Network Storage Enclosure Dealers in Bangalore

• Country of Origin: India
• Type: Server Rack
• Material: Aluminium, Metal, Steel
• Shape: Rectangular, Square
• Thickness: 0-5mm
• Color: Black, Grey
• Pattern: Plain
• Condition: New

Shree Devi Fabrication is the well known telecom enclosure manufacturers in Bangalore, India. These enclosures protect equipment needed for communication which is conducted over a distance. So far we have manufactured an extensive range of telecom enclosures for various indoor and outdoor telecom applications. Our entire range is manufactured using high quality materials that can last for a longer time and available in different sizes and colors.Moreover, we manufacture and supply these enclosures in different configurations so as to match up the exact requirements. Based in Bangalore, we have been constantly improving our manufacturing methodology to increase the overall performance of our enclosures and quality is also checked at each and every stage of production.

• Depth: 300 mm
• Height: 1150 mm
• Door Lockable: Yes
• Material: CRCA Sheet
• Shape: Rectangular
• Width: 450 mm

• Basic Frame: Steel folder
• Construction: Welded
• Top And Bottom Cover: Integrated to Frame with Cable entry exit cut outs
• Front Door: Lockable Toughened Glass Door OR Lockable Perforated steel Doors
• Rear Doors: Lockable steel Doors -Plain / Vented / Perforated
• Std Equipment Mounting: Din std 10 mm Sq Slots
• Standard Finish: Powder coated
• Standard Colour: Grey And Off White OR Black
• Standard Mounting: Caster wheels
• Static Load: 350Kg with casters 750Kg with Levelers / Plinth

• Material: MS Enclosure
• Shape: Rectangular / Square
• Color: RAL 7035
• Size: 6U to 45U
• Brand Name: BCH Electric Limited
• Country of Origin: Made in India
• Usage/Application: Networking Rack
• Model Name/Number: BCH - BIL-W-6-5504
• Product Type: Wall Mount
• Cabinet Type: Wall Mount / Networking Rack / Server Rack

echnical Data: Basic Section Steel Tube Construction Welded Standard Finished Black Powder Coated Standard Mounting Bolt& Nut Anchor Bolts Note : Other Color powder coating on Request

• Size: 82SU
• Height(mm): 2200
• Width(mm): 600

Standard configuration of Rackman cabinet comprises of a top, base and 2 sides with integrated Rackman equipment mounting slots. Rackman racks ships fully assembled allowing for quick deployment. Standard rack height is approx 2200mm giving 82 SU(1 SU = 1 system unit = 25mm)of equipment mounting space. External width of the Rackman rack is 600mm. Rackman racks telecom racks are available in 3 standard depths: 300mm, 450mm and 600mm. A comprehensive range of options and accessories for Rackman racks is available. For instance, front glass door, rear panel and plain steel door, simple & advanced DC power distribution panels, exhaust fan kit etc. [Optional] Hold down bracket protects add on cards from shocks and vibrations. Chassis body made from heavy duty steel and powder coated with polyester paint. 2 post Rackman racks with a comprehensive range of accessories are also offered. To fully meet customers requirements we can modify & customize Rackman racks. Using our 19" conversion kit the Rackman cabinet can be converted into a 19" (EIA-310-D) compliant cabinet. Also Rackman rack can accommodate(mount) 19" brackets provide flexibility to the Rackman telecommunication rack accessories page. Technical Data Dimensions are in mm. 1SU = 25mm. Meterial of construction for Rackman rack : Top, bottom and sides is 1.6mm mild steel. The rack top, bottom and sides are MIG welded together for superior strength, rigidity and finish. Or as per customer's specifications. Finish: The Rackman racks are power coated Grey (Basic rack: Munshell Grey, Doors ans accessories: Bone Grey) or full Black.
