Stabilizers Dealers in Bangalore

Low Voltage Protection. High Voltage Protection. Short Circuit Protection. Over Load Protection. Single Phase Preventer. Indications Input – ON. Output – ON. Panel Control Input / Output Selector through soft key. Auto / Manual Selector Switch. Voltage Increase / Decrease through soft key.

Oil cooled servo stabilizer is generally 3 phase stabilizer which starts from 50KVA and goes up to 2500KVA.

Our Servo Stabilizers have the largest satisfied customer base. Dedicated to providing environment friendly quality solutions and commitment to delight customers with unique value propositions.

• Color: Black

Micro controller based lcd tv voltage stabilizer. With low voltage & high voltage cut- off. With time dealy of 5 seconds.

• Type: Servo Voltage Stabilizer
• Certification: ISO9001-2015 CERTIFIED
• Color: Grey, Sky Blue
• Feature: Auto Cut, Easy Operate, Shocked Proof, Stable Performance, Works In Low Voltage
• Voltage: 440V
• Condition: New
• Output Type: AC Single Phase, AC Three Phase
• Frequency: 50hz
• Automatic Grade: Automatic
• Warrenty: 1year
• Produce Power: 10-15kw
• Country of Origin: India
• Brand Name: OPTEK
• Application: AC VOLTAGE STABILIZE
• Phase: 3PHASE
• Brand Name: OPTEK
• Application: AC VOLTAGE STABILIZE
• Phase: 3PHASE

PANEL INDICATIONSInput     - ONOutput  - ONInput     - LowInput     - High PANEL METERSVolt Meter With Selector Switch to read Input/Output Voltages, phase to phase and phase to neutral.SAILENT FEATURESHigh Overload capacity Higher overload capabilities for high starting and regenerative currents repeatedfrequency in CNC Machines.Fast Correction  Fastest rate of correction up to 70 V/sec.No Hunting, No Oscillations, Machine - Wound Variable Auto Transformer, with special Carbon Brush to minimizeNo Noise Generation carbon deposit and for smooth commutation.SERVO CONTROLLED VOLTAGE STABILIZERS ARE AVAILABLE IN TWO MODELSWith analog meterWith digital meteredCAPACITIES1)1kva onwards in 1 PH2)3kva onwards in 3 PH

With the use of latest technology and Machinery, we Manufacture and Supply high quality Single Phase Air Cooled Stabilizer. Backed up by a team of experienced members, we produce supreme Single Phase - Air Cooled I KVA to 100 KVA. To ensure protection of sensitive electronic and electrical equipments, we use latest technology and only certified components in the manufacturing process. We are known for providing both Off-the-shelf and customized Single Phase Air Cooled Stabilizer. We have gained the trust of our clients for delivering all orders on time. For affordable prices, contact us.Technical Specifications : Input Voltage : 170V to 270V Normal Range Input Voltage : 140V to 270V Extended Range Input Voltage : 110V to 270V super Extended Range Output Voltage : 230V +/-1% (Can be Adjustable from 220V to 240V) Output Regulation : +/-1% of the set output voltage over specified input range from No Load to full load Output Waveform : True reproduction of input Frequency : 50 Hz Efficiency : 98% Correction : 70v/Sec Effect of load Power factor : Nil Operational Temperature : 55oC Voltage Selector Switch to read input and output voltage

• Brand Name: EXCELON
• Application: Voltage stabilization
• Phase: Three Phase
• Efficiency: 98%
• Cooling: AIR/ OIL COOLED
• Model Number: SCVS 3 Phase
• Place of Origin: Bangalore
• Input voltage of 1KVA - 150KVA SINGLE PHASE: 170 V - 270 V
• Input Voltage 3 Phase: 340 V - 470 V
• OUTPUT REGULATION: +/-1%
• RATE OF CORRECTION: 70 V / Sec Ph-Ph
• CONTROL: MICRO PROCESSOR
• DUTY CYCLE: CONTINUOUS
• PROTECTION: HIGH VOLTAGE , LOW VOLTAGE , SINGLE PHASING , MOTOR PROTECTION

