Level Indicator Dealers in Ankleshwar

Suitable for continuous level indication of horizontal tank and mainly underground tank containing very hazardous and corrosive liquid in nature. It is covered in two units, one units fixed on mounting flange with guided cage assembly & float is connected to the S.S. pipe having imported magnet assembly.Second unit fixed on mounting flange. The magnet assembly moves up & down in the main S.S. pipe chamber. The float magnet is operated by magnetically coupled to the follower red magnet outside chamber which is mounted on front side of the main S.S. pipe.

Suitable for direct reading in atmospheric, batch tanks mounted parallel along with side of tank. As the level increases in side the tank, the level in the glass tube changes accordingly & gives local liquid level indication.

• Temperature: Up to 350° C
• Liquids: Acids/Alkalies/Solvents/Oils/ Lubricants/Liquid Gases Stored in Underground or Over Ground Tanks
• Density / Sp. Gravity: Minimum 0.6
• Tank Hight (Range): Up to 3000 mm
• Material of Wetted Parts: MS/CS/SS304/304L/316316L PTFE Lined SS/PVC/PP
• Connection: Flanged to ASA/BS/DIN/ Triclover
• Top Mounted Magnetic Level Indicator Viscosity: Up to 250 cp
• Top Mounted Magnetic Level Indicator Pressure: Up to 20 Kg/cm²

Top Mounted Magnetic Level Indicator is a Simple principle of mechanics & magnetism harnessed to offer an absolutely safe, reliable & trust worthly level indicator for dangerous & toxic liquids under high pressure & temperature. As the liquid level rises in the tank, the float is lifted up due tobuoyancy. The float carries a stem attached to it & on the other side of the stem a magnet is fixed. The float stem moves inside an SS enclose. External to this enclose is a glass tube, which carriesthe magnetic follower. Due to magnetic attraction, the magnet on the float stem & the magnetic follower also moves inside the glass tube, & the position of the follower can be read against the scale.
