHMW self lubrication guide below chain. SS elegantly matt finishing. Adjustable height of conveyor belt, to align with Other machine of the line Self-alignment bearing for easy maintenance. Rigid vibration free construction for trouble free performance Technical Specification of Online Bottle Visula Inspection Machine Direction of Movement** Left to Right Output * Up to 100 Containers/minute Number of Operator Four (2x2, Two Side Seated) Power Characteristics** 0.5 HP / 220 Volts / 50 Hz. Height of Conveyor ** 860 mm to 910 mm Machine Dimensions** 1880 mm (L) x 700 mm (W) x 1525 mm (H) Case Dimensions** 2150 mm (L) x 950 mm (W) x 1750 mm (H) Net Weight 200 Kgs. Gross Weight 425 Kgs. Approx

Optical Ampoule Vial Inspection Machine, ROTOCONE VACUUM DRYER