• Brand Name: ISTAB
• Shelf Life: 24 MONTHS
• Place of Origin: INDIA
• WHITE: FREE FLOWING POWDER
• RICH CREAMY TEXTURE: BETTER OUTPUT

A special blend of stabilizing and emulsifing system is designed and developed for the dessert industry. Istab which is a complete system of emulsifier stabilizer which is standarized blends of guar gum and hydrocolloids from vegetable and seaweed sources. Since istab is designed to give consistent mix viscosities over a period of continuous supply in order to minimize variation at user lever hereby saving the user's valuable time in adjusting amount of different ingredients for stabilization & emulsification. The growth of ice crystals during the processing and storage of ice cream is one of the biggest challenge faced by ice cream manufacturer. Different grades for used for different applications: istab reg: a combination of emulsifier of vegetable origin and permitted stabilizers designed for use in all types of freezers. Istab fine: a premium combination of emulsifier of vegetable origin and permitted stabilizers designed for use in all types of freezers setting new standards, formulated to with stand temperature variation during distrbution andor scooping operations. istab icy: an economical modern combination of stabilizers together with emulsifiers of vegetable origin designed for use in water ice, ice lollies and other frozen desserts. Istab gel: a complete system of emulsifier & stabilizer which is standardized blends of hydrocolloids from vegetable and seaweed sources. This product is specially designed to offer the user the option of use the stabilizer in variety of gelato preparation with different fatsolid contents, by varying only the percentage of stabilizer to be incorporated in the mix, depending upon the fat content in the mix. Istab ultra: a modern combination of permitted stabilizersdesigned for use in a very wide range of frozen confectionery (sorbet, sherbet, thick shakes).

Features . High response, low inertia rugged A. C. servo motor . Critically damped response on all loadssupply conditionsli> . Energy savings due to high efficiency and superior transformer design . High quality raw materials used − prime grade CRGO lamination and high purity electrolytic copper wiresstrips used . High speeds of correction up to 35Vsec for three phase and 20Vsec for single phase . Machine wound variacs with special carbon brushes for enhanced life . Simple, systematic construction for dependability and ease of maintenance . Solid state control circuitry

Energx servo voltage stabilizers consists of three basic components a motorized variable transformer, a buck boost transformer, and a controller. Input power is applied across the motor driven variable transformer Which has a center tap that divides that variable transformer into bucking and boosting voltages areas. The buck-boost transformer is a fixed ratio isolation transformer capable of high amperes at low voltage. The ratio of the transformer is determined by the amount of voltage needed to buck or boost the input line to maintain the specified output level. The buck boost transformer secondary is wired in series with the load and the primary is connected across the variable transformers "Center tap & brush terminals. Depending on which side of the "center tap" (the variable transformer brush is positioned, the variable/buck-boost transformer system will add to (boost) or subtract from (buck) the Input line voltage. The further the variable transformer brush is from the "center tap" the more bucking or boosting of voltage will occur. The key to the proven reliability and long trouble free service life of a Energx Voltage Stabilizer is in the combination of a motor driven variable transformer With buck boost transformer technology.

• Country of Origin: Made in India
• Brand Name: POWERTECH
• Features: Optimum output, Quality tested
• Mounting Type: Wall Mounting
• Capacity: UPTO 55
• Phase: Single Phase
• Model Name/Number: PT305
• Output Voltage: 210V TO 250V
• Current : 2 AMPS
• Input Voltage: 100V TO 290V

