Hand Drill Dealers in Bhavnagar

Universal Radial Drilling Machine SMTR-I Technical Specification : Capacity : M.S. C.I. Drill Capacity 38 mm 38 mm Drill Head : 1. Spindle nose MT 4 2. Spindle Travel 220 3. No. of Spindle Speed 8 4. Range of Spindle Speed 62-1980 5. Range of Power Feed mm / Rev. (2) 0.08-0.04 Power : H.P. V. Belt Main Motor 1.5 B-44 Arm Elevating Motor 0.5 A-23 Working Table : L x M x W mm. 380x300x300 Working Range : 1. Drilling Radius Max./Min. mm. 895/440 2. Distance from column to Spindle Max./Min. mm. 810/360 3. Max Drill Head Travel mm. 450 4. Distance from Base to Spindle Max./Min mm. 930/230 5. Diametere of Column mm. 165 6. Swivel of Arm L/R Side mm. 90 Base Plate : 1. L x W x H mm. 925x600x120 mm 2. Working Surface mm. 820x610 mm 3. No. of T-Slots mm. 4/16 mm 4. Overall Height mm. 2000 mm Wooden case size L x W x H mm. 1250x1550x2000 mm
