Geared Pillar Drilling Machine SSC-A/2 Technical Specification Machine Capacity 40 mm Column Diameter 130 mm Centre of Spindle to Column 305 mm Distance Spindle to Table 515 mm Distance Spindle to Base 1040 mm Spindle Nose MT - 4 Spindle Travel 215 mm Range of Spindle Speed 75 / 2070 RPM No. of Spindle Speed 8 Range of power feed (2) 0.08 0.04 Table size 435 x 435 mm Base size (machined area) 490 x 470 mm V-Belt Section B - 62 Overall Height with guard 1830 mm Main Electrical Motor 1.5 HP Wooden Case L x W x H 1140 x 650 x 1950 mm

• Model: JIR 35
• Drilling Cap.: 35
• Tapping Cap.: 20
• Spindle RAM Dia.: 75
• Spindle Hole Taper: MT- 4
• Spindle Travel: 200
• Spindle Speed: 88-2600 x 8
• Spindle Autofeed Ranges: Fine Feed
• Max./Min. Dist. Spindle nose to Base: 900/250
• Max./Min. Dist. Spindle center to Column: 700/300
• Drilling Radius: 800
• Dia. Of Column: 130
• Work Table: 300 x 300x 385
• Drill Head Motor: 1.5HP,1440RPM
• Elevating Motor: 0.5HP 1440 RPM
• V- Belt Size for Head Motor: B39
• V- Belt Size for Elevating Motor: A21
