Vibration Meters Dealers in Bangalore

We are offering digital vibration meter.digital vibration meter are offering by us those are made by high grade of material. features : • 4 digits, 18mm lcd display • auto power off • max. Hold • measure accelerator / velocity / displacement with rpm & frequency • metric / imperial measurement • low battery indicator • ac output socket for headphones and recording • optional headphones for use as electronic stethoscope • optional rs-232 communication (advanced software program for all windows) technical data basic function metric imperial acceleration10hz-1khz (mode1) 0.1 ~ 200 m/s² 0.3 ~ 200ft/s² 10hz-10khz (mode 10) 0.3-200ft/ms² 0.3-1312ft/ms² velocity 10hz-1khz 0.01 ~ 40 cm/s 0.000 ~ 16.00"/s true rms 0.004-16.0inch displacement 10hz-1khz 0.001 ~ 4mm 0.04-160 mil rpm(revolution) : 60 ~ 99,990r/min frequency : 1 ~ 20khz • standard accessory : magnet, accelerometer, stinger probe (cone), stinger probe (ball), hard carrying case, manual • optional accessory : rs-232 cable with software, • dimensions : 124 x 62 x 30mm

Hand-held Vibration meter(VM516A0) is a portable and easy to use instrument which is used in conjunction with Integrated Electronics Piezoelectric (IEPE) accelerometers to measure mechanical vibrations in terms of acceleration, velocity and displacement. It is suitable for both laboratory and field conditions.This instrument can be used to monitor vibration levels in production machines on a periodic basis, so that action can be taken before a complete machine failure. It’s operation is simple and quite suitable for use by nonscientific personnel not conversant with electronic instrumentation. In combination with IPA piezoelectric accelerometers the unit provides direct read out of vibration parameters on a LCD screen in both Metric and Imperial units. The device uses a 2200mah rechargeable battery which gives a battery life upto 70hrs continuously following a full charge. It features a dedicated power save button for extended battery life. An output of 2V DC (F.S) is available for recording purpose.   Applications • Industrial Blowers.• Cooling Towers.• Electric Motors.• Diesel Engines.• Small Turbines.• Industrial Gearboxes.• Centrifuges and Decanters.• Centrifugal Pumps.• Test Benches.• Conveyers.

 Professional Vibration meter supply with vibration sensor full set•  Velocity range : 200 mm/S•  Acceleration range : 200 m/S•  RMS & Peak measurement, peak function to hold the peak value.•  Wide frequency range.•  Memory function to record maximum and minimum readingswith recall.•  Separate Vibration probe, easy operation.•  Auto shut off saves battery life•  Built-in low battery indicator•  Heavy duty & compact housing case.•  Complete set with the hard carrying case.

• Brand Name: SV
• Weight: 0.3
• Color: White/Blue
• Application: Industrial/Laboratory/College/University_Industrial machinery vibration measurement
• Power Supply: Rechargable
• use for: Vibration Measurements
• Memory: Expandable upto 16 gb

filter : high-pass filter(1, 5, 10hz, 100hz-15khz cutoff)        - band-pass filter(0.5-300hz, 2hz-1khz, 10-500hz,        - 10hz-1khz cutoff – iso 10816)        - butterworth filter(1.6khz, 200hz, 100hz cutoff) 3 detectors : acceleration, velocity, displacement display : 3 detectors shows synchronous display of digital value & time trace graph integration time and time constant control value : rms, peak, peak-to-peak, min, max unit : acceleration m/s², cm/s², mm/s², µm/s², g, db       - velocity m/s, cm/s, mm/s, µm/s, db       - displacement m, cm, mm, µm, db real time measurement data and wave file recording and playing time constant : 35ms, 0.125ms, 1sec etc..

The Portable Vibration Meter is a battery powered portable instrument designed to operate with a constant current type accelerometer to make vibration measurement simple and convenient. Peak RMS, peak to peak are the various parameters that can be measured for acceleration, velocity and displacement. The instrument has a built in RS-232 PC serial interfaces for data capture and analysis. The system can store the machine signature for later analysis.or later analysis.
