Farmax Technologies Pvt Ltd JP Nagar, Bangalore, Karnataka

Technical Specification CAPACITY :1 KVA 25 KVA 1PH Air Cooled : 3 KVA 100 KVA 3PH Air Cooled :100 KVA 1500 KVA 3PH Oil Cooled INPUT VOLTAGE : 170V 270V 1PH AC : 340V 460V 3PH OUTPUT VOLTAGE :200V 220V 230V 1PH : 380V 400V 415V 3PH OUTPUT VOLTAGE REGULATION :+ 1% at No-Load to Full-Load. OPERATING FREQUENCY : 47 Hz 53 Hz SYSTEM OPERATION : Un-Balanced 4 Wires SPEED OF CORRECTION : 35VSec � Phase to Neutral WAVE FORM DISTORTION : Nil OUTPUT WAVE FORM : True Reproduction of Input INSULATION : CLASS � B, F & H OPERATING TEMPERATURE

Protection low voltage protection. High voltage protection. Short circuit protection. Over load protection. Single phase preventer. Indications input – on. Output – on. Input – low. Input – high. Output cut-off.

Technical Specification CAPACITY : 1KVA 25KVA 1PH : 3KVA 75KVA 3PH [Air Cooled] : 75KVA 500KVA 3PH [Oil Cooled] PRIMARY VOLTAGE : 200220V 1PH AC : 380400415V 3PH AC SECONDARY VOLTAGE : 110230V 1PH : 220380400415V 3PH SYSTEM : Delta Star : Star Star
