Hydraulic Cylinder Parts Dealers in Bangalore

Extremely compact for positioning and fixturing. Fine positioning and convenient installation. DESCRIPTION:These cylinders can be threaded directly into manifold/ fixture body. Suitable for positioning, clamping or ejecting the work piece. These cylinders can be used in fixtures where space is a constraint. Special aluminium washer provides self sealing. Aluminium washer is included in the delivery.FEATURES: Threaded cylinder with internal threaded piston rod. Can be lined up to very close dimensions, as close as hexagonal nut (min 35 mm). Min./ Max. Operating Pressure 5 / 250 bar. NOTE : Do not load in retracted condition. Refer general design notes before selection & use. Ordering specification for seal kit. Add prefix "SK" to the model Number. Keep back pressure to minimum for smooth working of cylinder. (Refer General Recommendations sheet Page No. R1). Tighten manifold cylinder to specified tightening torque Tt mentioned in the specification chart.

We are one of the leading manufacturers of Hydraulic and Pneumatic Cylinders and Power Packs based at Bangalore. Since 1991 we are in this field and supplying good quality products as per customer requirements and at reasonable price. Quality assurance is an integral part of our manufacturing process. We have the team of qualified Engineers and Professionals having vast knowledge of Designing Hydraulics, Sealing systems and Mechanical properties with a focus on innovation which ensures maximum performance and quality of the products. We are supplying to various customers across India and also exporting to Australia & South Africa, for Material Handling Equipments, Steel Mills, Rig Application and Earth Moving Equipments. Apart from this we undertake Reconditioning of Hydraulic & Pneumatic Cylinders. We are also the supplier of Hydraulic Components and Accessories like valves, Seal Kits etc. Cylinders are of Double Acting Single Acting type and as per customer drawing. Our standard guaranteewarranty terms are 12 months from the date of dispatch subject to material and manufacturing defects only. Non metallic items, Wear and Tear items are not covered under this warranty. Any spare can be provided on chargeable basis. Special type of painting charges will be extra at actual. We welcome our customer, or their clients representative for inspection at our Works. We will send inspection call once cylinders are ready for dispatch from Our end along with duly tested & inspected reports and we will follow your instructions for our further action of dispatch of cylinders. Product Quick Details:- From Bore Size 40MM to 800MM Stroke Length Upto 10000MM WORKING Pressure upto 600bar Tube: - High Tensile ST52Equivalent Piston Rod & Piston: - EN8 C45 IS1570 Seals: - ParkerMerkelHalliteEquivalent Testing Cylinders as per: - IS standard test procedure. (BIS 10585-1983).

• Material: Steel
• Color: Black
• Brand: FLOWTEK, Taiwan
• Product Type: Hydraulic Link Clamp - Single Acting
• Clamp Type: Link Type
• Size: Bore dia. 22, 25 , 32, 40, 50, 63 mm

• Material: Carbon Steel
• Thickness: 0-4 mm, 4-8 mm,
• Condition: New, Used
• Color: Black
• Finishing: Polished

We are a leading manufacturer, exporter and supplier of Compact Cylinders and are situated in Bangalore, Karnataka. We offer ZNRA/192000/M with male piston thread. Our compact cylinders comply with ISO/21287 pitch and mounting to VDMA 24562. These come with standard magnetic piston. Seal ensures long life and low friction during operation. Switches can be mounted flush too. Additional stoke up to 15 times the size of the bore is available on request. Details : The cylinders are double acting and non-cushioned type Medium is compressed and filtered air, both lubricated and non lubricated Operating pressure is 1 to 10 bar and operating temperature ranges from -5oC to 80oC End covers, piston and barrel of the cylinder is made from anodized aluminium alloy Piston rod is made of martensitic stainless steel, the rod seals are of polyurethane and piston seals and O-rings are made of nitrile rubber   More about Industrial CylindersWe : We are the best manufacturer, exporter and supplier of Compact Cylinders and our manufacturing unit is in Bangalore, Karnataka. We also offer other industrial cylinders such as, Imperial Cylinders, Magnetic Cylinders, Pneumatic Cylinders, Positioner Cylinders, Heavy Duty Cylinders, Impact Cylinders, Hydraulic Cylinders and Standard Cylinders. We accept bulk orders and ensure punctual delivery with proper packaging.

• Material: Mild Steel
• Usage/Application: Heavy Duty Vehicle Lifting
• Corrosion Resistance: Yes
• Hardness: 50-60 HRC
• Tensile Strength: 300-400 MPa

Compact cylinder, We design and develop these hydraulic cylinders using the high grade raw materials to ensure durability and high tensile strength. We offer the hydraulic cylinders that have been known among our clients for their quality, reliability and performance. Our hydraulic cylinders have acquired certificates from various certification bodies. These hydraulic cylinders are manufactured under strict supervision of our quality assurance department that makes it easy to handle and install.

We have established ourselves as prime Manufacturer and Supplier of Hydraulic Swing Clamp Cylinder in India. The Swing Clamp Cylinder is precisely engineered using qualitative materials, by strictly abiding international quality norms. Moreover, each Hydraulic Swing Clamp Cylinder is exclusively designed keeping in mind unique requirements of our clients. These are available from us at economical prices. Owing to our large production facility, even bulk orders are promptly catered.Features: Optimum rotational capability Space saver Low maintenance

• Country of Origin: India
• Type: Hydraulic Cylinder
• Piston Diameter (mm): 105
• Piston Stroke (mm): 15
• Draw Bar Pull Side (kN): 23.5
• Draw Bar Push Side (kN): 24.5
• Max Operating Pressure (MPa): 3.9
• Max Speed: 8000rpm
• Moment of Inertia (kg.m2): 0.012
• Net Weight (kg): 9

Our payment terms and conditions and easily comprehensible and our methods are practical. We do not impose hidden charges and ensure business is carried out ethically. We have achieved great heights of success by providing top-notch array of Pneumatic Cylinder. We make available, Pneumatic Cylinder, which is acclaimed for its flawless make.

Light weight construction, sleek design. Miniature ISO range : 12, 16, 20, 25 mm bore dia. conforming to ISO 6432. Medium ISO range : 32, 40, 50, 63, 80 and 100 mm bore dia. conforming to ISO 6431. "Add on" feature for mountings available on standard ISO range.

Highly compact, accurate, and rigid LCM series linear slide (φ4.5/ φ6/ φ8). - Ideal for highly accurate positioning - Highly accurate 0.005mm sliding parallelism and 0.3mm installation parallelism are ensured, making this actuator ideal for positioning. - Ultimate pursuit of downsizing The cylinder, linear guide, and slide table have been integrated into a highly compact unit.

• Country of Origin: Made in India
• Brand Name: PREAC
• Model Name/Number: 4451
