Heat Treating Services in Bangalore

• Hot zone size :: 850 (W), 550(H), 1100(D)
• Pressure :: 5 bar (A)

Vacuum heat treatment prevents distortion of the material and provides an oxidation free surface. HHV’s cold - walled horizontal vacuum heat treatment furnace has oil and gas quenching capability. The furnace has a horizontally mounted double walled water cooled chamber fabricated with carbon steel in accordance with ASME code. It has a diameter of 1100 mm, wall thickness of 12mm and a cylindrical length of 1000mm housing the hot zone of size of 730mm (D) x 750mm Depth. A fork lift facility has been provided for loading and unloading of charge of up to 200 kg in weight. The furnace provides a uniform operating temperature of up to 1250 deg.C in the hot zone utilizing resistance heating by molybdenum band type heating elements. A vacuum system comprising a high speed diffusion pump in combination with roots and rotary pumps enables achieving a vacuum of 1x10-5 m.bar.

• Model Number: BEV008
• Place of Origin: Karnataka, India
• Brand Name: Universal Auto Gears LLP
• After-sales Service Provided: No overseas service provided
• Supply Ability: 1500 Kilogram/Kilograms per Month

we are providing The Commercial Heat Treatment Servise.Division at HIGHTEMP has been in operation since 1991. Today, we have heat treat centers at close proximity to major automotive units at four different locations across India - Bangalore (Karnataka), Pune (Maharashtra), Gurgaon (Haryana) and Kancheepuram (Tamil Nadu). The prowess of the Commercial Heat Treatment offering at HIGHTEMP has its roots in a combination of factors. Modern facilities, state-of-the-art equipment, well equipped metallurgical laboratory and trained & competent personnel � backed by controlled atmosphere furnaces, auxiliary equipments and advanced process control systems. HIGHTEMP has earned a strong reputation for providing reliable and high quality heat treatment services at competitive prices � with an unflinching commitment to exemplary quality assurance and on time delivery.

Induction hardening, induction anneling , silver & copper brazing, carburiurising & hardening, toughfning, anneling, through hardening, stress releving.
