AMF Panel Dealers in Bangalore

• Frequency: 50Hz
• Phase: Three Phase
• Country of Origin: India
• Brand Name: Unnatthi Control & Equipments
• Material: Mild Steel
• Power: 175 kVA
• Automation Grade: Automatic
• Rated Voltage: 440V
• Current: 5000 Amp

  AMF panel and generator packages are designed to provide emergency power during mains supply failure. During operation, the control panel of the AMF monitors the mains entering the building. If a mains failure occurs, the panel will disconnect the mains from the load, the generator is started and its output connected to the load. (The load being appliances, lights, etc in use within the house/office/factory at the time of mains failure). The generator continues to supply the building until the mains supply returns. The generator then automatically disconnects, stops and the mains is re-connected to the load. The AMF panel reverts to the standby mode ready to respond in case of another mains failure. Operation With the generator in 'Auto' mode, the incoming main is monitored continuously. If the mains voltage falls outside the preset limits, a 'mains failure' has occurred and the process of starting the generator set is initiated. Once the mains failure is recognised, the contacts are released to disconnect the load from the mains. The 'mains available' and 'mains on load' lamps extinguish. There is a pre-set and adjustable time delay before the generator is started. This avoids unnecessary starting of the generator when very short duration mains breaks occur e.g. 2 or 3 second breaks due to lightning strikes. After the delay, the engine fuel solenoid / ignition system is energised. A pre-heat period begins for generators fitted with indirect injection diesel engines. The choke is operated on petrol-engined sets. The starter motor relay energises and the engine is cranked for a pre-set period (typically 10 seconds). If the engine fires up and the speed increases through the 'crank-cut' threshold, then the starter motor is dis-engaged. Alternatively, if the engine does not start during the first crank period then the starter de-energises for an equal rest period before energising for another attempt. If the engine has not started after the last 'crank' period, then the engine fuel solenoid / ignition is de-energised and the generator is deemed to have failed to start and the appropriate annunciator is illuminated. Assuming that the generator has started during one of the attempts, the alternator output is checked to ensure that it is within specification. If so, then the generator contactor is energised and the load is supplied from the generator. In normal circumstances, the period from mains failure occurring to generator supply being connected is about 20 seconds. During generator operation, the engine oil pressure and temperatures are monitored and should an abnormality occur, the generator will immediately be shutdown and the appropriate annunciator illuminated. When the mains supply returns, the mains available lamp is illuminated within specified limits. The main is then monitored for a pre-set time to ensure that the supply is stable. The generator contactor is then de-energised and the mains contactor energised so that the mains supply is restored to the load. The 'alternator available' and 'alternator on-load' lamps extinguish and 'mains on load' lamp is illuminated. A short break in approximately 1 second occurs whilst the changeover is complete. The generator is 'run-on' for a cooling down period (adjustable up to 30 minutes) before the fuel solenoid / ignition system is de-energised and the engine stops. The operational cycle is then complete and the generator returns to a standby condition. During this time the starter battery is maintained in a charged condition by a 'trickle' charger supplied from the mains.

• Material: Mild Steel
• Certification: ISI Certified
• Feature: Maintenance Free, Perfect Shape, Shock Proof
• Frequency: 50Hz
• Power: AC
• Rated Voltage: 230 Watt (W)

  Our organization is engaged in manufacturing top quality AMF control panels. These panels are available in various models and sizes as per clients’ specifications. Use of quality raw material makes them cost efficient and ensure long life of the AMF panel. The AMF panels that we manufacture helps to start the generator in case of mains failure. It immediately gets the power back without any attended and loss of work. Load is transferred from mains to the generator. Therefore there is no need to transfer the load by means of changeover switch. AMF resumes the supply in just a few seconds in case of main failure.   Attributes : Efficient working Corrosion resistant Diligently wired Pests free Shock proof Easy operations Have mechanical and or electrical interlocked pole contactors Used for : Automatic changeover from mains to stand-by generator at the time of power failure Where the generators are installed between main AC and load Applications : Foundries Apartments Textile industry Sugar industry Chemical industry Telecommunications

We are well-known manufacturers of Automatic Mains Failure Panel including Protection for DG sets. It uses an advance technology to make an easy and trouble-free Genset control. Our panel comes with various functions and timers which help in the efficient running of the AMF panels. It also consists of the metering facilities for monitoring of the frequency/current/voltage. We can also customize it according to the client specifications and details. We offer automatic mains failure panels or automatic AMF panels, that are installed for automatic changeover from mains to stand-by generator at the time of power failure. Our this range of AMF panel includes automatic mains failure detectcion and starting the D.G. set and putting it online with current limit, battery charger, power inverters, automatic changeover and sine wave inverters.

• Feature: Fully automatic operation Option of manual start & transfer of load on DG

AMF panels find their application in Automation of Diesel generators. These panels are used to control the DG sets with respect to the mains condition. These panels are fitted with controller which senses the mains voltage & single phasing. Once mains failure is sensed, the DG start is provided & DG is started. Once DG is running, the loads are automatically transferred to the DG. Same way, when the mains supply becomes alright, DG is stopped & loads are automatically transferred to mains.

