Hydraulic Hacksaw Machine Dealers in Batala

• Weight: 100-200kg, 200-300kg, 300-400kg, 400-500kg, 500-600kg
• Color: Multi Colour
• Driven Type: Electric
• Warranty: 1year
• Type: Power Hacksaw Machine
• Application: Cutting Metal
• Certification: CE Certified
• Voltage: 220V, 380V
• Automatic Grade: Automatic
• Power: 1-3kw, 3-6kw, 6-9kw

• Weight: 100-200kg
• Driven Type: Electric
• Warranty: 1year
• Certification: CE Certified
• Voltage: 110V
• Automatic Grade: Automatic
• Power: 3-6kw

Strong construction and accurate performance- our Hydraulic Power Hacksaw Machines are totally worth every dime spent. Also, these Machines are acclaimed for simple & easy controls. We offer these Hydraulic Power Hacksaw Machines in ample of sizes, construction materials and other specifications to match the exacting requirements of client’s project. As a reputed Manufacturer, Supplier and Exporter, we fix very nominal prices for these Hydraulic Power Hacksaw Machines.

• Type: Automatic Hacksaw Machine
• Application: Cutting Metal
• Weight: 100-200kg
• Color: Black
• Voltage: 110V
• Automatic Grade: Automatic
• Driven Type: Electric

Generally the mechanism of this Hydraulic Hacksaw Machine has been reselected with the latest technology to increase efficiency, run the machine Free-load, to consume less power and give heavy output. All parts of Hydraulic Hacksaw Machine free-load are designed to consume less power and give heavy output; also, all parts of Hydraulic Hacksaw Machine are interchangeable. The bore of this Hydraulic Hacksaw Machine is very closely reamed, double ball bearing are fitted in disc arm, at its connection with the disc, the main crank-shaft runs in heavy duty taper roller-bearing. The Bed : in of heavy dimension provided with guide way for the vice, to clamp the work pice. One jaw of the vice is fixed while the other is adjusted according to the material diameter. Saw Frame : is of rigid construction and runs in prismatic guide insuring a square and parallel cut. The cut takes place on draw stroke, and the blade is hydraulically lifted out of contact with forward stroke to prevent wear of the blade, and can cut all types of metal which are machinable of all strength. Feed : Two levers are provided at the dash-pot. The small lever regulates the rate of feed, while the other big one enables the slide to start cutting or to be raised the slide automatically on cycle and hte motor switched off automatically. Speed : A two speed drive macnaism are incorporated for the selection of the most suitable speed for the material being cut. Cooling the machine comes with a very reliable and efficient centrifugal pump, for quick cooling the blade. It comes with connection pipes from water tank to stay put on the work pice. The pump is driven by a intermediate drive. Standard Accessories : All machines are supplied with centrifugal water pump, motor-pully, motor-plate, but without 'v' belts and electricals. Extra Accessories : Angular vice simple, angular vice with graduation, electric-motor and starter, 'V' belts, blade. A direct on line push-button. Starter can be incorported which sets into motor an adjustable trip mechanism which stops the machine as soon as the blade is clear from work. The non-productive time is reduced to minimum.

• Weight: 100-200kg
• Color: Natural
• Driven Type: Electric
• Warranty: 1year
• Type: Power Hacksaw Machine
• Application: Cutting Metal
• Certification: CE Certified
• Voltage: 110V
• Automatic Grade: Automatic
• Power: 1-3kw

We offer an extensive array of hydraulic hacksaw machine , which is fabricated using superior grade raw material, that is in compliance with the industry norms. Furthermore, we use the latest techniques and methods to manufacture our range of hydraulic hacksaw machine.relying on our extensive experience, we have gain mastery in the manufacturing of hydraulic hacksaw machine. Hydraulic hacksaw machines are broadly demanded to cut accurately and quickly all substances from plastic to steel. Moreover, we also make these machines in tailor made specifications as per client requirement. Besides, you can avail the complete array of these machines at much reduced rates. These machines ensure proper cutting of the substance. Precisely so, we are celebrated as one of the chief hydraulic control hacksaw machine manufacturers based in india.

• Weight: 100-200kg
• Color: Light White
• Driven Type: Electric
• Warranty: 1year
• Application: Cutting Metal
• Voltage: 220V
• Automatic Grade: Automatic
• Power: 1-3kw

R.P. Engineering Company is listed as one of the supreme Hydraulic Hacksaw Machines Manufacturers, Suppliers and Exporters from India. Genuine grade Pig Iron and Steel is used in the manufacturing that ensures countable features and compliance to the ISO 9001:2015 quality standards. These Hydraulic Hacksaw Machines are also available in customized specifications to meet the requirements of the buyers. The Hydraulic Hacksaw Machines are a perfect combination of technology and precision. These are available at market leading prices and delivered within the stipulated time frame. Moreover, we have ascertained utmost satisfaction to our valued clients. APPLICATIONS OF HYDRAULIC HACKSAW MACHINES The Hydraulic Hacksaw Machines are designed in standard as well as customized specifications to meet the requirements of the industries like Steel Plants, Rolling Mills, Heavy Industry, Cement Plants, Paper Mills, Sugar Mills, Engineering Workshops, etc. Here listed are a few of our esteemed clients: Army Base Workshops Ordnance Factories Railways NTPC BHEL NMDC FEATURES OF HYDRAULIC HACKSAW MACHINES Below mentioned are the notable attributes of Hydraulic Hacksaw Machines that make them widely demanded in the domestic as well as international market. High productivity Corrosion-resistance Trouble free service Optimum performance Long lasting We have acquired huge clientele base in the regions of Uttar Pradesh, Nagaland, Uttarakhand, Mizoram, Rajasthan, Meghalaya, Punjab, Manipur, Odisha, etc., catering excellent products and prompt service. Moreover, we have also extended our business network internationally covering regions of UAE, Saudi Arab, Sri Lanka, Nigeria, Bangladesh, Oman, UK, Kenya, etc.

