Exposing Machine Dealers in Bangalore

World class metal halide screen exposing machine. Ideal machine for all types of screen especially high density screens. Easy operation through hydraulic spring's system.  Electronic ballast switching for zero maintenance. Instant start halide lamp for long service life. High quality rubber blanks for perfect hugging of the screens. Microprocessor for controlled exposing.

Automated & Semi-automated UV Exposure Machine The fundamental objective of a dry-film laminator is to intimately bond the dry-film resin and the copper surface of the board, avoiding any air entrapment whatsoever. From a physical standpoint, this can only be correctly performed in the moment that the resin reaches the contact point, in a very fluid/gel like status. The high pressure of hot lamination rolls and a sufficient temperature of the board surface, contributes to a successful lamination process. Pits and scratches on the copper surface can then be totally filled with dry-film as shown in below figure. Manual laminators are very close to this ideal lamination condition, since in these machines, the dry-film envelops the hot roll for more than a 1/4 of its circumference, maintaining heat and becoming gel like before coming into contact with the board surface. But generally, in the conventional process, boards are not preheated and therefore, the result is not perfect. Refer below figure FEATURES Very high productivity/quality Tacking and cutting on flight (no stop process) Lamination rolls vibration Very high lamination pressure Adjustable dry-film preheating Excellent board preheating High lamination speed Suitable for inner layer and rigid board

• Grade: Manual
• Type: Plate Exposure
• Automatic Grade: Automatic
• Object to be Printed: T-Shirt, Banner

Features: World class metal halide screen exposing machine. Ideal machine for all types of screen especially high density screens. Easy operation through hydraulic spring's system.  Electronic ballast switching for zero maintenance. Instant start halide lamp for long service life. High quality rubber blanks for perfect hugging of the screens. Microprocessor for controlled exposing.

Screen Exposing Machine is referred as screen printing exposing machine. The specification of this printing machine are dimension (L*H*W) (mm): 1000*1200*1200, 1200*1800*1200 etc, voltage (V): 220,380 etc, power (kW): 2.2, 5 etc, current (A): 5, 17 etc and frequency (Hz): 5060. It is an automated machine incorporated with digital timer and light sensor. It is widely used for printing all kinds of rolling material like film, paper and PVC.

• Capacity: 100 Screen Per Day
• Voltage: 220 V
• Material: MS
• Power: 1 kW
• Size: 42 x 35 inch
• Phase: Single Phase
• Weight: 48 kg
• Air Pressure: 3 CFM
• Model/Type: VacuumX
• Operating Temperature: 60 Degree Celsius