• Application: Generator
• Frequency: 50 to 60 Hz
• Material: Stainless steel
• IP Rating: IP44
• Phase Type: Three Phase
• Voltage (V): 220/440 V
• Power: 5 KVA to 1000 KVA

• Material: Mild Steel
• Usage/Application: Industrial
• Phase Type: 3 - Phase
• Voltage: 450 V
• Current Range: 50 A
• Automatic Grade: Automatic
• IP Rating: IP33

We offer AMF Panels that are used for emergency power supply during the main power supply failure. These AMF panels are used for automatic operation of Gen set as it helps to rotate starting gear of Gen set after main supply is cut. AMF Panels are used in various application areas such as processing plants, generators, engineering units, hospitals, offices etc.

• Frequency: 50 Hz
• Shape: Rectangular
• Usage/Application: Commercial
• Phase Type: Three Phase
• Voltage: 415V
• Mounting Type: Free Stand
• Surface Finish: Powder Coated
• Humidity: 95%
• Body Material: Mild Steel

Being a prominent name in the industry, we are specialized in offering wide array of Syncronizing Panels. It ensures reliability and continuity of electrical power supply and also has the flexibility for further expansion. Our company is backed by a proficient team whose experience has helped the company to continue as a leading manufacturers and suppliers of Syncronizing panel

These are the panels mainly made for generator systems. The AMF Panel works on the following principle: When EB Supply is OFF; the DG supply would be ON within the fraction of seconds automatically. Panel contains Control Relays, Control MCBs, Indications, ACDC Meters, Frequency meter, Energy meter, Earth Leakage Relays.At the incoming side, this panel will have two incomers usually HRC Fuses and one common switch. Through the AMF Relay, the panel works automatically.Inside the panel there will be one relay for both under & over Voltage. If the incoming supply is under voltage or over, then entire system would trip. Hooter is used in the switchgears for indication of EB supply when DG Supply is in working condition.

We are a reputed manufacturer of APFC/AMF Panels that is immensely used in various industries for emergency power supply. APFC/AMF Panel means Automatic Main Failure Panel and it is generally connected with generators. It detects the power failure and starts the generator within a certain time limit and automatically switches off when electricity comes.

We are of the renowned manufacturers of Auto Mains Failure (AMF) Panelswhich plays a vital role in power supply system. These panels are designed on the basis of plant capacity. The functioning of this panel start when the mains supply fails. After the main supply failure is, detected & necessary signals are provided to D.G. set, it starts and thus the stand by supply is made on time being. When the mains supply resumes the stand by supply is disconnected & the system goes on mains again. Before supplying it to our clients, we conduct several tests to ensure excellent reliability and utility.

AMF Panels   We manufacture and supply of Automatic Mains Failure(AMF). Our Electrical AMF Panels are durable and meet customer's requirements. Our team customizes the product range in accordance with customer requirements. These Customized AMF Panels can be availed in various sizes as per customer's requirement.Salient Features: Generator starting, stopping and monitoring sequence. Automatic shutdown during DG fault. Continuous monitoring of three-phase voltage/current/frequency of mains and DG along with battery voltage of DG. Configurable Solid state Outputs.

Micro Mann GC-09 is a mastermind in the field of generators. The GC-09 is an Automatic Mains Failure module with generator Controlling facilities and field programmable timers. Unique Feature:1.Microcontroller based2.Power on Reset (Auto Test)3.Dual mode operation Energize to RUN and Energize to STOP4.Auto and Manual operation5.Wide range of fault detection6.Field programmable Digital timers (with Default settings t1-t5)7.Designed compact, Weight less, and clear display along with high visibility fault indicating LED’s.8.Eco –friendly, with use of SMD components.   Application:Suitable for all rating of DG sets for Auto/start stop and load changeover application

Fully automatic synchronizing panels operated by microprocessor based relays, Auto synchronizing, manual synchronizing, auto load sharing, active and reactive power management with protection etc., we specialize in offering all-inclusive range of synchronizing panels. Our user friendly and easy to keep up panels can be expanded as per requirements due to their flexibility.

When working with network system components, it is a fact that you cannot connect them and have them work properly, unless you have their voltage curves coincide. If this is not the case, the electrical stresses that they must suffer will become too high and might lead to the distortion of the equipment that comprises the system. An uninterruptible power supply (UPS) system is your bridge between mains power and your backup generators. Regulation of the generators is required manually without AMF panels, and that can mean lost data, potential damage to electrical equipment and huge amounts of interruption. AMF panels which are also called automatic transfer switch panels (ATS) that make the power switch to emergency standby generators in the incident of a significant loss of mains power. We manufacture AMF panels, generally as part of an inclusive automatic standby power solution which links ATS, UPS and standby generators with remote monitoring and associated security and safety features.

We are into offering high performing amf panel that is highly appreciated by esteemed clients. The amf panels range is offered upto 2500 amp meters and is suitable for measuring volatage and frequency. The amf panel range is called multi data meter and is offered to the valued cleints at market leading rates. salient features high performancehigh efficiencylonger service lifesuitable for measuring volatage and frequency used in electrical industry