Advantages.. Quick, steady and accurate correction of voltage Constant output voltage, despite load current variations Balanced output voltage, irrespective of input unbalance Overall energy saving - above 98% efficiency Increased life of your equipment, reduced heating and minimal losses Optional features include additional metering, surge suppression, voltage cut-off, overload protection, single phase prevention, bypass mechanism, Soft Start, time delay, audio-visual alarms, trips for abnormalities, etc. Features of Servo Voltage Stabilizer : Fully Solid State Control Circuit + 1.0%Regulation No Wave-form Distortion High Efficiency of 98% on full load Auto/Manual Operation Facility Over Voltage & Under Voltage Protection: With this feature, the unit will automatically switch off when the output voltage remains for certain time above or below a certain preset voltage limit. Overload protection to switch off the unit when the load current remains at a value higher than the rated value Extended input Range 140-280 V/110-260 V/90-260V or other volatge range on request. 110 V (output) can also be supplied. Built in spike suppressor. Single Phasing Preventor for three phase Units AM Meter with/without switch. Manual By Pass facility Features: MICRO-CONTROLLER BASED Intelligent Control Design. Display Indications (Status & Fault) CCCV Technology with Auto Trickle Mode Smart Overload Sense and Short Circuit Protection Battery State Monitoring Easily Serviceable Cold start function

Powertec systems are offering Servo Controlled Voltage Stabilizers to our customers. To cater to the critical requirements of our clients from all strata of industrial, commercial and residential sectors we offer our own manufactured systems and back up our supply with products from some of the most reliable names in the industry.

Method of operations servo controlled voltage stabilizers maintain accurate output by feedback controllingm by servo motor. the input line is connected in series with the secondary winding of a buck boost transformer. The secondary will get additive or subtract voltage induced from its primary. When the input is low, the secondary will have additive voltage to give boosted output and vice versa. the primary of this buck – boost transformer is connected to the fixed tap and variable point of the variable transformer which is connected across the input supply. the position of the variable point with respect to the fixed tap point determines the amount of primary voltage and hence the secondary voltage of the transformer which becomes additive or subtract. Thus the input is boosted or bucked by the series connected secondary wiring corresponding to the position of the variable point of the variable transformer. the variable point is driven by a servo motor in the forward or reverse directions. the forward or reverse signals is given through a controller circuit which is energized by an output sensing transformer. the controller circuit will be giving forward or reverse signals to the motor till the ouiput is corrected to the required value. as sensed by the sensing transformer if the variation in the input voltage goes beyond the specified range. the brush arm of the variable transformer will be driven to either of the ends, thus unable to correct the output further. This however is likely to cause damage to the variacs, motor etc. To avoid the same limit switches are provided at both the ends of the variacs winding so that the brush arm on reaching the end will automatically cut off the supply to the motor and prevent further movement. if the variation in the input voltage revives to within the specified range, the supply to the motor comes into function automatically to set the output voltage to its specified level also when the limit

• Type: Stabilizer
• Weight: 0.5-1kg
• Color: Black
• Voltage: 110V
• Output Type: AC Single Phase
• Power: 10-15kw
• Cooling System: Air Cooling
• Warrenty: 1year

SALIENT FEATURES : Reliable and trouble free operation. Very High Efficiency and Fast response. Low failure rate in all weather conditions (Indoor and Outdoor models) Solid state Micro controlled circuit. Rugged AC synchronous motor. Precise electronic sensing for all trips. Less active component avoids failure ratings. Output regulation of 0.5% can be achieved Zero Waveform Distortion No effect of power factor. Ruggedised construction, Excellent quality and high durability. Suitable for unbalanced input voltage conditions and unbalanced load conditions APPLICATIONS : CNC Machines, Laser Machines and Molding Machines etc. Refrigeration and Air-conditioning. Laboratory equipment’s. Office Automation. Research Labs. Domestic Purpose. Computer and Micro-Processor Controlled Equipment’s. Processors, Phototypesetters, Photographic Equipment’s. Photo Copiers and Packaging Industries. Medical Equipment’s, X-Ray Machines, E.C.G. Machines I Monitors, MRI, CT Scans Etc.