“Kailash" Brand Hydraulic Control Hacksaw Machine has been designed to cut quickly & accurately all material from nickel chrome steel to plastic, controls are simple & easy, An automatic cut out operates at the completion of the operation Er the bow slide retums to the top position, The machines has attractive appearance. Bed : The bed is of rigid casting with a wide through for collection of coolant, swarf & also houses the V-belts device, bed is single piece casting. Saw Frame : The saw frame is of rigid construction & runs in prismatic guide ensuring a square & parallel out & this cut takes place on the backward pull stroke, The blade is hydraulically lifted out of contact with work place on the forward stroke to prevent wear of the blade. The Drive : The drive is given to the machine through V-Pullys with provision to adiust fully the tension of the V-Belts. The shafts are fitted with taper and ball bearings which eliminate friction. Speed : Two speeds has been provided in order to make it suitable for all metals. High speed for metals like mild steel, brass, copper etc. and low speed for cast iron. Feed Saw : Feed saw is controlled hyd aulically by two levers provided at the dash-pot. One controls the rate of feed, while the other enables the bow slide to be raised or lowered and the motor gets switched off on completion of the cut. Vice : The vice is rigid construction. The one iaw remains fixed while other can be adjusted according to the size ofthe material to be cut. Coolant : The coolant tank is totally enclosed in the machine base with a constant speed pump which continuously supplies coolant to the saw blade. Electricals : Push button starter is fitted with an adjustable trip mechanism which stops the machine soon after the blade is clear from the work at extra cost.

KRISHNA MACHINE TOOLS is one of the reputed Manufacturers, Exporters, and Suppliers of Hydraulic Hacksaw Machine. The Hacksaw Machine has a rigid construction and runs in prismatic guide ensuring a parallel cut. This cut takes place on the draw stroke and hydraulically lifted out of contacts with the work piece on the forward stroke to prevent wear or the blade and cut out metals of all kinds and strength.

We are engaged in manufacturing and supplying Hydraulic Power Hacksaw Machine. Our Hydraulic Power Hacksaw Machines are supplied to various clients across the countries. We manufacture the Hydraulic Power Hacksaw Machines by using the latest techniques. Our Hydraulic Power Hacksaw Machines are admired by the clients for their precise make and advanced functioning. We offer Hydraulic Power Hacksaw Machine at reasonably market leading price. Why Our Hydraulic Power Hacksaw Machine? Easy operationHighly advanced featuresCorrosion resistantServe for a longer duration Standard Accessories Mechanical Coolant PumpMotor PulleyStarter PlateLength Gauge Belts GuardsFlexible Coolant pipe Extra Accessories V - belts, BladeHydraulic OilBar StandMotorStarterElectrical WiringThree Speed Gear Box Technical SpecificationsModelM-175M-200M-250M-300M-350M-400M-500M-600Cap. of Round Bar175200250300350400500600Cap. of Square Bar125150200250275352350425Strocke135135140140140135150150Strocke per min. (approx)100-200100-20085-10085-10085-10070-8570-8570-85Blade Size12"-14"14"-16"16"-18"18"-20"20"-22"18"-24"24"-32"30"-36"Electric Motor1.H.P.1.H.P.2.H.P.2.H.P.2.H.P.3.H.P.5.H.P.5.H.P.RPM of Motor144014401440144014401440960960Length10001000115012501300150016501750Width6006006256506506757500725Height800800100010001000120013001400Weight (approx.)325 Kg.325 Kg.450 Kg.550 Kg.650 Kg.750 Kg.1100 Kg.1200 Kg.Weight with Packing400 Kg.450 Kg.500 Kg.650 Kg.775 Kg.900 Kg.1300 Kg.1400 Kg.V - Belts Required 4 Pcs.4 Pcs.4 Pcs.4 Pcs.4 Pcs.5 Pcs.6 Pcs.6 Pcs. Note : All Specifications are subjected to change without prior notice

We are Manufacturer, Supplier and Exporter of Hydraulic Hacksaw Machine. Based in Punjab, we are offering Hydraulic Hacksaw Machine in various grades and specifications all over the world. We ensure safe and easy delivery of these Hydraulic Hacksaw Machines gaining maximum client satisfaction. Moreover, we can easily handle bulk orders of Hydraulic Hacksaw Machine as per the requirement of the clients.

We are offering hydraulic hacksaw machines hydraulic hacksaw machines fabricated by us is precision engineered so as to meet the modern demands of several industries. Due to their smooth & swift functioning ability they are able to operate in a spontaneous way which aids the worker in consistently carrying his work with ultimate efficiency. Some of the specifications of the power hacksaw machine that we supply are listed below: size 7” 8” 10” 12” 14” 16” 18' 20” stroke 5.5” 5.5” 5.5” 5.5” 5.5” 5.5” 5.5” 5.5” stroke per minute 110 110 95 95 95 80 70 70 power reod. (in h.p) 1 1 1.5 2 2 3 3 5 blade size 14” 16” 18” 20” 22” 24” 28” 30” round bar cap. 7” 8” 10” 12” 14” 16” 18” 20” square bar cap. 5” 6” 8” 11” 11” 13” 14” 15

• CUTTING CAP. IN ROUND BAR: 178 MM
• SIZE OF BLADE ( MM ): 300 – 350

THE BED: is of heavy dimension provided with guide way for the vice, to clamp the work pice. One jaw of the vice is fixed while the other is adjusted according to the material diameter.
